| General information | |
|---|---|
| Brand | GMC |
| Model | Sierra 2500HD |
| Generation | Sierra 2500HD IV (GMTK2XX) Double Cab Standard Box |
| Type (Engine) | 6.0 V8 (301 Hp) Automatic CNG |
| Start of production | 2015 year |
| End of production | 2016 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Petrol / CNG |
| Engine specs | |
| Power | 301 Hp @ 5000 rpm. |
| Power per litre | 50.4 Hp/l |
| Torque | 452 Nm @ 4200 rpm. 333.38 lb.-ft. @ 4200 rpm. |
| Maximum engine speed | 6000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | Vortec LC8 |
| Engine displacement | 5967 cm3 364.13 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Cylinder Bore | 101.6 mm 4 in. |
| Piston Stroke | 92 mm 3.62 in. |
| Compression ratio | 9.6:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | OHV, VVT |
| Engine oil capacity | 5.7 l 6.02 US qt | 5.02 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 15.5 l 16.38 US qt | 13.64 UK qt |
|
|
|
| Space, Volume and weights | |
| Fuel tank capacity | 136 l 35.93 US gal | 29.92 UK gal |
| CNG cylinder capacity | 67 kg |
| Permitted trailer load with brakes (12%) | 4218 kg 9299.1 lbs. |
| Dimensions | |
| Length | 5842 mm 230 in. |
| Width including mirrors | 2045 mm 80.51 in. |
| Height | 1984 mm 78.11 in. |
| Wheelbase | 3662 mm 144.17 in. |
| Front track | 1748 mm 68.82 in. |
| Rear (Back) track | 1709 mm 67.28 in. |
| Ride height (ground clearance) | 218 mm 8.58 in. |
| Minimum turning circle (turning diameter) | 15 m 49.21 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission Hydra-Matic |
| Front suspension | Coil spring, Double wishbone, Transverse stabilizer |
| Rear suspension | Rigid axle suspension, Leaf spring |
| Front brakes | Ventilated discs, 350×40 mm |
| Rear brakes | Ventilated discs, 360×34 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
| Tires size | 245/75 R17; 265/70 R17; 265/70 R18; 265/60 R20 |
| Wheel rims size | 7.5J x 17; 8J x 18; 8.5J x 20 |
| What is the body type, GMC Sierra 2500HD IV (GMTK2XX) Double Cab Standard Box? | Pick-up, 4 Doors, 5 Seats |
|---|---|
| How much power, GMC Sierra 2500HD Pick-up 2015 6.0 V8 (301 Hp) Automatic CNG? | 301 Hp, 452 Nm 333.38 lb.-ft. |
| What is the engine size, GMC Sierra 2500HD Pick-up 2015 6.0 V8 (301 Hp) Automatic CNG? | 6.0 l 5967 cm3 364.13 cu. in. |
| How many cylinders, 2015 GMC 6.0 V8 (301 Hp) Automatic CNG? | 8, V-engine |
| What is the drivetrain, GMC Sierra 2500HD IV (GMTK2XX) Double Cab Standard Box Pick-up 2015 6.0 V8 (301 Hp) Automatic CNG? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2015 GMC Sierra 2500HD Pick-up? | 5842 mm 230 in. |
| How wide is the vehicle, 2015 GMC Sierra 2500HD Pick-up? | 2045 mm 80.51 in. |
| How many gears, What type is the gearbox, 2015 GMC Sierra 2500HD IV (GMTK2XX) Double Cab Standard Box 6.0 V8 (301 Hp) Automatic CNG? | 6, automatic transmission Hydra-Matic |
