The Geely Azkarra 1.5TD (190 Hp) EMS 4WD DCT is a compact SUV produced by the Chinese automaker Geely, entering production in July 2019. Positioned as a mid-range offering within the Azkarra lineup, this variant combines a turbocharged 1.5-liter three-cylinder engine with a 48-volt mild hybrid system and a seven-speed dual-clutch transmission (DCT), coupled with an all-wheel-drive (AWD) system. The Azkarra represents Geely’s ambition to move upmarket, offering a more sophisticated and technologically advanced vehicle compared to its earlier offerings, primarily targeted towards the growing SUV market in China and select export markets.
Technical Specifications
| Brand | Geely |
| Model | Azkarra |
| Type | 1.5TD (190 Hp) EMS 4WD DCT |
| Start of production | July, 2019 |
| Powertrain Architecture | MHEV (Mild Hybrid Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 9 kg/Hp |
| Weight-to-torque ratio | 5.7 kg/Nm |
| Battery voltage | 48 V |
| Battery location | Under the trunk |
| Electric motor power | 14 Hp |
| Electric motor Torque | 50 Nm (36.88 lb.-ft.) |
| Electric motor location | Front, Transverse |
| Power | 190 Hp @ 5500 rpm |
| Torque | 300 Nm @ 1500-4000 rpm (221.27 lb.-ft. @ 1500-4000 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | 3G15TDB |
| Engine displacement | 1477 cm3 (90.13 cu. in.) |
| Number of cylinders | 3 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Kerb Weight | 1705 kg (3758.88 lbs.) |
| Fuel tank capacity | 58 l (15.32 US gal | 12.76 UK gal) |
| Length | 4544 mm (178.9 in.) |
| Width | 1831 mm (72.09 in.) |
| Height | 1713 mm (67.44 in.) |
| Wheelbase | 2670 mm (105.12 in.) |
| Ride height (ground clearance) | 163 mm (6.42 in.) |
| Drivetrain Architecture | ICE and electric motor drive front wheels, rear drive via clutch |
| Drive wheel | All wheel drive (4×4) |
| Number of gears | 7 |
| Gearbox type | Automatic transmission DCT |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/60 R18 |
| Wheel rims size | 18 |
Powertrain & Engine Architecture
The heart of the Azkarra 1.5TD is the 3G15TDB engine, a 1.5-liter inline three-cylinder gasoline engine. This engine utilizes direct fuel injection and is coupled with a turbocharger and intercooler to boost power output. The engine’s relatively small displacement is compensated for by the turbocharging, allowing it to produce 190 horsepower at 5500 rpm and 300 Nm (221 lb-ft) of torque between 1500 and 4000 rpm. What sets this variant apart is its 48-volt mild hybrid electric vehicle (MHEV) system. This system incorporates a 48V battery located under the trunk floor and a small electric motor producing 14 hp and 50 Nm of torque. The electric motor provides assistance during acceleration and allows for a start/stop system to improve fuel efficiency. The seven-speed dual-clutch transmission (DCT) provides quick and smooth gear changes, contributing to a more engaging driving experience. The DCT is known for its efficiency and responsiveness compared to traditional automatic transmissions.
Driving Characteristics
The Geely Azkarra 1.5TD offers a balanced driving experience. The combination of the turbocharged engine and the electric motor provides adequate acceleration for everyday driving situations. While not a performance-oriented vehicle, the 190 hp output and the DCT transmission allow for brisk acceleration. The all-wheel-drive system enhances traction, particularly in adverse weather conditions. The DCT transmission’s gear ratios are tuned for a balance between fuel efficiency and performance. Compared to potential lower-powered versions of the Azkarra, this 1.5TD variant delivers a noticeably more responsive and confident driving experience. The mild hybrid system contributes to smoother starts and improved fuel economy, especially in city driving.
Equipment & Trim Levels
The 1.5TD EMS 4WD DCT trim typically includes a comprehensive suite of standard features. These often include automatic climate control, a touchscreen infotainment system with smartphone connectivity (Apple CarPlay and Android Auto), a rearview camera, and various safety features such as ABS, electronic stability control, and multiple airbags. Interior upholstery is generally a combination of fabric and leatherette, with higher trims offering full leather seats. Optional extras could include a panoramic sunroof, upgraded audio system, and advanced driver-assistance systems (ADAS) like adaptive cruise control and lane departure warning.
Chassis & Braking
The Azkarra utilizes an independent McPherson strut suspension setup at the front and an independent multi-link suspension at the rear, providing a comfortable ride quality and good handling characteristics. The chassis is designed to balance ride comfort with stability. The braking system consists of ventilated discs at the front and solid discs at the rear, providing adequate stopping power for the vehicle’s weight. The inclusion of ABS (Anti-lock Braking System) enhances safety by preventing wheel lockup during hard braking.
Market Reception & Comparison
The Geely Azkarra 1.5TD received generally positive reviews in markets where it was launched. Critics praised its modern design, spacious interior, and comprehensive feature list. The 1.5TD engine was considered a good compromise between performance and fuel efficiency. Compared to other trims in the Azkarra lineup, the 1.5TD offered a more refined driving experience and better performance than lower-powered options. Fuel economy figures were competitive within the compact SUV segment. Reliability reports have been mixed, with some owners reporting minor issues with the infotainment system and occasional electronic glitches, but overall, the Azkarra has proven to be a relatively reliable vehicle.
Legacy
The Geely Azkarra 1.5TD represents a significant step forward for Geely in terms of design, technology, and overall quality. The 3G15TDB engine, while not without its quirks, has proven to be a reasonably durable powertrain. In the used car market, the Azkarra 1.5TD holds its value relatively well, particularly models with lower mileage and a full service history. The mild hybrid system adds a degree of future-proofing, as demand for more fuel-efficient vehicles continues to grow. The Azkarra’s success has helped to establish Geely as a credible player in the global automotive market.
