| General information | |
|---|---|
| Brand | Hyundai |
| Model | IONIQ 5 |
| Generation | IONIQ 5 (facelift 2024) |
| Type (Engine) | Long Range 84 kWh (325 Hp) Electric AWD |
| Start of production | March, 2024 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Weight-to-power ratio | 6.5 kg/Hp, 153.3 Hp/tonne |
| Weight-to-torque ratio | 3.5 kg/Nm, 285.4 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 84 kWh |
| Battery voltage | 697 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| All-electric range | 411-451 km 255.38 – 280.24 mi |
| Average Energy consumption | 20.8-22.7 kWh/100 km
33.47 – 36.53 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 325 Hp |
| System torque | 605 Nm 446.23 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2120-2160 kg 4673.8 – 4761.98 lbs. |
| Dimensions | |
| Length | 4655 mm 183.27 in. |
| Width | 1890 mm 74.41 in. |
| Height | 1605 mm 63.19 in. |
| Wheelbase | 3000 mm 118.11 in. |
| Front track | 1628-1638 mm 64.09 – 64.49 in. |
| Rear (Back) track | 1637-1647 mm 64.45 – 64.84 in. |
| Front overhang | 866 mm 34.09 in. |
| Rear overhang | 789 mm 31.06 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/55 R19; 255/45 R20 |
| Wheel rims size | 19; 20 |
| What is the body type, Hyundai IONIQ 5 (facelift 2024)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, Long Range 84 kWh (325 Hp) Electric AWD? | 411-451 km 255.38 – 280.24 mi |
| What is electricity consumption, Hyundai IONIQ 5 (facelift 2024) Long Range 84 kWh (325 Hp) Electric AWD? | 20.8-22.7 kWh/100 km 33.47 – 36.53 kWh/100 mi 101 – 92 MPGe 4.8 – 4.4 km/kWh 3 – 2.7 mi/kWh |
| How much power, Hyundai IONIQ 5 SUV 2024 Long Range 84 kWh (325 Hp) Electric AWD? | 325 Hp, 605 Nm 446.23 lb.-ft. |
| What is the drivetrain, Hyundai IONIQ 5 (facelift 2024) SUV 2024 Long Range 84 kWh (325 Hp) Electric AWD? | All wheel drive (4×4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| How long is this vehicle, 2024 Hyundai IONIQ 5 SUV? | 4655 mm 183.27 in. |
| How wide is the vehicle, 2024 Hyundai IONIQ 5 SUV? | 1890 mm 74.41 in. |
| What is the curb weight, 2024 Hyundai IONIQ 5 (facelift 2024) Long Range 84 kWh (325 Hp) Electric AWD? | 2120-2160 kg 4673.8 – 4761.98 lbs. |
| How many gears, What type is the gearbox, 2024 Hyundai IONIQ 5 (facelift 2024) Long Range 84 kWh (325 Hp) Electric AWD? | 1, automatic transmission |
