| General information | |
|---|---|
| Brand | Forthing |
| Model | T5 EVO |
| Generation | T5 EVO |
| Type (Engine) | 1.5 TD (197 Hp) DCT |
| Start of production | November, 2020 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 6.8-7.37 l/100 km 34.6 – 31.9 US mpg 41.5 – 38.3 UK mpg 14.7 – 13.6 km/l |
| Fuel consumption (economy) – urban | 8.9 l/100 km 26.4 US mpg 31.7 UK mpg 11.2 km/l |
| Fuel consumption (economy) – extra urban | 5.7 l/100 km 41.3 US mpg 49.6 UK mpg 17.5 km/l |
| Fuel consumption (economy) – combined | 6.6 l/100 km 35.6 US mpg 42.8 UK mpg 15.2 km/l |
| CO2 emissions | 174 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 9.5 sec |
| Acceleration 0 – 62 mph | 9.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9 sec |
| Maximum speed | 195 km/h 121.17 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 7.6 kg/Hp, 131.3 Hp/tonne |
| Weight-to-torque ratio | 5.3 kg/Nm, 190 Nm/tonne |
| Engine specs | |
| Power | 197 Hp @ 5600 rpm. |
| Power per litre | 133 Hp/l |
| Torque | 285 Nm @ 1500-4000 rpm. 210.21 lb.-ft. @ 1500-4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | 4A95TD |
| Engine displacement | 1481 cm3 90.38 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 74 mm 2.91 in. |
| Piston Stroke | 86 mm 3.39 in. |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC, DVVT |
| Engine oil capacity | 3.5 l 3.7 US qt | 3.08 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8.5 l 8.98 US qt | 7.48 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1500-1550 kg 3306.93 – 3417.17 lbs. |
| Max. weight | 1875-1925 kg 4133.67 – 4243.9 lbs. |
| Max load | 375 kg 826.73 lbs. |
| Trunk (boot) space – minimum | 480 l 16.95 cu. ft. |
| Trunk (boot) space – maximum | 1480 l 52.27 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Permitted trailer load with brakes (12%) | 1800 kg 3968.32 lbs. |
| Dimensions | |
| Length | 4565 mm 179.72 in. |
| Width | 1860 mm 73.23 in. |
| Height | 1690 mm 66.54 in. |
| Wheelbase | 2715 mm 106.89 in. |
| Front track | 1590 mm 62.6 in. |
| Rear (Back) track | 1595 mm 62.8 in. |
| Front overhang | 990 mm 38.98 in. |
| Rear overhang | 860 mm 33.86 in. |
| Ride height (ground clearance) | 165 mm 6.5 in. |
| Minimum turning circle (turning diameter) | 11.8 m 38.71 ft. |
| Approach angle | 17° |
| Departure angle | 26° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission DCT |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link suspension, Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/60 R18; 235/55 R19 |
| Wheel rims size | 6.5J x 18; 7J x 19 |
| What is the body type, Forthing T5 EVO? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Forthing T5 EVO 1.5 TD (197 Hp) DCT? | 6.8-7.37 l/100 km 34.6 – 31.9 US mpg 41.5 – 38.3 UK mpg 14.7 – 13.6 km/l |
| How ECO is the car, Forthing T5 EVO 1.5 TD (197 Hp) DCT? | 174 g/km CO2 Euro 6 |
| How fast is the car, 2020 T5 EVO 1.5 TD (197 Hp) DCT? | 195 km/h | 121.17 mph 0-100 km/h: 9.5 sec 0-60 mph: 9 sec |
| How much power, Forthing T5 EVO SUV 2020 1.5 TD (197 Hp) DCT? | 197 Hp, 285 Nm 210.21 lb.-ft. |
| What is the engine size, Forthing T5 EVO SUV 2020 1.5 TD (197 Hp) DCT? | 1.5 l 1481 cm3 90.38 cu. in. |
| How many cylinders, 2020 Forthing 1.5 TD (197 Hp) DCT? | 4, Inline |
| What is the drivetrain, Forthing T5 EVO SUV 2020 1.5 TD (197 Hp) DCT? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2020 Forthing T5 EVO SUV? | 4565 mm 179.72 in. |
| How wide is the vehicle, 2020 Forthing T5 EVO SUV? | 1860 mm 73.23 in. |
| What is the curb weight, 2020 Forthing T5 EVO 1.5 TD (197 Hp) DCT? | 1500-1550 kg 3306.93 – 3417.17 lbs. |
| What is the gross weight, 2020 Forthing T5 EVO 1.5 TD (197 Hp) DCT? | 1875-1925 kg 4133.67 – 4243.9 lbs. |
| How much trunk (boot) space, 2020 Forthing T5 EVO SUV? | 480 – 1480 l 16.95 – 52.27 cu. ft. |
| How many gears, What type is the gearbox, 2020 Forthing T5 EVO 1.5 TD (197 Hp) DCT? | 7, automatic transmission DCT |
