| General information | |
|---|---|
| Brand | Honda |
| Model | Pilot |
| Generation | Pilot IV |
| Type (Engine) | TrailSport 3.5 V6 (285 Hp) AWD Automatic |
| Start of production | December, 2022 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV, Crossover |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 13 l/100 km 18.1 US mpg 21.7 UK mpg 7.7 km/l |
| Fuel consumption (economy) – extra urban | 10.3 l/100 km 22.8 US mpg 27.4 UK mpg 9.7 km/l |
| Fuel consumption (economy) – combined | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | Tier 3 Bin 30 |
| Weight-to-power ratio | 7.5 kg/Hp, 133.8 Hp/tonne |
| Weight-to-torque ratio | 6 kg/Nm, 166.7 Nm/tonne |
| Engine specs | |
| Power | 285 Hp @ 6100 rpm. |
| Power per litre | 82.1 Hp/l |
| Torque | 355 Nm @ 5000 rpm. 261.83 lb.-ft. @ 5000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | J35Y8 |
| Engine displacement | 3471 cm3 211.81 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 89 mm 3.5 in. |
| Piston Stroke | 93 mm 3.66 in. |
| Compression ratio | 11.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, i-VTEC |
| Engine oil capacity | 5.5 l 5.81 US qt | 4.84 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.67 l 8.1 US qt | 6.75 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2130 kg 4695.85 lbs. |
| Max. weight | 2810 kg 6194.99 lbs. |
| Max load | 680 kg 1499.14 lbs. |
| Trunk (boot) space – minimum | 618 l 21.82 cu. ft. |
| Trunk (boot) space – maximum | 3219 l 113.68 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| Permitted trailer load with brakes (12%) | 2268 kg 5000.08 lbs. |
| Dimensions | |
| Length | 5085 mm 200.2 in. |
| Width with mirrors folded | 2090 mm 82.28 in. |
| Width including mirrors | 2254 mm 88.74 in. |
| Height | 1829 mm 72.01 in. |
| Wheelbase | 2891 mm 113.82 in. |
| Front track | 1707 mm 67.2 in. |
| Rear (Back) track | 1712 mm 67.4 in. |
| Ride height (ground clearance) | 210 mm 8.27 in. |
| Minimum turning circle (turning diameter) | 11.52 m 37.8 ft. |
| Approach angle | 19.8° |
| Departure angle | 19° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 10 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 265/60 R18 110T |
| Wheel rims size | 18 |
| What is the body type, Honda Pilot IV? | SUV, Crossover, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Honda Pilot IV TrailSport 3.5 V6 (285 Hp) AWD Automatic? | 11.8 l/100 km 19.9 US mpg 23.9 UK mpg 8.5 km/l |
| How ECO is the car, Honda Pilot TrailSport 3.5 V6 (285 Hp) AWD Automatic? | Tier 3 Bin 30 |
| How much power, Honda Pilot SUV, Crossover 2022 TrailSport 3.5 V6 (285 Hp) AWD Automatic? | 285 Hp, 355 Nm 261.83 lb.-ft. |
| What is the engine size, Honda Pilot SUV, Crossover 2022 TrailSport 3.5 V6 (285 Hp) AWD Automatic? | 3.5 l 3471 cm3 211.81 cu. in. |
| How many cylinders, 2022 Honda TrailSport 3.5 V6 (285 Hp) AWD Automatic? | 6, V-engine |
| What is the drivetrain, Honda Pilot IV SUV, Crossover 2022 TrailSport 3.5 V6 (285 Hp) AWD Automatic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2022 Honda Pilot SUV, Crossover? | 5085 mm 200.2 in. |
| How wide is the vehicle, 2022 Honda Pilot SUV, Crossover? | 2090 mm 82.28 in. |
| What is the curb weight, 2022 Honda Pilot IV TrailSport 3.5 V6 (285 Hp) AWD Automatic? | 2130 kg 4695.85 lbs. |
| What is the gross weight, 2022 Honda Pilot IV TrailSport 3.5 V6 (285 Hp) AWD Automatic? | 2810 kg 6194.99 lbs. |
| How much trunk (boot) space, 2022 Honda Pilot SUV, Crossover? | 618 – 3219 l 21.82 – 113.68 cu. ft. |
| How many gears, What type is the gearbox, 2022 Honda Pilot IV TrailSport 3.5 V6 (285 Hp) AWD Automatic? | 10, automatic transmission |
