| General information | |
|---|---|
| Brand | Ford |
| Model | F-350 Super Duty |
| Generation | F-350 Super Duty IV Crew Cab Short box |
| Type (Engine) | 6.2 V8 (385 Hp) 4×4 Automatic SRW |
| Start of production | 2017 year |
| End of production | 2019 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 6 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 7.9 kg/Hp, 126.8 Hp/tonne |
| Weight-to-torque ratio | 5.2 kg/Nm, 192 Nm/tonne |
| Engine specs | |
| Power | 385 Hp @ 5750 rpm. |
| Power per litre | 62 Hp/l |
| Torque | 583 Nm @ 3800 rpm. 430 lb.-ft. @ 3800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine displacement | 6211 cm3 379.02 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Cylinder Bore | 102.1 mm 4.02 in. |
| Piston Stroke | 95 mm 3.74 in. |
| Compression ratio | 9.8:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 6.6 l 6.97 US qt | 5.81 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 20.2 l 21.35 US qt | 17.77 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 3036-3062 kg 6693.23 – 6750.55 lbs. |
| Trunk (boot) space – minimum | 1852 l 65.4 cu. ft. |
| Fuel tank capacity | 182 l 48.08 US gal | 40.03 UK gal |
| Permitted trailer load with brakes (12%) | 5534 kg 12200.38 lbs. |
| Dimensions | |
| Length | 6350 mm 250 in. |
| Width | 2032 mm 80 in. |
| Width including mirrors | 2690 mm 105.91 in. |
| Height | 2065 mm 81.3 in. |
| Wheelbase | 4059 mm 159.8 in. |
| Front track | 1735 mm 68.31 in. |
| Rear (Back) track | 1707 mm 67.2 in. |
| Front overhang | 970 mm 38.19 in. |
| Rear overhang | 1321 mm 52.01 in. |
| Ride height (ground clearance) | 208 mm 8.19 in. |
| Approach angle | 17.5° |
| Departure angle | 21.2° |
| Ramp-over (brakeover) angle | 22.4° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 6 gears, automatic transmission TorqShift |
| Front suspension | Dependent spring suspension with anti-roll bar, Trailing arm |
| Rear suspension | Rigid axle suspension, Leaf spring |
| Front brakes | Ventilated discs, 363 mm |
| Rear brakes | Ventilated discs, 363 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | 245/75 R17 |
| What is the body type, Ford F-350 Super Duty IV Crew Cab Short box? | Pick-up, 4 Doors, 6 Seats |
|---|---|
| How much power, Ford F-350 Super Duty Pick-up 2017 6.2 V8 (385 Hp) 4×4 Automatic SRW? | 385 Hp, 583 Nm 430 lb.-ft. |
| What is the engine size, Ford F-350 Super Duty Pick-up 2017 6.2 V8 (385 Hp) 4×4 Automatic SRW? | 6.2 l 6211 cm3 379.02 cu. in. |
| How many cylinders, 2017 Ford 6.2 V8 (385 Hp) 4×4 Automatic SRW? | 8, V-engine |
| What is the drivetrain, Ford F-350 Super Duty IV Crew Cab Short box Pick-up 2017 6.2 V8 (385 Hp) 4×4 Automatic SRW? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2017 Ford F-350 Super Duty Pick-up? | 6350 mm 250 in. |
| How wide is the vehicle, 2017 Ford F-350 Super Duty Pick-up? | 2032 mm 80 in. |
| What is the curb weight, 2017 Ford F-350 Super Duty IV Crew Cab Short box 6.2 V8 (385 Hp) 4×4 Automatic SRW? | 3036-3062 kg 6693.23 – 6750.55 lbs. |
| How much trunk (boot) space, 2017 Ford F-350 Super Duty Pick-up? | 1852 l 65.4 cu. ft. |
| How many gears, What type is the gearbox, 2017 Ford F-350 Super Duty IV Crew Cab Short box 6.2 V8 (385 Hp) 4×4 Automatic SRW? | 6, automatic transmission TorqShift |
