| General information | |
|---|---|
| Brand | Ford |
| Model | F-Series F-100/F-150 |
| Generation | F-Series F-150 XIV SuperCrew (facelift 2023) |
| Type (Engine) | 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT |
| Start of production | September, 2023 year |
| Powertrain Architecture | FHEV (Full Hybrid Electric Vehicle) |
| Body type | Pick-up |
| Seats | 5-6 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban (EPA) | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| Fuel consumption (economy) – extra urban (EPA) | 9.8 l/100 km 24 US mpg 28.8 UK mpg 10.2 km/l |
| Fuel consumption (economy) – combined (EPA) | 10.2 l/100 km 23.1 US mpg 27.7 UK mpg 9.8 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 5.9 kg/Hp, 169.8 Hp/tonne |
| Weight-to-torque ratio | 3.3 kg/Nm, 305.2 Nm/tonne |
| Electric cars and hybrids specs | |
| Electric motor 1 | |
| Electric motor location | Between the combustion engine and the transmission |
| System power | 430 Hp @ 6000 rpm. |
| System torque | 773 Nm @ 3000 rpm. 570.14 lb.-ft. @ 3000 rpm. |
| Internal combustion engine specs | |
| Engine layout | Front, Longitudinal |
| Engine displacement | 3497 cm3 213.4 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 92.5 mm 3.64 in. |
| Piston Stroke | 86.7 mm 3.41 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection and Multi-port manifold injection |
| Engine aspiration | Twin-Turbo, Intercooler |
| Valvetrain | DOHC, Ti-VCT |
| Engine oil capacity | 5.7 l 6.02 US qt | 5.02 UK qt |
| Engine oil specification |  Log in to see. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2533 kg 5584.31 lbs. |
| Max. weight | 3357 kg 7400.92 lbs. |
| Max load | 824 kg 1816.61 lbs. |
| Trunk (boot) space – minimum | 1495 l 52.8 cu. ft. |
| Fuel tank capacity | 116 l 30.64 US gal | 25.52 UK gal |
| Permitted trailer load with brakes (12%) | 5080 kg 11199.48 lbs. |
| Dimensions | |
| Length | 5893 mm 232.01 in. |
| Width | 2029 mm 79.88 in. |
| Width with mirrors folded | 2123 mm 83.58 in. |
| Width including mirrors | 2431 mm 95.71 in. |
| Height | 1958 mm 77.09 in. |
| Wheelbase | 3693 mm 145.39 in. |
| Front track | 1725 mm 67.91 in. |
| Rear (Back) track | 1735 mm 68.31 in. |
| Front overhang | 950 mm 37.4 in. |
| Rear overhang | 1250 mm 49.21 in. |
| Ride height (ground clearance) | 249 mm 9.8 in. |
| Minimum turning circle (turning diameter) | 14.6 m 47.9 ft. |
| Approach angle | 24.2° |
| Departure angle | 21° |
| Ramp-over (brakeover) angle | 19.8° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 10 gears, automatic transmission Modular Hybrid Transmission |
| Front suspension | Double wishbone, Independent coil spring |
| Rear suspension | Rigid axle suspension, Leaf spring |
| Front brakes | Ventilated discs, 350×34 mm |
| Rear brakes | Ventilated discs, 336×20 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/70 R17; 265/70 R17; 265/60 R18; 265/70 R18; 275/65 R18; 275/60 R20; 275/50 R22 |
| Wheel rims size | 17; 18; 20; 22 |
| What is the body type, Ford F-Series F-150 XIV SuperCrew (facelift 2023)? | Pick-up, 4 Doors, 5-6 Seats |
|---|---|
| What is the fuel economy, Ford F-Series F-150 XIV SuperCrew (facelift 2023) 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT? | 10.2 l/100 km 23.1 US mpg 27.7 UK mpg 9.8 km/l |
| How much power, Ford F-Series F-100/F-150 Pick-up 2023 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT? | 430 Hp, 773 Nm 570.14 lb.-ft. |
| What is the engine size, Ford F-Series F-100/F-150 Pick-up 2023 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT? | 3.5 l 3497 cm3 213.4 cu. in. |
| How many cylinders, 2023 Ford 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT? | 6, V-engine |
| What is the drivetrain, Ford F-Series F-150 XIV SuperCrew (facelift 2023) Pick-up 2023 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT? | All wheel drive (4×4). FHEV (Full Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the rear wheels of the vehicle, capable of running in full electric or mixed mode, and if necessary through the electrically or mechanically controlled clutch, the front wheels are driven. |
| How long is this vehicle, 2023 Ford F-Series F-100/F-150 Pick-up? | 5893 mm 232.01 in. |
| How wide is the vehicle, 2023 Ford F-Series F-100/F-150 Pick-up? | 2029 mm 79.88 in. |
| What is the curb weight, 2023 Ford F-Series F-150 XIV SuperCrew (facelift 2023) 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT? | 2533 kg 5584.31 lbs. |
| What is the gross weight, 2023 Ford F-Series F-150 XIV SuperCrew (facelift 2023) 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT? | 3357 kg 7400.92 lbs. |
| How much trunk (boot) space, 2023 Ford F-Series F-100/F-150 Pick-up? | 1495 l 52.8 cu. ft. |
| How many gears, What type is the gearbox, 2023 Ford F-Series F-150 XIV SuperCrew (facelift 2023) 3.5 PowerBoost V6 (430 Hp) Full Hybrid 4×4 MHT? | 10, automatic transmission Modular Hybrid Transmission |
