The Ford Scorpio II 2.0 i, produced between 1994 and 1998, represented a mid-range offering within the second generation (GFR, GGR) Scorpio lineup. Positioned above the base models and below the more powerful 2.3 and 2.9-liter variants, the 2.0 i aimed to provide a balance of performance and economy for the European market. The Scorpio II, as a whole, was Ford’s flagship executive car, intended to compete with vehicles like the Opel Omega and BMW 5 Series. This particular 2.0-liter iteration offered a more accessible entry point into the Scorpio range, appealing to buyers prioritizing fuel efficiency and a comfortable driving experience over outright speed.
Technical Specifications
| Brand | Ford |
| Model | Scorpio |
| Generation | Scorpio II (GFR,GGR) |
| Type (Engine) | 2.0 i (115 Hp) |
| Start of production | 1994 |
| End of production | 1998 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Fuel consumption (combined) | 8.6 l/100 km (27.4 US mpg, 32.8 UK mpg, 11.6 km/l) |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 193 km/h (119.92 mph) |
| Weight-to-power ratio | 12.5 kg/Hp, 80.3 Hp/tonne |
| Weight-to-torque ratio | 8.6 kg/Nm, 116.5 Nm/tonne |
| Power | 115 Hp @ 5500 rpm |
| Power per litre | 57.6 Hp/l |
| Torque | 167 Nm @ 2500 rpm (123.17 lb.-ft. @ 2500 rpm) |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | NSD |
| Engine displacement | 1998 cm3 (121.93 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86 mm (3.39 in.) |
| Piston Stroke | 86 mm (3.39 in.) |
| Compression ratio | 9.8:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 4.25 l (4.49 US qt | 3.74 UK qt) |
| Coolant | 7.9 l (8.35 US qt | 6.95 UK qt) |
| Kerb Weight | 1433 kg (3159.22 lbs.) |
| Max. weight | 1990 kg (4387.2 lbs.) |
| Max load | 557 kg (1227.97 lbs.) |
| Trunk (boot) space – minimum | 465 l (16.42 cu. ft.) |
| Trunk (boot) space – maximum | 833 l (29.42 cu. ft.) |
| Fuel tank capacity | 70 l (18.49 US gal | 15.4 UK gal) |
| Length | 4825 mm (189.96 in.) |
| Width | 1875 mm (73.82 in.) |
| Height | 1388 mm (54.65 in.) |
| Wheelbase | 2770 mm (109.06 in.) |
| Front track | 1478 mm (58.19 in.) |
| Rear (Back) track | 1495 mm (58.86 in.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Wishbone |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Power steering | Hydraulic Steering |
| Tires size | 195/65 R15 |
Powertrain & Engine Architecture
The heart of the Scorpio II 2.0 i is the Ford NSD engine, a 1.998-liter inline-four cylinder gasoline engine. This engine utilizes a multi-port fuel injection system, delivering fuel directly into the intake ports, optimizing combustion efficiency. The engine features a double overhead camshaft (DOHC) valvetrain, operating four valves per cylinder, which contributes to improved breathing and power output. The NSD engine produces 115 horsepower at 5500 rpm and 167 Nm (123.17 lb-ft) of torque at 2500 rpm. The engine’s longitudinal mounting and rear-wheel drive configuration were characteristic of larger Ford models of the era, providing a more balanced weight distribution. The 2.0 i was exclusively offered with a 5-speed manual transmission, providing drivers with full control over the engine’s power band.
Driving Characteristics
The 2.0 i Scorpio offered a comfortable and refined driving experience, prioritizing ease of use over outright performance. While not as quick as the higher-powered variants, the 2.0-liter engine provided adequate power for everyday driving and highway cruising. The 5-speed manual transmission allowed drivers to keep the engine within its optimal power band, providing reasonable acceleration. The rear-wheel drive layout contributed to balanced handling, although it wasn’t particularly sporty. Compared to the 2.3 and 2.9-liter models, the 2.0 i felt less responsive, particularly during overtaking maneuvers. However, its lighter weight and more efficient engine resulted in improved fuel economy.
Equipment & Trim Levels
The Scorpio II 2.0 i typically came equipped with a respectable level of standard features for its time. These included central locking, electric front windows, power steering, and an anti-lock braking system (ABS). Interior upholstery was typically cloth, with a functional and durable design. Optional extras included air conditioning, a sunroof, and upgraded audio systems. Trim levels varied slightly depending on the market, but generally, the 2.0 i represented a mid-range offering, bridging the gap between the basic models and the more luxurious trims.
Chassis & Braking
The Scorpio II utilized a robust chassis with independent wishbone suspension at the front and a coil spring setup at the rear. This suspension configuration provided a comfortable ride, absorbing bumps and imperfections in the road surface effectively. The braking system consisted of ventilated discs at the front and solid discs at the rear, providing adequate stopping power for the vehicle’s weight. The hydraulic power steering system offered light and precise steering control, enhancing the driving experience.
Market Reception & Comparison
The Scorpio II 2.0 i was generally well-received by automotive critics as a practical and comfortable family car. It was praised for its spacious interior, comfortable ride, and reasonable fuel economy. However, some critics noted that its performance was somewhat underwhelming compared to its rivals. Compared to the 2.3 and 2.9-liter Scorpio variants, the 2.0 i offered better fuel economy but lacked the same level of performance. The 2.0 i was often seen as a sensible choice for buyers prioritizing practicality and affordability over outright driving excitement.
Legacy
The Ford Scorpio II 2.0 i, while not the most iconic version of the Scorpio, remains a relatively reliable and affordable classic car in the used market. The NSD engine is known for its durability, and with proper maintenance, it can provide many years of reliable service. Parts availability can be a challenge, but many components are still available through specialist suppliers. Today, the Scorpio II 2.0 i represents a piece of Ford’s history, offering a glimpse into the era of large, comfortable, and well-equipped family cars. Its blend of practicality, affordability, and reasonable performance continues to appeal to enthusiasts and collectors alike.
