| General information | |
|---|---|
| Brand | Honda |
| Model | Civic |
| Generation | Civic IX Tourer (facelift 2014) |
| Type (Engine) | 1.6 i-DTEC (120 Hp) |
| Start of production | 2014 year |
| End of production | 2017 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 4.2 l/100 km 56 US mpg 67.3 UK mpg 23.8 km/l |
| Fuel consumption (economy) – extra urban | 3.6 l/100 km 65.3 US mpg 78.5 UK mpg 27.8 km/l |
| Fuel consumption (economy) – combined | 3.8 l/100 km 61.9 US mpg 74.3 UK mpg 26.3 km/l |
| CO2 emissions | 99 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 10.3 sec |
| Acceleration 0 – 62 mph | 10.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.8 sec |
| Maximum speed | 195 km/h 121.17 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 11.8 kg/Hp, 85 Hp/tonne |
| Weight-to-torque ratio | 4.7 kg/Nm, 212.5 Nm/tonne |
| Engine specs | |
| Power | 120 Hp @ 4000 rpm. |
| Power per litre | 75.1 Hp/l |
| Torque | 300 Nm @ 2000 rpm. 221.27 lb.-ft. @ 2000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | N16A1 |
| Engine displacement | 1597 cm3 97.45 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 76 mm 2.99 in. |
| Piston Stroke | 88 mm 3.46 in. |
| Compression ratio | 16:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.7 l 4.97 US qt | 4.14 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 5.66 l 5.98 US qt | 4.98 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1412 kg 3112.93 lbs. |
| Max. weight | 1910 kg 4210.83 lbs. |
| Max load | 498 kg 1097.9 lbs. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| Permitted trailer load with brakes (12%) | 1400 kg 3086.47 lbs. |
| Permitted trailer load without brakes | 500 kg 1102.31 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4590 mm 180.71 in. |
| Width | 1770 mm 69.69 in. |
| Width including mirrors | 2065 mm 81.3 in. |
| Wheelbase | 2595 mm 102.17 in. |
| Front track | 1530 mm 60.24 in. |
| Rear (Back) track | 1530 mm 60.24 in. |
| Ride height (ground clearance) | 145 mm 5.71 in. |
| Minimum turning circle (turning diameter) | 11.28 m 37.01 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Semi-independent, coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 205/55 R16 91V |
| Wheel rims size | 6.5J x 16 |
| What is the body type, Honda Civic IX Tourer (facelift 2014)? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Honda Civic IX Tourer (facelift 2014) 1.6 i-DTEC (120 Hp)? | 3.8 l/100 km 61.9 US mpg 74.3 UK mpg 26.3 km/l |
| How ECO is the car, Honda Civic 1.6 i-DTEC (120 Hp)? | 99 g/km CO2 Euro 5 |
| How fast is the car, 2014 Civic IX Tourer (facelift 2014) 1.6 i-DTEC (120 Hp)? | 195 km/h | 121.17 mph 0-100 km/h: 10.3 sec 0-60 mph: 9.8 sec |
| How much power, Honda Civic Station wagon (estate) 2014 1.6 i-DTEC (120 Hp)? | 120 Hp, 300 Nm 221.27 lb.-ft. |
| What is the engine size, Honda Civic Station wagon (estate) 2014 1.6 i-DTEC (120 Hp)? | 1.6 l 1597 cm3 97.45 cu. in. |
| How many cylinders, 2014 Honda 1.6 i-DTEC (120 Hp)? | 4, Inline |
| What is the drivetrain, Honda Civic IX Tourer (facelift 2014) Station wagon (estate) 2014 1.6 i-DTEC (120 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2014 Honda Civic Station wagon (estate)? | 4590 mm 180.71 in. |
| How wide is the vehicle, 2014 Honda Civic Station wagon (estate)? | 1770 mm 69.69 in. |
| What is the curb weight, 2014 Honda Civic IX Tourer (facelift 2014) 1.6 i-DTEC (120 Hp)? | 1412 kg 3112.93 lbs. |
| What is the gross weight, 2014 Honda Civic IX Tourer (facelift 2014) 1.6 i-DTEC (120 Hp)? | 1910 kg 4210.83 lbs. |
| How many gears, What type is the gearbox, 2014 Honda Civic IX Tourer (facelift 2014) 1.6 i-DTEC (120 Hp)? | 6, manual transmission |
