The Ford Fiesta Mk4, produced between 1995 and 2002, represented a significant step forward for Ford’s supermini. The 3-door 1.4i 16V variant, available from 1996 to 1999, occupied a middle ground in the Fiesta Mk4 lineup, offering a balance between affordability, practicality, and reasonable performance. This model was aimed at buyers seeking a well-equipped and relatively efficient hatchback for daily commuting and urban driving. It sat below the more powerful Zetec models and above the base 1.3L variants, making it a popular choice in the European market, and to a lesser extent, in the UK.
Technical Specifications
| Brand | Ford |
| Model | Fiesta |
| Generation | Fiesta IV (Mk4) 3 door |
| Type (Engine) | 1.4 i 16V (90 Hp) |
| Start of production | 1996 |
| End of production | 1999 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 3/5 |
| Fuel consumption (urban) | 9.6 l/100 km (24.5 US mpg) |
| Fuel consumption (extra urban) | 6.1 l/100 km (38.6 US mpg) |
| Fuel consumption (combined) | 7.4 l/100 km (31.8 US mpg) |
| CO2 emissions | 175 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 10.8 sec |
| Acceleration 0 – 62 mph | 10.8 sec |
| Acceleration 0 – 60 mph | 10.3 sec |
| Maximum speed | 183 km/h (113.71 mph) |
| Weight-to-power ratio | 14.9 kg/Hp |
| Weight-to-torque ratio | 10.7 kg/Nm |
| Power | 90 Hp @ 5500 rpm |
| Torque | 125 Nm @ 4500 rpm (92.2 lb.-ft. @ 4500 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | FHA, FHE |
| Engine displacement | 1388 cm3 (84.7 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 76 mm (2.99 in.) |
| Piston Stroke | 76.5 mm (3.01 in.) |
| Compression ratio | 10.3:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated |
| Valvetrain | DOHC |
| Engine oil capacity | 4 l (4.23 US qt | 3.52 UK qt) |
| Coolant capacity | 6 l (6.34 US qt | 5.28 UK qt) |
| Kerb Weight | 1340 kg (2954.19 lbs.) |
| Max. weight | 1450 kg (3196.7 lbs.) |
| Max load | 110 kg (242.51 lbs.) |
| Trunk (boot) space – minimum | 250 l (8.83 cu. ft.) |
| Trunk (boot) space – maximum | 930 l (32.84 cu. ft.) |
| Fuel tank capacity | 42 l (11.1 US gal | 9.24 UK gal) |
| Permitted trailer load with brakes (12%) | 900 kg (1984.16 lbs.) |
| Permitted trailer load without brakes | 310 kg (683.43 lbs.) |
| Length | 3828 mm (150.71 in.) |
| Width | 1634 mm (64.33 in.) |
| Height | 1334 mm (52.52 in.) |
| Wheelbase | 2446 mm (96.3 in.) |
| Front track | 1429 mm (56.26 in.) |
| Rear track | 1384 mm (54.49 in.) |
| Drivetrain | Front wheel drive |
| Number of gears | 5 |
| Gearbox type | Manual transmission |
| Front suspension | Coil spring |
| Rear suspension | Coil spring |
| Front brakes | Disc |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic |
| Tires size | 185/55 R14 |
INTRODUCTION
The Ford Fiesta Mk4, launched in 1995, was a crucial model for Ford in Europe, representing a significant upgrade over its predecessor. The 3-door 1.4i 16V, produced from 1996-1999, was a popular choice for buyers looking for a practical and economical hatchback. Built on the 1HX0/A3 platform, this Fiesta offered improved safety, comfort, and refinement compared to earlier models. The 1.4L engine provided a good balance between performance and fuel efficiency, making it suitable for both city driving and longer journeys. This variant was positioned as a mid-range offering, bridging the gap between the entry-level 1.3L models and the sportier Zetec versions.
Powertrain & Engine Architecture
The heart of the Fiesta 1.4i 16V is the Ford FHA or FHE engine, a 1.4-liter (1388cc) inline-four cylinder petrol engine. This engine featured a multi-port fuel injection system and a double overhead camshaft (DOHC) valvetrain, contributing to its relatively high output for its size. The 16-valve configuration allowed for improved breathing and increased power. The engine produced 90 horsepower at 5500 rpm and 125 Nm (92.2 lb-ft) of torque at 4500 rpm. The engine’s compression ratio was 10.3:1. The 1.4L engine was typically paired with a 5-speed manual transmission, but a 4-speed automatic transmission was also available, though less common. The automatic transmission, while offering convenience, did impact acceleration and fuel economy compared to the manual version.
Driving Characteristics
The Fiesta 1.4i 16V with the manual transmission offered a reasonably engaging driving experience. While not a performance car, the engine provided adequate power for everyday driving, with a usable powerband. The automatic transmission, however, dulled the driving experience somewhat. Gear changes were not particularly quick, and the engine often felt strained when accelerating hard. The 0-60 mph time was around 10.3 seconds, and the top speed was approximately 113.71 mph. The Fiesta’s light weight and well-tuned suspension contributed to its nimble handling, making it enjoyable to drive on winding roads. The steering was precise and well-weighted, providing good feedback to the driver.
Equipment & Trim Levels
The 1.4i 16V Fiesta typically came equipped with features such as power steering, central locking, and an adjustable steering column. Higher trim levels offered additional features like electric windows, a sunroof, and alloy wheels. Interior upholstery was typically cloth, with a relatively simple and functional dashboard layout. Optional extras included air conditioning, a radio/cassette player, and upgraded seat fabrics. The 3-door configuration emphasized a slightly sportier aesthetic, appealing to younger buyers or those prioritizing a more compact footprint.
Chassis & Braking
The Fiesta Mk4 utilized a MacPherson strut front suspension and a twist-beam rear suspension. This setup provided a good balance between ride comfort and handling. The front brakes were disc brakes, while the rear brakes were typically disc brakes on higher trim levels, but drum brakes were common on the base and mid-range models. Anti-lock Braking System (ABS) was available as an option, enhancing safety. The Fiesta’s relatively light weight contributed to its good braking performance. The steering was rack and pinion, providing precise and responsive steering feel.
Market Reception & Comparison
The Fiesta 1.4i 16V was generally well-received by automotive critics. It was praised for its practicality, fuel efficiency, and comfortable ride. However, some critics noted that the engine could feel underpowered, especially when fully loaded or driving uphill. Compared to the more powerful Zetec models, the 1.4i 16V offered a more affordable and economical option. The 1.3L models were even more economical but lacked the performance of the 1.4L. In terms of reliability, the Fiesta Mk4 was generally considered to be a reliable car, although some owners reported issues with the cooling system and electrical components.
Legacy
The Ford Fiesta Mk4 1.4i 16V remains a popular choice among classic car enthusiasts and budget-conscious buyers. The engine is known for its durability and relatively simple maintenance requirements. Parts availability is generally good, making it relatively easy to keep these cars on the road. While not a particularly rare or valuable car, well-maintained examples are increasingly sought after by collectors and enthusiasts. The Fiesta Mk4 played a significant role in establishing the Fiesta as one of Europe’s most popular superminis, and the 1.4i 16V variant represents a sweet spot in the lineup, offering a good balance of performance, economy, and practicality.
