| General information | |
|---|---|
| Brand | Hyundai |
| Model | H-1 |
| Generation | H-1 II Travel (facelift 2018) |
| Type (Engine) | 2.5 CRDi (170 Hp) Automatic |
| Start of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 8 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 12 l/100 km 19.6 US mpg 23.5 UK mpg 8.3 km/l |
| Fuel consumption (economy) – extra urban | 7.7 l/100 km 30.5 US mpg 36.7 UK mpg 13 km/l |
| Fuel consumption (economy) – combined | 9.3 l/100 km 25.3 US mpg 30.4 UK mpg 10.8 km/l |
| CO2 emissions | 244 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 14.4 sec |
| Acceleration 0 – 62 mph | 14.4 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 13.7 sec |
| Maximum speed | 180 km/h 111.85 mph |
| Emission standard | Euro 6d-TEMP |
| Weight-to-power ratio | 13.5 kg/Hp, 74.2 Hp/tonne |
| Weight-to-torque ratio | 5.2 kg/Nm, 192.6 Nm/tonne |
| Engine specs | |
| Power | 170 Hp @ 3600 rpm. |
| Power per litre | 68.1 Hp/l |
| Torque | 441 Nm @ 2000-2250 rpm. 325.26 lb.-ft. @ 2000-2250 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | D4CB |
| Engine displacement | 2497 cm3 152.38 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 91 mm 3.58 in. |
| Piston Stroke | 96 mm 3.78 in. |
| Compression ratio | 16.4:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 7.4 l 7.82 US qt | 6.51 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 13 l 13.74 US qt | 11.44 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2290 kg 5048.59 lbs. |
| Max. weight | 3070 kg 6768.19 lbs. |
| Max load | 780 kg 1719.61 lbs. |
| Trunk (boot) space – minimum | 842 l 29.73 cu. ft. |
| Fuel tank capacity | 75 l 19.81 US gal | 16.5 UK gal |
| Permitted trailer load with brakes (12%) | 1500 kg 3306.93 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 5150 mm 202.76 in. |
| Width | 1920 mm 75.59 in. |
| Height | 1925 mm 75.79 in. |
| Wheelbase | 3200 mm 125.98 in. |
| Front track | 1685 mm 66.34 in. |
| Rear (Back) track | 1660 mm 65.35 in. |
| Front overhang | 880 mm 34.65 in. |
| Rear overhang | 1070 mm 42.13 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R17 |
| Wheel rims size | 7.0J x 17 |
| What is the body type, Hyundai H-1 II Travel (facelift 2018)? | Minivan, 5 Doors, 8 Seats |
|---|---|
| What is the fuel economy, Hyundai H-1 II Travel (facelift 2018) 2.5 CRDi (170 Hp) Automatic? | 9.3 l/100 km 25.3 US mpg 30.4 UK mpg 10.8 km/l |
| How ECO is the car, Hyundai H-1 2.5 CRDi (170 Hp) Automatic? | 244 g/km CO2 Euro 6d-TEMP |
| How fast is the car, 2018 H-1 II Travel (facelift 2018) 2.5 CRDi (170 Hp) Automatic? | 180 km/h | 111.85 mph 0-100 km/h: 14.4 sec 0-60 mph: 13.7 sec |
| How much power, Hyundai H-1 Minivan 2018 2.5 CRDi (170 Hp) Automatic? | 170 Hp, 441 Nm 325.26 lb.-ft. |
| What is the engine size, Hyundai H-1 Minivan 2018 2.5 CRDi (170 Hp) Automatic? | 2.5 l 2497 cm3 152.38 cu. in. |
| How many cylinders, 2018 Hyundai 2.5 CRDi (170 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Hyundai H-1 II Travel (facelift 2018) Minivan 2018 2.5 CRDi (170 Hp) Automatic? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2018 Hyundai H-1 Minivan? | 5150 mm 202.76 in. |
| How wide is the vehicle, 2018 Hyundai H-1 Minivan? | 1920 mm 75.59 in. |
| What is the curb weight, 2018 Hyundai H-1 II Travel (facelift 2018) 2.5 CRDi (170 Hp) Automatic? | 2290 kg 5048.59 lbs. |
| What is the gross weight, 2018 Hyundai H-1 II Travel (facelift 2018) 2.5 CRDi (170 Hp) Automatic? | 3070 kg 6768.19 lbs. |
| How much trunk (boot) space, 2018 Hyundai H-1 Minivan? | 842 l 29.73 cu. ft. |
| How many gears, What type is the gearbox, 2018 Hyundai H-1 II Travel (facelift 2018) 2.5 CRDi (170 Hp) Automatic? | 5, automatic transmission |
