| General information | |
|---|---|
| Brand | Honda |
| Model | NSX |
| Generation | NSX II Coupe |
| Type (Engine) | 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT |
| Start of production | 2016 year |
| End of production | 2022 year |
| Powertrain Architecture | FHEV (Full Hybrid Electric Vehicle) |
| Body type | Coupe |
| Seats | 2 |
| Doors | 2 |
| Performance specs | |
| Fuel consumption (economy) – urban | 10.3 l/100 km 22.8 US mpg 27.4 UK mpg 9.7 km/l |
| Fuel consumption (economy) – extra urban | 9.9 l/100 km 23.8 US mpg 28.5 UK mpg 10.1 km/l |
| Fuel consumption (economy) – combined | 10 l/100 km 23.5 US mpg 28.2 UK mpg 10 km/l |
| CO2 emissions | 228 g/km |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 308 km/h 191.38 mph |
| Weight-to-power ratio | 3.2 kg/Hp, 314.6 Hp/tonne |
| Weight-to-torque ratio | 2.9 kg/Nm, 349.2 Nm/tonne |
| Electric cars and hybrids specs | |
| Battery technology | Lithium-ion (Li-Ion) |
| Electric motor 1 | |
| Electric motor power | 48 Hp @ 3000 rpm. |
| Electric motor Torque | 147 Nm @ 500-2000 rpm.
108.42 lb.-ft. @ 500-2000 rpm. |
| Electric motor model/code | H2 |
| Electric motor location | Between the combustion engine and the transmission |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor power | 37 Hp @ 4000 rpm. |
| Electric motor Torque | 73 Nm @ 0-2000 rpm.
53.84 lb.-ft. @ 0-2000 rpm. |
| Electric motor model/code | H3 |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 3 | |
| Electric motor power | 37 Hp @ 4000 rpm. |
| Electric motor Torque | 73 Nm @ 0-2000 rpm.
53.84 lb.-ft. @ 0-2000 rpm. |
| Electric motor model/code | H3 |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| System power | 581 Hp |
| System torque | 645 Nm @ 2000-6000 rpm. 475.73 lb.-ft. @ 2000-6000 rpm. |
| Internal combustion engine specs | |
| Power | 507 Hp @ 6500-7500 rpm. |
| Power per litre | 145.1 Hp/l |
| Torque | 550 Nm @ 2000-6000 rpm. 405.66 lb.-ft. @ 2000-6000 rpm. |
| Maximum engine speed | 7500 rpm. |
| Engine Model/Code | JNC1 |
| Engine displacement | 3493 cm3 213.16 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 91 mm 3.58 in. |
| Piston Stroke | 89.5 mm 3.52 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | BiTurbo, Intercooler |
| Valvetrain | i-VTEC |
| Engine oil capacity | 7.9 l 8.35 US qt | 6.95 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 15.5 l 16.38 US qt | 13.64 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1847-1861 kg 4071.94 – 4102.8 lbs. |
| Max. weight | 2040 kg 4497.43 lbs. |
| Max load | 179-193 kg 394.63 – 425.49 lbs. |
| Trunk (boot) space – minimum | 110 l 3.88 cu. ft. |
| Fuel tank capacity | 59 l 15.59 US gal | 12.98 UK gal |
| Dimensions | |
| Length | 4487 mm 176.65 in. |
| Width | 1920 mm 75.59 in. |
| Width including mirrors | 2216 mm 87.24 in. |
| Height | 1204 mm 47.4 in. |
| Wheelbase | 2630 mm 103.54 in. |
| Front track | 1659 mm 65.31 in. |
| Rear (Back) track | 1620 mm 63.78 in. |
| Ride height (ground clearance) | 104 mm 4.09 in. |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the rear wheels of the car with the ability to work in full electric or mixed mode. Two electric motors drive the front wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission DCT |
| Front suspension | Double wishbone |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 245/35 ZR19 93Y Rear wheel tires: 305/30 ZR20 103Y |
| Wheel rims size | Front wheel rims: 8J x 19 Rear wheel rims: 11J x 20 |
| What is the body type, Honda NSX II Coupe? | Coupe, 2 Doors, 2 Seats |
|---|---|
| What is the fuel economy, Honda NSX II Coupe 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 10 l/100 km 23.5 US mpg 28.2 UK mpg 10 km/l |
| How ECO is the car, Honda NSX 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 228 g/km CO2 |
| How fast is the car, 2016 NSX II Coupe 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 308 km/h | 191.38 mph |
| How much power, Honda NSX Coupe 2016 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 581 Hp, 645 Nm 475.73 lb.-ft. |
| What is the engine size, Honda NSX Coupe 2016 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 3.5 l 3493 cm3 213.16 cu. in. |
| How many cylinders, 2016 Honda 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 6, V-engine |
| What is the drivetrain, Honda NSX II Coupe Coupe 2016 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | All wheel drive (4×4). FHEV (Full Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the rear wheels of the car with the ability to work in full electric or mixed mode. Two electric motors drive the front wheels. |
| How long is this vehicle, 2016 Honda NSX Coupe? | 4487 mm 176.65 in. |
| How wide is the vehicle, 2016 Honda NSX Coupe? | 1920 mm 75.59 in. |
| What is the curb weight, 2016 Honda NSX II Coupe 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 1847-1861 kg 4071.94 – 4102.8 lbs. |
| What is the gross weight, 2016 Honda NSX II Coupe 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 2040 kg 4497.43 lbs. |
| How much trunk (boot) space, 2016 Honda NSX Coupe? | 110 l 3.88 cu. ft. |
| How many gears, What type is the gearbox, 2016 Honda NSX II Coupe 3.5 i-VTEC Bi-Turbo V6 (581 Hp) Hybrid SH-AWD DCT? | 9, automatic transmission DCT |
