| General information | |
|---|---|
| Brand | Haval |
| Model | Jolion |
| Generation | Jolion |
| Type (Engine) | 1.5T (150 Hp) DCT |
| Start of production | December, 2020 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – combined | 8.1 l/100 km 29 US mpg 34.9 UK mpg 12.3 km/l |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 9.1 kg/Hp, 109.5 Hp/tonne |
| Weight-to-torque ratio | 6.2 kg/Nm, 160.6 Nm/tonne |
| Engine specs | |
| Power | 150 Hp @ 5600-6000 rpm. |
| Power per litre | 100.2 Hp/l |
| Torque | 220 Nm @ 2000-4400 rpm. 162.26 lb.-ft. @ 2000-4400 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | GW4G15K |
| Engine displacement | 1497 cm3 91.35 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm 2.95 in. |
| Piston Stroke | 84.7 mm 3.33 in. |
| Compression ratio | 9.3:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 3.8 l 4.02 US qt | 3.34 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.7 l 7.08 US qt | 5.9 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1370-1431 kg 3020.33 – 3154.81 lbs. |
| Max. weight | 2075 kg 4574.59 lbs. |
| Max load | 644-705 kg 1419.78 – 1554.26 lbs. |
| Trunk (boot) space – minimum | 430 l 15.19 cu. ft. |
| Trunk (boot) space – maximum | 1133 l 40.01 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Permitted trailer load with brakes (12%) | 1500 kg 3306.93 lbs. |
| Permitted trailer load without brakes | 710 kg 1565.28 lbs. |
| Dimensions | |
| Length | 4472 mm 176.06 in. |
| Width | 1841 mm 72.48 in. |
| Height | 1574 mm 61.97 in. |
| Wheelbase | 2700 mm 106.3 in. |
| Minimum turning circle (turning diameter) | 11.5 m 37.73 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission DCT |
| Front suspension | Independent type McPherson |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/60 R17 96H; 225/55 R18 98V |
| Wheel rims size | 6.5J x 17 ET37; 7J x 18 ET37 |
| What is the body type, Haval Jolion? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Haval Jolion 1.5T (150 Hp) DCT? | 8.1 l/100 km 29 US mpg 34.9 UK mpg 12.3 km/l |
| How much power, Haval Jolion SUV 2020 1.5T (150 Hp) DCT? | 150 Hp, 220 Nm 162.26 lb.-ft. |
| What is the engine size, Haval Jolion SUV 2020 1.5T (150 Hp) DCT? | 1.5 l 1497 cm3 91.35 cu. in. |
| How many cylinders, 2020 Haval 1.5T (150 Hp) DCT? | 4, Inline |
| What is the drivetrain, Haval Jolion SUV 2020 1.5T (150 Hp) DCT? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2020 Haval Jolion SUV? | 4472 mm 176.06 in. |
| How wide is the vehicle, 2020 Haval Jolion SUV? | 1841 mm 72.48 in. |
| What is the curb weight, 2020 Haval Jolion 1.5T (150 Hp) DCT? | 1370-1431 kg 3020.33 – 3154.81 lbs. |
| What is the gross weight, 2020 Haval Jolion 1.5T (150 Hp) DCT? | 2075 kg 4574.59 lbs. |
| How much trunk (boot) space, 2020 Haval Jolion SUV? | 430 – 1133 l 15.19 – 40.01 cu. ft. |
| How many gears, What type is the gearbox, 2020 Haval Jolion 1.5T (150 Hp) DCT? | 7, automatic transmission DCT |
