| General information | |
|---|---|
| Brand | Ford |
| Model | F-Series F-100/F-150 |
| Generation | F-Series F-1 I Pickup |
| Type (Engine) | 3.9 239 V8 (100 Hp) |
| Start of production | November, 1947 year |
| End of production | 1952 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 2-3 |
| Doors | 2 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Engine specs | |
| Power | 100 Hp @ 3800 rpm. |
| Power per litre | 25.5 Hp/l |
| Engine layout | Front, Longitudinal |
| Engine displacement | 3917 cm3 239.03 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Compression ratio | 6.8:1 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
|
|
|
| Space, Volume and weights | |
| Max. weight | 2132 kg 4700.26 lbs. |
| Trunk (boot) space – minimum | 1274 l 44.99 cu. ft. |
| Fuel tank capacity | 76 l 20.08 US gal | 16.72 UK gal |
| Dimensions | |
| Length | 4803 mm 189.09 in. |
| Width | 1929 mm 75.94 in. |
| Height | 1921 mm 75.63 in. |
| Wheelbase | 2896 mm 114.02 in. |
| Front track | 1475 mm 58.07 in. |
| Rear (Back) track | 1524 mm 60 in. |
| Front overhang | 908 mm 35.75 in. |
| Rear overhang | 999 mm 39.33 in. |
| Ride height (ground clearance) | 207 mm 8.15 in. |
| Wading depth | 534-612 mm 21.02 – 24.09 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 3 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Dependent, multi-link spring with telescopic shock absorbers |
| Front brakes | Drum |
| Rear brakes | Drum |
| Wheel rims size | 16 |
| What is the body type, Ford F-Series F-1 I Pickup? | Pick-up, 2 Doors, 2-3 Seats |
|---|---|
| How much power, Ford F-Series F-100/F-150 Pick-up 1947 3.9 239 V8 (100 Hp)? | 100 Hp |
| What is the engine size, Ford F-Series F-100/F-150 Pick-up 1947 3.9 239 V8 (100 Hp)? | 3.9 l 3917 cm3 239.03 cu. in. |
| How many cylinders, 1947 Ford 3.9 239 V8 (100 Hp)? | 8, V-engine |
| What is the drivetrain, Ford F-Series F-1 I Pickup Pick-up 1947 3.9 239 V8 (100 Hp)? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 1947 Ford F-Series F-100/F-150 Pick-up? | 4803 mm 189.09 in. |
| How wide is the vehicle, 1947 Ford F-Series F-100/F-150 Pick-up? | 1929 mm 75.94 in. |
| What is the gross weight, 1947 Ford F-Series F-1 I Pickup 3.9 239 V8 (100 Hp)? | 2132 kg 4700.26 lbs. |
| How much trunk (boot) space, 1947 Ford F-Series F-100/F-150 Pick-up? | 1274 l 44.99 cu. ft. |
| How many gears, What type is the gearbox, 1947 Ford F-Series F-1 I Pickup 3.9 239 V8 (100 Hp)? | 3, manual transmission |
