| General information | |
|---|---|
| Brand | Haval |
| Model | H9 |
| Generation | H9 II |
| Type (Engine) | 2.4d (184 Hp) 4WD Automatic |
| Start of production | December, 2024 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Off-road vehicle, SUV |
| Seats | 5-7 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Diesel |
| Emission standard | China VI |
| Engine specs | |
| Power | 184 Hp @ 3600 rpm. |
| Power per litre | 77.6 Hp/l |
| Torque | 480 Nm @ 1500-2500 rpm. 354.03 lb.-ft. @ 1500-2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | GW4D24 |
| Engine displacement | 2370 cm3 144.63 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Fuel tank capacity | 78 l 20.61 US gal | 17.16 UK gal |
| Dimensions | |
| Length | 5070 mm 199.61 in. |
| Width | 1976 mm 77.8 in. |
| Height | 1930 mm 75.98 in. |
| Wheelbase | 2850 mm 112.2 in. |
| Front track | 1635 mm 64.37 in. |
| Rear (Back) track | 1635 mm 64.37 in. |
| Ride height (ground clearance) | 224 mm 8.82 in. |
| Approach angle | 31° |
| Departure angle | 26° |
| Wading depth | 800 mm 31.5 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 265/60 R18 |
| Wheel rims size | 18 |
| What is the body type, Haval H9 II? | Off-road vehicle, SUV, 5 Doors, 5-7 Seats |
|---|---|
| How ECO is the car, Haval H9 2.4d (184 Hp) 4WD Automatic? | China VI |
| How much power, Haval H9 Off-road vehicle, SUV 2024 2.4d (184 Hp) 4WD Automatic? | 184 Hp, 480 Nm 354.03 lb.-ft. |
| What is the engine size, Haval H9 Off-road vehicle, SUV 2024 2.4d (184 Hp) 4WD Automatic? | 2.4 l 2370 cm3 144.63 cu. in. |
| How many cylinders, 2024 Haval 2.4d (184 Hp) 4WD Automatic? | 4, Inline |
| What is the drivetrain, Haval H9 II Off-road vehicle, SUV 2024 2.4d (184 Hp) 4WD Automatic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2024 Haval H9 Off-road vehicle, SUV? | 5070 mm 199.61 in. |
| How wide is the vehicle, 2024 Haval H9 Off-road vehicle, SUV? | 1976 mm 77.8 in. |
| How many gears, What type is the gearbox, 2024 Haval H9 II 2.4d (184 Hp) 4WD Automatic? | 9, automatic transmission |
