| General information | |
|---|---|
| Brand | Ford |
| Model | Transit Connect |
| Generation | Transit Connect III Panel Van L2 |
| Type (Engine) | 2.0 EcoBlue (102 Hp) |
| Start of production | 2024 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 2 |
| Doors | 4-5 |
| Performance specs | |
| Fuel consumption at Low speed (WLTP) | 7 l/100 km 33.6 US mpg 40.4 UK mpg 14.3 km/l |
| Fuel consumption at Medium speed (WLTP) | 5.1 l/100 km 46.1 US mpg 55.4 UK mpg 19.6 km/l |
| Fuel consumption at high speed (WLTP) | 4.7 l/100 km 50 US mpg 60.1 UK mpg 21.3 km/l |
| Fuel consumption at very high speed (WLTP) | 5.9 l/100 km 39.9 US mpg 47.9 UK mpg 16.9 km/l |
| Combined fuel consumption (WLTP) | 5.5 l/100 km 42.8 US mpg 51.4 UK mpg 18.2 km/l |
| CO2 emissions (WLTP) | 144-145 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 14 sec |
| Acceleration 0 – 62 mph | 14 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 13.3 sec |
| Maximum speed | 173 km/h 107.5 mph |
| Emission standard | Euro 6e |
| Weight-to-power ratio | 14.9 kg/Hp, 67 Hp/tonne |
| Weight-to-torque ratio | 5.4 kg/Nm, 184 Nm/tonne |
| Engine specs | |
| Power | 102 Hp |
| Power per litre | 51.8 Hp/l |
| Torque | 280 Nm 206.52 lb.-ft. |
| Engine layout | Front, Transverse |
| Engine Model/Code | EA288 evo |
| Engine displacement | 1968 cm3 120.09 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.5 l 5.81 US qt | 4.84 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1522-1541 kg 3355.44 – 3397.32 lbs. |
| Max. weight | 2300 kg 5070.63 lbs. |
| Max load | 759-778 kg 1673.31 – 1715.2 lbs. |
| Trunk (boot) space – maximum | 3700 l 130.66 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| AdBlue tank | 15 l 3.96 US gal | 3.3 UK gal |
| Permitted trailer load with brakes (12%) | 1500 kg 3306.93 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4853 mm 191.06 in. |
| Width | 1855 mm 73.03 in. |
| Width with mirrors folded | 1931 mm 76.02 in. |
| Width including mirrors | 2100 mm 82.68 in. |
| Height | 1860 mm 73.23 in. |
| Wheelbase | 2970 mm 116.93 in. |
| Front track | 1565-1572 mm 61.61 – 61.89 in. |
| Rear (Back) track | 1603-1606 mm 63.11 – 63.23 in. |
| Front overhang | 890 mm 35.04 in. |
| Rear overhang | 993 mm 39.09 in. |
| Ride height (ground clearance) | 159 mm 6.26 in. |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Approach angle | 14.6° |
| Departure angle | 15.9° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Rigid axle suspension, Trailing arm, Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/55 R17 |
| Wheel rims size | 6.5J x 17; 7J x 17 |
| What is the body type, Ford Transit Connect III Panel Van L2? | Minivan, 4-5 Doors, 2 Seats |
|---|---|
| What is the fuel economy, Ford Transit Connect III Panel Van L2 2.0 EcoBlue (102 Hp)? | 5.5 l/100 km 42.8 US mpg 51.4 UK mpg 18.2 km/l |
| How ECO is the car, Ford Transit Connect 2.0 EcoBlue (102 Hp)? | 144-145 g/km CO2 Euro 6e |
| How fast is the car, 2024 Transit Connect III Panel Van L2 2.0 EcoBlue (102 Hp)? | 173 km/h | 107.5 mph 0-100 km/h: 14 sec 0-60 mph: 13.3 sec |
| How much power, Ford Transit Connect Minivan 2024 2.0 EcoBlue (102 Hp)? | 102 Hp, 280 Nm 206.52 lb.-ft. |
| What is the engine size, Ford Transit Connect Minivan 2024 2.0 EcoBlue (102 Hp)? | 2.0 l 1968 cm3 120.09 cu. in. |
| How many cylinders, 2024 Ford 2.0 EcoBlue (102 Hp)? | 4, Inline |
| What is the drivetrain, Ford Transit Connect III Panel Van L2 Minivan 2024 2.0 EcoBlue (102 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2024 Ford Transit Connect Minivan? | 4853 mm 191.06 in. |
| How wide is the vehicle, 2024 Ford Transit Connect Minivan? | 1855 mm 73.03 in. |
| What is the curb weight, 2024 Ford Transit Connect III Panel Van L2 2.0 EcoBlue (102 Hp)? | 1522-1541 kg 3355.44 – 3397.32 lbs. |
| What is the gross weight, 2024 Ford Transit Connect III Panel Van L2 2.0 EcoBlue (102 Hp)? | 2300 kg 5070.63 lbs. |
| How much trunk (boot) space, 2024 Ford Transit Connect Minivan? | 3700 l 130.66 cu. ft. |
| How many gears, What type is the gearbox, 2024 Ford Transit Connect III Panel Van L2 2.0 EcoBlue (102 Hp)? | 6, manual transmission |
