| General information | |
|---|---|
| Brand | Ford |
| Model | F-Series F-100/F-150 |
| Generation | F-Series F-150 XIV SuperCrew (facelift 2023) |
| Type (Engine) | 3.5 EcoBoost V6 (400 Hp) SelectShift |
| Start of production | September, 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 5-6 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban (EPA) | 13.8 l/100 km 17 US mpg 20.5 UK mpg 7.2 km/l |
| Fuel consumption (economy) – extra urban (EPA) | 9.4 l/100 km 25 US mpg 30.1 UK mpg 10.6 km/l |
| Fuel consumption (economy) – combined (EPA) | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 5.5 kg/Hp, 182.1 Hp/tonne |
| Weight-to-torque ratio | 3.2 kg/Nm, 308.6 Nm/tonne |
| Engine specs | |
| Power | 400 Hp @ 6000 rpm. |
| Power per litre | 114.4 Hp/l |
| Torque | 678 Nm @ 3100 rpm. 500.07 lb.-ft. @ 3100 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | EcoBoost |
| Engine displacement | 3497 cm3 213.4 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 92.5 mm 3.64 in. |
| Piston Stroke | 86.7 mm 3.41 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection and Multi-port manifold injection |
| Engine aspiration | Twin-Turbo, Intercooler |
| Valvetrain | DOHC, Ti-VCT |
| Engine oil capacity | 5.7 l 6.02 US qt | 5.02 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 13.5 l 14.27 US qt | 11.88 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2197 kg 4843.56 lbs. |
| Max. weight | 3084 kg 6799.06 lbs. |
| Max load | 887 kg 1955.5 lbs. |
| Trunk (boot) space – minimum | 1495 l 52.8 cu. ft. |
| Fuel tank capacity | 136 l 35.93 US gal | 29.92 UK gal |
| Permitted trailer load with brakes (12%) | 5806 kg 12800.04 lbs. |
| Dimensions | |
| Length | 5893 mm 232.01 in. |
| Width | 2029 mm 79.88 in. |
| Width with mirrors folded | 2123 mm 83.58 in. |
| Width including mirrors | 2431 mm 95.71 in. |
| Height | 1915 mm 75.39 in. |
| Wheelbase | 3693 mm 145.39 in. |
| Front track | 1725 mm 67.91 in. |
| Rear (Back) track | 1735 mm 68.31 in. |
| Front overhang | 950 mm 37.4 in. |
| Rear overhang | 1250 mm 49.21 in. |
| Ride height (ground clearance) | 208 mm 8.19 in. |
| Minimum turning circle (turning diameter) | 14.6 m 47.9 ft. |
| Approach angle | 21° |
| Departure angle | 18.6° |
| Ramp-over (brakeover) angle | 17.1° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 10 gears, automatic transmission SelectShift |
| Front suspension | Double wishbone, Independent coil spring |
| Rear suspension | Rigid axle suspension, Leaf spring |
| Front brakes | Ventilated discs, 350×34 mm |
| Rear brakes | Ventilated discs, 336×20 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/70 R17; 265/70 R17; 265/60 R18; 265/70 R18; 275/65 R18; 275/60 R20; 275/50 R22 |
| Wheel rims size | 17; 18; 20; 22 |
| What is the body type, Ford F-Series F-150 XIV SuperCrew (facelift 2023)? | Pick-up, 4 Doors, 5-6 Seats |
|---|---|
| What is the fuel economy, Ford F-Series F-150 XIV SuperCrew (facelift 2023) 3.5 EcoBoost V6 (400 Hp) SelectShift? | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| How much power, Ford F-Series F-100/F-150 Pick-up 2023 3.5 EcoBoost V6 (400 Hp) SelectShift? | 400 Hp, 678 Nm 500.07 lb.-ft. |
| What is the engine size, Ford F-Series F-100/F-150 Pick-up 2023 3.5 EcoBoost V6 (400 Hp) SelectShift? | 3.5 l 3497 cm3 213.4 cu. in. |
| How many cylinders, 2023 Ford 3.5 EcoBoost V6 (400 Hp) SelectShift? | 6, V-engine |
| What is the drivetrain, Ford F-Series F-150 XIV SuperCrew (facelift 2023) Pick-up 2023 3.5 EcoBoost V6 (400 Hp) SelectShift? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2023 Ford F-Series F-100/F-150 Pick-up? | 5893 mm 232.01 in. |
| How wide is the vehicle, 2023 Ford F-Series F-100/F-150 Pick-up? | 2029 mm 79.88 in. |
| What is the curb weight, 2023 Ford F-Series F-150 XIV SuperCrew (facelift 2023) 3.5 EcoBoost V6 (400 Hp) SelectShift? | 2197 kg 4843.56 lbs. |
| What is the gross weight, 2023 Ford F-Series F-150 XIV SuperCrew (facelift 2023) 3.5 EcoBoost V6 (400 Hp) SelectShift? | 3084 kg 6799.06 lbs. |
| How much trunk (boot) space, 2023 Ford F-Series F-100/F-150 Pick-up? | 1495 l 52.8 cu. ft. |
| How many gears, What type is the gearbox, 2023 Ford F-Series F-150 XIV SuperCrew (facelift 2023) 3.5 EcoBoost V6 (400 Hp) SelectShift? | 10, automatic transmission SelectShift |
