The Honda Integra Type R, specifically the DC2 chassis produced from 1994 to 2001, represents a high point in Japanese front-wheel-drive performance. Within the DC2 generation, the 1.6 ZXi variant, producing 120 horsepower, served as a key entry point into the Integra lineup, offering a balance of affordability, practicality, and Honda’s renowned reliability. This model occupied a middle ground, positioned below the more potent Si and Type R trims, but above the base models, appealing to a broader customer base seeking a sporty and efficient compact liftback.
Technical Specifications
| Brand | Honda |
| Model | Integra |
| Generation | Integra III (DC2) |
| Type (Engine) | 1.6 ZXi (120 Hp) |
| Start of production | 1994 |
| End of production | 2001 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Liftback |
| Seats | 4 |
| Doors | 2 |
| Fuel consumption (combined) | 5.5 l/100 km (42.8 US mpg, 51.4 UK mpg, 18.2 km/l) |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 175 km/h (108.74 mph) |
| Weight-to-power ratio | 8.8 kg/Hp, 114.3 Hp/tonne |
| Weight-to-torque ratio | 7.4 kg/Nm, 135.2 Nm/tonne |
| Power | 120 Hp @ 6300 rpm |
| Power per litre | 75.5 Hp/l |
| Torque | 142 Nm @ 5500 rpm (104.73 lb.-ft. @ 5500 rpm) |
| Engine layout | Front, Transverse |
| Engine displacement | 1590 cm3 (97.03 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75 mm (2.95 in.) |
| Piston Stroke | 90 mm (3.54 in.) |
| Compression ratio | 9.1:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | OHC |
| Kerb Weight | 1050 kg (2314.85 lbs.) |
| Fuel tank capacity | 50 l (13.21 US gal | 11 UK gal) |
| Length | 4380 mm (172.44 in.) |
| Width | 1695 mm (66.73 in.) |
| Height | 1335 mm (52.56 in.) |
| Wheelbase | 2570 mm (101.18 in.) |
| Front track | 1475 mm (58.07 in.) |
| Rear track | 1465 mm (57.68 in.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Coil spring |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 185/65 R14 |
| Wheel rims size | 14 |
Powertrain & Engine Architecture
The 1.6 ZXi Integra utilized Honda’s SOHC 16-valve inline-four cylinder engine, designated as the D16Z6. This engine, displacing 1590cc, featured multi-point fuel injection and a compression ratio of 9.1:1. While not as technologically advanced as the VTEC-equipped engines found in the Si and Type R models, the D16Z6 was known for its durability and smooth power delivery. The engine produced 120 horsepower at 6300 rpm and 104.73 lb-ft of torque at 5500 rpm. The engine’s design prioritized fuel efficiency and reliability over outright performance. The transmission was a standard 5-speed manual, contributing to the car’s engaging driving experience.
Driving Characteristics
The 1.6 ZXi offered a comfortable and predictable driving experience. While lacking the razor-sharp handling and explosive acceleration of the higher-spec models, it provided ample power for everyday driving and spirited backroad excursions. The 5-speed manual transmission offered precise shifts, and the relatively light weight of the vehicle (around 2315 lbs) contributed to its nimble feel. Compared to the Si, the ZXi’s power delivery was less aggressive, making it more accessible to less experienced drivers. The gear ratios were tuned for fuel economy and everyday usability, rather than maximizing performance.
Equipment & Trim Levels
The 1.6 ZXi trim level typically included features such as power windows, power locks, and an AM/FM stereo. Interior upholstery was typically cloth, and the dashboard featured a straightforward layout with easy-to-read gauges. Optional extras included air conditioning, a sunroof, and upgraded audio systems. The ZXi was positioned as a well-equipped, yet affordable, option within the Integra range, offering a good balance of features and value.
Chassis & Braking
The DC2 Integra utilized a MacPherson strut front suspension and a double-wishbone rear suspension, providing a comfortable ride and predictable handling. The 1.6 ZXi models were equipped with ventilated disc brakes in the front and drum brakes in the rear. Anti-lock braking system (ABS) was standard, enhancing safety. The suspension tuning was softer than that of the Si and Type R models, prioritizing ride comfort over ultimate handling performance. The relatively narrow 185/65 R14 tires contributed to a comfortable ride but limited grip compared to the wider tires found on the higher-spec models.
Market Reception & Comparison
The 1.6 ZXi Integra was well-received by critics as a practical and reliable compact car. It was praised for its fuel efficiency, comfortable ride, and Honda’s reputation for quality. However, it was often criticized for its lack of outright performance compared to the Si and Type R models. Fuel economy was a strong point, achieving around 42.8 US mpg in combined driving. In terms of reliability, the D16Z6 engine proved to be exceptionally durable, with many examples exceeding 200,000 miles with proper maintenance. Compared to the Si, the ZXi offered a lower price point but sacrificed performance.
Legacy
The Honda Integra DC2 1.6 ZXi remains a popular choice among enthusiasts seeking a reliable and affordable Japanese import. The D16Z6 engine is known for its longevity and relatively simple maintenance requirements. While not as sought-after as the Si or Type R models, the ZXi offers a unique blend of practicality, reliability, and Honda’s signature driving dynamics. In the used car market, well-maintained examples command reasonable prices, making it an accessible entry point into the world of Honda performance. The DC2 Integra, in all its trims, has cemented its place as a classic of the 1990s, and the 1.6 ZXi continues to be appreciated for its understated charm and enduring quality.
