| General information | |
|---|---|
| Brand | Honda |
| Model | Pilot |
| Generation | Pilot I |
| Type (Engine) | 3.5 V6 (243 Hp) AWD Automatic |
| Start of production | 2002 year |
| End of production | 2004 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV, Crossover |
| Seats | 8 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 13.9 l/100 km 16.9 US mpg 20.3 UK mpg 7.2 km/l |
| Fuel consumption (economy) – extra urban | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 8.2 sec |
| Acceleration 0 – 62 mph | 8.2 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.8 sec |
| Maximum speed | 175 km/h 108.74 mph |
| Weight-to-power ratio | 8.2 kg/Hp, 121.5 Hp/tonne |
| Weight-to-torque ratio | 6.1 kg/Nm, 164 Nm/tonne |
| Engine specs | |
| Power | 243 Hp @ 5500 rpm. |
| Power per litre | 70 Hp/l |
| Torque | 328 Nm @ 4500 rpm. 241.92 lb.-ft. @ 4500 rpm. |
| Maximum engine speed | 6200 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | J35A4 |
| Engine displacement | 3471 cm3 211.81 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 89 mm 3.5 in. |
| Piston Stroke | 93 mm 3.66 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC VTEC |
| Engine oil capacity | 4.8 l 5.07 US qt | 4.22 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.6 l 6.97 US qt | 5.81 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2000-2010 kg 4409.25 – 4431.29 lbs. |
| Trunk (boot) space – minimum | 461 l 16.28 cu. ft. |
| Trunk (boot) space – maximum | 2557 l 90.3 cu. ft. |
| Fuel tank capacity | 73 l 19.28 US gal | 16.06 UK gal |
| Permitted trailer load with brakes (12%) | 2039 kg 4495.23 lbs. |
| Dimensions | |
| Length | 4775 mm 187.99 in. |
| Width | 1964 mm 77.32 in. |
| Height | 1793 mm 70.59 in. |
| Wheelbase | 2700 mm 106.3 in. |
| Front track | 1684 mm 66.3 in. |
| Rear (Back) track | 1689 mm 66.5 in. |
| Ride height (ground clearance) | 203 mm 7.99 in. |
| Minimum turning circle (turning diameter) | 11.5 m 37.73 ft. |
| Approach angle | 28.5° |
| Departure angle | 23° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs, 300 mm |
| Rear brakes | Disc, 312 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 235/70 R16 |
| Wheel rims size | 6.5J X 16 |
| What is the body type, Honda Pilot I? | SUV, Crossover, 5 Doors, 8 Seats |
|---|---|
| How fast is the car, 2002 Pilot I 3.5 V6 (243 Hp) AWD Automatic? | 175 km/h | 108.74 mph 0-100 km/h: 8.2 sec 0-60 mph: 7.8 sec |
| How much power, Honda Pilot SUV, Crossover 2002 3.5 V6 (243 Hp) AWD Automatic? | 243 Hp, 328 Nm 241.92 lb.-ft. |
| What is the engine size, Honda Pilot SUV, Crossover 2002 3.5 V6 (243 Hp) AWD Automatic? | 3.5 l 3471 cm3 211.81 cu. in. |
| How many cylinders, 2002 Honda 3.5 V6 (243 Hp) AWD Automatic? | 6, V-engine |
| What is the drivetrain, Honda Pilot I SUV, Crossover 2002 3.5 V6 (243 Hp) AWD Automatic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2002 Honda Pilot SUV, Crossover? | 4775 mm 187.99 in. |
| How wide is the vehicle, 2002 Honda Pilot SUV, Crossover? | 1964 mm 77.32 in. |
| What is the curb weight, 2002 Honda Pilot I 3.5 V6 (243 Hp) AWD Automatic? | 2000-2010 kg 4409.25 – 4431.29 lbs. |
| How much trunk (boot) space, 2002 Honda Pilot SUV, Crossover? | 461 – 2557 l 16.28 – 90.3 cu. ft. |
| How many gears, What type is the gearbox, 2002 Honda Pilot I 3.5 V6 (243 Hp) AWD Automatic? | 5, automatic transmission |
