| General information | |
|---|---|
| Brand | Ford |
| Model | Tourneo Custom |
| Generation | Tourneo Custom II L1 |
| Type (Engine) | 2.0 EcoBlue (136 Hp) |
| Start of production | July, 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Van |
| Seats | 8-9 |
| Doors | 4-5 |
| Performance specs | |
| Fuel consumption at Low speed (WLTP) | 9.5-10.4 l/100 km 24.8 – 22.6 US mpg 29.7 – 27.2 UK mpg 10.5 – 9.6 km/l |
| Fuel consumption at Medium speed (WLTP) | 7-7.5 l/100 km 33.6 – 31.4 US mpg 40.4 – 37.7 UK mpg 14.3 – 13.3 km/l |
| Fuel consumption at high speed (WLTP) | 6.2-6.8 l/100 km 37.9 – 34.6 US mpg 45.6 – 41.5 UK mpg 16.1 – 14.7 km/l |
| Fuel consumption at very high speed (WLTP) | 7.7-8.4 l/100 km 30.5 – 28 US mpg 36.7 – 33.6 UK mpg 13 – 11.9 km/l |
| Combined fuel consumption (WLTP) | 7.3-8 l/100 km 32.2 – 29.4 US mpg 38.7 – 35.3 UK mpg 13.7 – 12.5 km/l |
| CO2 emissions (WLTP) | 192-208 g/km |
| Fuel Type | Diesel |
| Emission standard | Euro 6.2 |
| Weight-to-power ratio | 16 kg/Hp, 62.5 Hp/tonne |
| Weight-to-torque ratio | 6 kg/Nm, 165.4 Nm/tonne |
| Engine specs | |
| Power | 136 Hp |
| Power per litre | 68.1 Hp/l |
| Torque | 360 Nm 265.52 lb.-ft. |
| Engine layout | Front, Transverse |
| Engine Model/Code | BJFA |
| Engine displacement | 1996 cm3 121.8 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 84.01 mm 3.31 in. |
| Piston Stroke | 90.03 mm 3.54 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 9.6 l 10.14 US qt | 8.45 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 12.3 l 13 US qt | 10.82 UK qt |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2176-2219 kg 4797.26 – 4892.06 lbs. |
| Max. weight | 3215-3175 kg 7087.86 – 6999.68 lbs. |
| Max load | 956-1039 kg 2107.62 – 2290.6 lbs. |
| Trunk (boot) space – minimum | 672 l 23.73 cu. ft. |
| Trunk (boot) space – maximum | 4683 l 165.38 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| AdBlue tank | 20 l 5.28 US gal | 4.4 UK gal |
| Permitted trailer load with brakes (12%) | 2500 kg 5511.56 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 5050 mm 198.82 in. |
| Width | 2032 mm 80 in. |
| Width with mirrors folded | 2148 mm 84.57 in. |
| Width including mirrors | 2275 mm 89.57 in. |
| Height | 1959-2040 mm 77.13 – 80.31 in. |
| Wheelbase | 3100 mm 122.05 in. |
| Front track | 1730 mm 68.11 in. |
| Rear (Back) track | 1721 mm 67.76 in. |
| Front overhang | 958 mm 37.72 in. |
| Rear overhang | 992 mm 39.06 in. |
| Ride height (ground clearance) | 140 mm 5.51 in. |
| Minimum turning circle (turning diameter) | 11.6 m 38.06 ft. |
| Approach angle | 16.5° |
| Departure angle | 16.4° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent coil spring, Trailing arm |
| Front brakes | Ventilated discs, 308 mm |
| Rear brakes | Ventilated discs, 304 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R16; 215/60 R17 |
| Wheel rims size | 6.5J x 16; 6.5J x 17 |
| What is the body type, Ford Tourneo Custom II L1? | Van, 4-5 Doors, 8-9 Seats |
|---|---|
| What is the fuel economy, Ford Tourneo Custom II L1 2.0 EcoBlue (136 Hp)? | 7.3-8 l/100 km 32.2 – 29.4 US mpg 38.7 – 35.3 UK mpg 13.7 – 12.5 km/l |
| How ECO is the car, Ford Tourneo Custom 2.0 EcoBlue (136 Hp)? | 192-208 g/km CO2 Euro 6.2 |
| How much power, Ford Tourneo Custom Van 2023 2.0 EcoBlue (136 Hp)? | 136 Hp, 360 Nm 265.52 lb.-ft. |
| What is the engine size, Ford Tourneo Custom Van 2023 2.0 EcoBlue (136 Hp)? | 2.0 l 1996 cm3 121.8 cu. in. |
| How many cylinders, 2023 Ford 2.0 EcoBlue (136 Hp)? | 4, Inline |
| What is the drivetrain, Ford Tourneo Custom II L1 Van 2023 2.0 EcoBlue (136 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2023 Ford Tourneo Custom Van? | 5050 mm 198.82 in. |
| How wide is the vehicle, 2023 Ford Tourneo Custom Van? | 2032 mm 80 in. |
| What is the curb weight, 2023 Ford Tourneo Custom II L1 2.0 EcoBlue (136 Hp)? | 2176-2219 kg 4797.26 – 4892.06 lbs. |
| What is the gross weight, 2023 Ford Tourneo Custom II L1 2.0 EcoBlue (136 Hp)? | 3215-3175 kg 7087.86 – 6999.68 lbs. |
| How much trunk (boot) space, 2023 Ford Tourneo Custom Van? | 672 – 4683 l 23.73 – 165.38 cu. ft. |
| How many gears, What type is the gearbox, 2023 Ford Tourneo Custom II L1 2.0 EcoBlue (136 Hp)? | 6, manual transmission |
