| General information | |
|---|---|
| Brand | Hyundai |
| Model | Elantra |
| Generation | Elantra VII (CN7, facelift 2023) |
| Type (Engine) | 1.6 T-GDI (201 Hp) DCT |
| Start of production | August, 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban | 8.4 l/100 km 28 US mpg 33.6 UK mpg 11.9 km/l |
| Fuel consumption (economy) – extra urban | 6.6 l/100 km 35.6 US mpg 42.8 UK mpg 15.2 km/l |
| Fuel consumption (economy) – combined | 7.6 l/100 km 30.9 US mpg 37.2 UK mpg 13.2 km/l |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | LEV3 ULEV70 |
| Weight-to-power ratio | 6.8 kg/Hp, 146.7 Hp/tonne |
| Weight-to-torque ratio | 5.2 kg/Nm, 192.7 Nm/tonne |
| Engine specs | |
| Power | 201 Hp @ 6000 rpm. |
| Power per litre | 125.8 Hp/l |
| Torque | 264 Nm @ 1500-4500 rpm. 194.72 lb.-ft. @ 1500-4500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Smartstream / G4FP |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75.6 mm 2.98 in. |
| Piston Stroke | 89 mm 3.5 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC, CVVD |
| Engine oil capacity | 4.8 l 5.07 US qt | 4.22 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.8 l 7.19 US qt | 5.98 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1370 kg 3020.33 lbs. |
| Max. weight | 1810 kg 3990.37 lbs. |
| Max load | 440 kg 970.03 lbs. |
| Trunk (boot) space – minimum | 402 l 14.2 cu. ft. |
| Fuel tank capacity | 47 l 12.42 US gal | 10.34 UK gal |
| Dimensions | |
| Length | 4710 mm 185.43 in. |
| Width | 1825 mm 71.85 in. |
| Height | 1415 mm 55.71 in. |
| Wheelbase | 2720 mm 107.09 in. |
| Front track | 1566 mm 61.65 in. |
| Rear (Back) track | 1581 mm 62.24 in. |
| Front overhang | 920 mm 36.22 in. |
| Rear overhang | 1070 mm 42.13 in. |
| Ride height (ground clearance) | 135 mm 5.31 in. |
| Drag coefficient (Cd) | 0.31 |
| Minimum turning circle (turning diameter) | 10.6 m 34.78 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission DCT |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 305 mm |
| Rear brakes | Disc, 284 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/40 R18 |
| Wheel rims size | 7.5J x 18; 8J x 18 |
| What is the body type, Hyundai Elantra VII (CN7, facelift 2023)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Hyundai Elantra VII (CN7, facelift 2023) 1.6 T-GDI (201 Hp) DCT? | 7.6 l/100 km 30.9 US mpg 37.2 UK mpg 13.2 km/l |
| How ECO is the car, Hyundai Elantra 1.6 T-GDI (201 Hp) DCT? | LEV3 ULEV70 |
| How much power, Hyundai Elantra Sedan 2023 1.6 T-GDI (201 Hp) DCT? | 201 Hp, 264 Nm 194.72 lb.-ft. |
| What is the engine size, Hyundai Elantra Sedan 2023 1.6 T-GDI (201 Hp) DCT? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2023 Hyundai 1.6 T-GDI (201 Hp) DCT? | 4, Inline |
| What is the drivetrain, Hyundai Elantra VII (CN7, facelift 2023) Sedan 2023 1.6 T-GDI (201 Hp) DCT? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2023 Hyundai Elantra Sedan? | 4710 mm 185.43 in. |
| How wide is the vehicle, 2023 Hyundai Elantra Sedan? | 1825 mm 71.85 in. |
| What is the curb weight, 2023 Hyundai Elantra VII (CN7, facelift 2023) 1.6 T-GDI (201 Hp) DCT? | 1370 kg 3020.33 lbs. |
| What is the gross weight, 2023 Hyundai Elantra VII (CN7, facelift 2023) 1.6 T-GDI (201 Hp) DCT? | 1810 kg 3990.37 lbs. |
| How much trunk (boot) space, 2023 Hyundai Elantra Sedan? | 402 l 14.2 cu. ft. |
| How many gears, What type is the gearbox, 2023 Hyundai Elantra VII (CN7, facelift 2023) 1.6 T-GDI (201 Hp) DCT? | 7, automatic transmission DCT |
