| General information | |
|---|---|
| Brand | Ford |
| Model | F-Series F-100/F-150 |
| Generation | F-Series F-1 I Panel |
| Type (Engine) | 3.9 239 V8 (100 Hp) |
| Start of production | November, 1947 year |
| End of production | 1952 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 2-3 |
| Doors | 3 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Engine specs | |
| Power | 100 Hp @ 3800 rpm. |
| Power per litre | 25.5 Hp/l |
| Engine layout | Front, Longitudinal |
| Engine displacement | 3917 cm3 239.03 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Compression ratio | 6.8:1 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
|
|
|
| Space, Volume and weights | |
| Max. weight | 2132 kg 4700.26 lbs. |
| Trunk (boot) space – maximum | 4539 l 160.29 cu. ft. |
| Fuel tank capacity | 64 l 16.91 US gal | 14.08 UK gal |
| Dimensions | |
| Length | 5139 mm 202.32 in. |
| Width | 1921 mm 75.63 in. |
| Height | 2011 mm 79.17 in. |
| Wheelbase | 2896 mm 114.02 in. |
| Wading depth | 605 mm 23.82 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 3 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Dependent, multi-link spring with telescopic shock absorbers |
| Front brakes | Drum |
| Rear brakes | Drum |
| Wheel rims size | 16 |
| What is the body type, Ford F-Series F-1 I Panel? | Minivan, 3 Doors, 2-3 Seats |
|---|---|
| How much power, Ford F-Series F-100/F-150 Minivan 1947 3.9 239 V8 (100 Hp)? | 100 Hp |
| What is the engine size, Ford F-Series F-100/F-150 Minivan 1947 3.9 239 V8 (100 Hp)? | 3.9 l 3917 cm3 239.03 cu. in. |
| How many cylinders, 1947 Ford 3.9 239 V8 (100 Hp)? | 8, V-engine |
| What is the drivetrain, Ford F-Series F-1 I Panel Minivan 1947 3.9 239 V8 (100 Hp)? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 1947 Ford F-Series F-100/F-150 Minivan? | 5139 mm 202.32 in. |
| How wide is the vehicle, 1947 Ford F-Series F-100/F-150 Minivan? | 1921 mm 75.63 in. |
| What is the gross weight, 1947 Ford F-Series F-1 I Panel 3.9 239 V8 (100 Hp)? | 2132 kg 4700.26 lbs. |
| How much trunk (boot) space, 1947 Ford F-Series F-100/F-150 Minivan? | 4539 l 160.29 cu. ft. |
| How many gears, What type is the gearbox, 1947 Ford F-Series F-1 I Panel 3.9 239 V8 (100 Hp)? | 3, manual transmission |
