The Fiat Stilo Multi Wagon 1.4 16V (90 hp) was a practical and affordable station wagon offered by Fiat between 2006 and 2008, following the facelift of the Stilo range. Positioned as an entry-level variant within the Multi Wagon lineup, it aimed to provide economical transportation for families and individuals needing a versatile vehicle. This model was primarily sold in European markets, where the station wagon body style remained popular. It represented Fiat’s attempt to compete in the crowded compact estate segment, offering a blend of practicality, reasonable performance, and Italian styling.
Technical Specifications
| Brand | Fiat |
| Model | Stilo |
| Generation | Stilo Multi Wagon (facelift 2006) |
| Type (Engine) | 1.4 16V (90 Hp) |
| Start of production | 2006 |
| End of production | 2008 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Fuel consumption (urban) | 8.7 l/100 km (27 US mpg, 32.5 UK mpg, 11.5 km/l) |
| Fuel consumption (extra urban) | 5.8 l/100 km (40.6 US mpg, 48.7 UK mpg, 17.2 km/l) |
| Fuel consumption (combined) | 6.8 l/100 km (34.6 US mpg, 41.5 UK mpg, 14.7 km/l) |
| CO2 emissions | 162 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 13 sec |
| Acceleration 0 – 62 mph | 13 sec |
| Acceleration 0 – 60 mph | 12.4 sec |
| Maximum speed | 176 km/h (109.36 mph) |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 13.7 kg/Hp, 72.9 Hp/tonne |
| Weight-to-torque ratio | 9.6 kg/Nm, 103.6 Nm/tonne |
| Power | 90 Hp @ 5500 rpm |
| Power per litre | 65.8 Hp/l |
| Torque | 128 Nm @ 4500 rpm (94.41 lb.-ft. @ 4500 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | 192B2000 |
| Engine displacement | 1368 cm3 (83.48 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 72 mm (2.83 in.) |
| Piston Stroke | 84 mm (3.31 in.) |
| Compression ratio | 11.2:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 2.8 l (2.96 US qt | 2.46 UK qt) |
| Coolant | 5.25 l (5.55 US qt | 4.62 UK qt) |
| Kerb Weight | 1235 kg (2722.71 lbs.) |
| Max. weight | 1745 kg (3847.07 lbs.) |
| Max load | 510 kg (1124.36 lbs.) |
| Trunk (boot) space – minimum | 510 l (18.01 cu. ft.) |
| Trunk (boot) space – maximum | 1480 l (52.27 cu. ft.) |
| Fuel tank capacity | 58 l (15.32 US gal | 12.76 UK gal) |
| Max. roof load | 80 kg (176.37 lbs.) |
| Permitted trailer load with brakes (12%) | 1000 kg (2204.62 lbs.) |
| Permitted trailer load without brakes | 500 kg (1102.31 lbs.) |
| Permitted towbar download | 60 kg (132.28 lbs.) |
| Length | 4516 mm (177.8 in.) |
| Width | 1756 mm (69.13 in.) |
| Height | 1570 mm (61.81 in.) |
| Wheelbase | 2600 mm (102.36 in.) |
| Front track | 1514 mm (59.61 in.) |
| Rear (Back) track | 1508 mm (59.37 in.) |
| Front overhang | 893 mm (35.16 in.) |
| Rear overhang | 1023 mm (40.28 in.) |
| Minimum turning circle | 10.6 m (34.78 ft.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Coil spring, Torsion |
| Front brakes | Ventilated discs, 284 mm |
| Rear brakes | Disc, 251 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 195/65 R15 |
| Wheel rims size | 6.5 J x 15 |
INTRODUCTION
The Fiat Stilo Multi Wagon, particularly the 1.4 16V variant introduced after the 2006 facelift, was a five-door station wagon based on the 1HX0/A3 platform shared with other Stellantis vehicles. It served as the practical, estate version of the Stilo hatchback, offering increased cargo capacity and versatility. This specific engine and transmission combination was aimed at buyers prioritizing fuel efficiency and affordability over outright performance. It occupied the lower end of the Multi Wagon range, with higher trims featuring larger engines and more luxurious appointments. The facelift brought subtle styling changes, including revised headlights and bumpers, along with improvements to the interior.
Powertrain & Engine Architecture
The heart of the Stilo Multi Wagon 1.4 16V is the 192B2000 engine, a 1368cc inline-four cylinder petrol engine. This engine utilizes a multi-port fuel injection system and a double overhead camshaft (DOHC) valvetrain, operating with four valves per cylinder. The 16V designation refers to the total number of valves. The engine’s 11.2:1 compression ratio contributes to its efficiency, though it limits its potential for high-performance tuning. The engine was typically paired with a five-speed manual transmission, although an automatic option was also available, albeit less common. The automatic transmission was a conventional torque converter type, prioritizing smooth shifts over sporty responsiveness. This engine code was a common one within the Fiat/Alfa Romeo range during this period, known for its relative simplicity and ease of maintenance.
Driving Characteristics
The 1.4 16V engine, producing 90 horsepower, provided adequate, but not exhilarating, performance in the Stilo Multi Wagon. Acceleration from 0-60 mph took around 12.4 seconds, and top speed was approximately 109 mph. The car felt most comfortable during relaxed cruising on highways or city streets. The automatic transmission, while offering convenience, resulted in some power loss compared to the manual version. Gear ratios were tuned for fuel economy rather than rapid acceleration. Compared to the more powerful 1.8 or 2.0-liter engines available in other Stilo models, the 1.4 felt noticeably slower, especially when fully loaded with passengers and cargo. However, its lighter weight and efficient engine contributed to better fuel economy.
Equipment & Trim Levels
The 1.4 16V Multi Wagon typically came with a reasonable level of standard equipment. This included central locking, electric front windows, power steering, and an ABS anti-lock braking system. Interior upholstery was usually cloth, with a functional, if somewhat basic, dashboard layout. Optional extras included air conditioning, alloy wheels, a CD stereo system, and rear electric windows. Higher trim levels added features like climate control, upgraded upholstery, and more sophisticated audio systems. The focus of this trim level was practicality and value, so luxury features were often kept to a minimum or offered as optional upgrades.
Chassis & Braking
The Stilo Multi Wagon featured an independent McPherson strut suspension at the front and a coil spring torsion beam suspension at the rear. This setup provided a comfortable ride quality, suitable for everyday driving. The front brakes were ventilated discs, offering good stopping power, while the rear brakes were solid discs. The steering was rack and pinion with electric power assistance, providing a light and easy driving experience. Stabilizer bars were fitted to both the front and rear axles to reduce body roll during cornering. The suspension was tuned for comfort rather than sporty handling, prioritizing a smooth ride over sharp responsiveness.
Market Reception & Comparison
The Fiat Stilo Multi Wagon 1.4 16V was generally well-received as a practical and affordable family car. Critics praised its spacious interior, versatile cargo area, and reasonable fuel economy. However, it was often criticized for its lack of outright performance and somewhat uninspired styling. Compared to rivals like the Ford Focus Estate or Volkswagen Golf Estate, the Stilo offered a more affordable price point but lacked the same level of refinement and driving dynamics. The 1.4 engine was considered adequate for most everyday driving needs, but those requiring more power or frequently carrying heavy loads would likely opt for a higher-spec model. Fuel economy was a strong point, making it an attractive option for budget-conscious buyers.
Legacy
The Fiat Stilo Multi Wagon 1.4 16V has become a relatively affordable and reliable used car option. The 192B2000 engine is known for its durability, provided it has been regularly maintained. Common issues include occasional sensor failures and wear and tear on suspension components. Parts availability is generally good, and maintenance costs are relatively low. While it may not offer the prestige or performance of some of its rivals, the Stilo Multi Wagon 1.4 16V remains a practical and economical choice for those seeking a spacious and versatile estate car.
