| General information | |
|---|---|
| Brand | Ford |
| Model | Tourneo Custom |
| Generation | Tourneo Custom II L2 |
| Type (Engine) | 2.5 Duratec (233 Hp) Plug-in Hybrid CVT |
| Start of production | March, 2024 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Van |
| Seats | 8-9 |
| Doors | 4-5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 1.8-2.9 l/100 km 130.7 – 81.1 US mpg 156.9 – 97.4 UK mpg 55.6 – 34.5 km/l |
| CO2 emissions (WLTP) | 40-65 g/km |
| Fuel Type | Petrol / electricity |
| Emission standard | Euro 6.2 |
| Electric cars and hybrids specs | |
| Gross battery capacity | 16.5 kWh |
| Net (usable) battery capacity | 11.8 kWh |
| Battery technology | Lithium nickel manganese cobalt oxides (Li-NMC) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 40-51 km 24.85 – 31.69 mi |
| Average Energy consumption (WLTP) | 19.9-26.2 kWh/100 km
32.03 – 42.16 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 152 Hp |
| Electric motor Torque | 320 Nm
236.02 lb.-ft. |
| Electric motor location | Integrated into the transmission |
| Electric motor type | Synchronous |
| System power | 233 Hp |
| Internal combustion engine specs | |
| Power | 118 Hp |
| Power per litre | 47.4 Hp/l |
| Torque | 205 Nm 151.2 lb.-ft. |
| Engine layout | Front, Transverse |
| Engine Model/Code | BGFA |
| Engine displacement | 2488 cm3 151.83 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 89 mm 3.5 in. |
| Piston Stroke | 100 mm 3.94 in. |
| Compression ratio | 13:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, VCT |
|
|
|
| Space, Volume and weights | |
| Trunk (boot) space – minimum | 819 l 28.92 cu. ft. |
| Trunk (boot) space – maximum | 5472 l 193.24 cu. ft. |
| Fuel tank capacity | 63 l 16.64 US gal | 13.86 UK gal |
| Permitted trailer load with brakes (12%) | 1850 kg 4078.55 lbs. |
| Dimensions | |
| Length | 5450 mm 214.57 in. |
| Width | 2032 mm 80 in. |
| Width with mirrors folded | 2148 mm 84.57 in. |
| Width including mirrors | 2275 mm 89.57 in. |
| Height | 1963-2031 mm 77.28 – 79.96 in. |
| Wheelbase | 3500 mm 137.8 in. |
| Front track | 1730 mm 68.11 in. |
| Rear (Back) track | 1721 mm 67.76 in. |
| Front overhang | 958 mm 37.72 in. |
| Rear overhang | 992 mm 39.06 in. |
| Ride height (ground clearance) | 140 mm 5.51 in. |
| Minimum turning circle (turning diameter) | 12.8-13.6 m 41.99 – 44.62 ft. |
| Approach angle | 17.2° |
| Departure angle | 16.4° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | automatic transmission CVT |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent coil spring, Trailing arm |
| Front brakes | Ventilated discs, 308 mm |
| Rear brakes | Ventilated discs, 304 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R16; 215/60 R17; 235/50 R19 |
| Wheel rims size | 6.5J x 16; 6.5J x 17; 7.5J x 19 |
| What is the body type, Ford Tourneo Custom II L2? | Van, 4-5 Doors, 8-9 Seats |
|---|---|
| What is the fuel economy, Ford Tourneo Custom II L2 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | 1.8-2.9 l/100 km 130.7 – 81.1 US mpg 156.9 – 97.4 UK mpg 55.6 – 34.5 km/l |
| How ECO is the car, Ford Tourneo Custom 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | 40-65 g/km CO2 Euro 6.2 |
| What is the range of pure electric driving, 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | 40-51 km 24.85 – 31.69 mi |
| What is electricity consumption, Ford Tourneo Custom II L2 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | 19.9-26.2 kWh/100 km 32.03 – 42.16 kWh/100 mi 105 – 80 MPGe 5 – 3.8 km/kWh 3.1 – 2.4 mi/kWh |
| How much power, Ford Tourneo Custom Van 2024 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | 233 Hp, 205 Nm 151.2 lb.-ft. |
| What is the engine size, Ford Tourneo Custom Van 2024 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | 2.5 l 2488 cm3 151.83 cu. in. |
| How many cylinders, 2024 Ford 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | 4, Inline |
| What is the drivetrain, Ford Tourneo Custom II L2 Van 2024 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2024 Ford Tourneo Custom Van? | 5450 mm 214.57 in. |
| How wide is the vehicle, 2024 Ford Tourneo Custom Van? | 2032 mm 80 in. |
| How much trunk (boot) space, 2024 Ford Tourneo Custom Van? | 819 – 5472 l 28.92 – 193.24 cu. ft. |
| How many gears, What type is the gearbox, 2024 Ford Tourneo Custom II L2 2.5 Duratec (233 Hp) Plug-in Hybrid CVT? | automatic transmission CVT |
