| General information | |
|---|---|
| Brand | Hyundai |
| Model | IONIQ |
| Generation | IONIQ (facelift 2019) |
| Type (Engine) | 1.6 GDI (141 Hp) Hybrid DCT |
| Start of production | 2019 year |
| End of production | July, 2022 year |
| Powertrain Architecture | FHEV (Full Hybrid Electric Vehicle) |
| Body type | Liftback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 10.8 sec |
| Acceleration 0 – 62 mph | 10.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 10.3 sec |
| Maximum speed | 185 km/h 114.95 mph |
| Emission standard | Euro 6d-TEMP |
| Weight-to-power ratio | 10.4 kg/Hp, 96 Hp/tonne |
| Weight-to-torque ratio | 5.5 kg/Nm, 180.4 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 1.56 kWh |
| Battery voltage | 240 V |
| Battery technology | Lithium-polymer (LiPo) |
| Electric motor 1 | |
| Electric motor power | 44 Hp |
| Electric motor Torque | 170 Nm
125.39 lb.-ft. |
| Electric motor type | Synchronous |
| System power | 141 Hp |
| System torque | 265 Nm 195.45 lb.-ft. |
| Internal combustion engine specs | |
| Power | 105 Hp @ 5700 rpm. |
| Power per litre | 66.5 Hp/l |
| Torque | 147 Nm @ 4000 rpm. 108.42 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Transverse |
| Engine displacement | 1580 cm3 96.42 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 72 mm 2.83 in. |
| Piston Stroke | 97 mm 3.82 in. |
| Compression ratio | 13:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 3.8 l 4.02 US qt | 3.34 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.7 l 7.08 US qt | 5.9 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1469 kg 3238.59 lbs. |
| Max. weight | 1870 kg 4122.64 lbs. |
| Max load | 401 kg 884.05 lbs. |
| Trunk (boot) space – minimum | 443 l 15.64 cu. ft. |
| Trunk (boot) space – maximum | 1505 l 53.15 cu. ft. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Permitted trailer load with brakes (12%) | 750 kg 1653.47 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4470 mm 175.98 in. |
| Width | 1820 mm 71.65 in. |
| Width including mirrors | 2045 mm 80.51 in. |
| Height | 1450 mm 57.09 in. |
| Wheelbase | 2700 mm 106.3 in. |
| Front track | 1549-1563 mm 60.98 – 61.54 in. |
| Rear (Back) track | 1563-1577 mm 61.54 – 62.09 in. |
| Minimum turning circle (turning diameter) | 10.6 m 34.78 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission DCT |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Disc |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 195/65 R15; 225/45 R17 |
| Wheel rims size | 6J x 15; 7J x 17 |
| What is the body type, Hyundai IONIQ (facelift 2019)? | Liftback, 5 Doors, 5 Seats |
|---|---|
| How ECO is the car, Hyundai IONIQ 1.6 GDI (141 Hp) Hybrid DCT? | Euro 6d-TEMP |
| How fast is the car, 2019 IONIQ (facelift 2019) 1.6 GDI (141 Hp) Hybrid DCT? | 185 km/h | 114.95 mph 0-100 km/h: 10.8 sec 0-60 mph: 10.3 sec |
| How much power, Hyundai IONIQ Liftback 2019 1.6 GDI (141 Hp) Hybrid DCT? | 141 Hp, 265 Nm 195.45 lb.-ft. |
| What is the engine size, Hyundai IONIQ Liftback 2019 1.6 GDI (141 Hp) Hybrid DCT? | 1.6 l 1580 cm3 96.42 cu. in. |
| How many cylinders, 2019 Hyundai 1.6 GDI (141 Hp) Hybrid DCT? | 4, Inline |
| What is the drivetrain, Hyundai IONIQ (facelift 2019) Liftback 2019 1.6 GDI (141 Hp) Hybrid DCT? | Front wheel drive. FHEV (Full Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2019 Hyundai IONIQ Liftback? | 4470 mm 175.98 in. |
| How wide is the vehicle, 2019 Hyundai IONIQ Liftback? | 1820 mm 71.65 in. |
| What is the curb weight, 2019 Hyundai IONIQ (facelift 2019) 1.6 GDI (141 Hp) Hybrid DCT? | 1469 kg 3238.59 lbs. |
| What is the gross weight, 2019 Hyundai IONIQ (facelift 2019) 1.6 GDI (141 Hp) Hybrid DCT? | 1870 kg 4122.64 lbs. |
| How much trunk (boot) space, 2019 Hyundai IONIQ Liftback? | 443 – 1505 l 15.64 – 53.15 cu. ft. |
| How many gears, What type is the gearbox, 2019 Hyundai IONIQ (facelift 2019) 1.6 GDI (141 Hp) Hybrid DCT? | 6, automatic transmission DCT |
