| General information | |
|---|---|
| Brand | Hyundai |
| Model | Santa Cruz |
| Generation | Santa Cruz |
| Type (Engine) | 2.5 GDI MPI (191 Hp) Automatic |
| Start of production | June, 2021 year |
| End of production | March, 2024 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban (EPA) | 10.7 l/100 km 22 US mpg 26.4 UK mpg 9.3 km/l |
| Fuel consumption (economy) – extra urban (EPA) | 9 l/100 km 26.1 US mpg 31.4 UK mpg 11.1 km/l |
| Fuel consumption (economy) – combined (EPA) | 10.2 l/100 km 23.1 US mpg 27.7 UK mpg 9.8 km/l |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | ULEV |
| Weight-to-power ratio | 8.9 kg/Hp, 112.2 Hp/tonne |
| Weight-to-torque ratio | 7 kg/Nm, 143.9 Nm/tonne |
| Engine specs | |
| Power | 191 Hp @ 6100 rpm. |
| Power per litre | 76.5 Hp/l |
| Torque | 245 Nm @ 4000 rpm. 180.7 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Smartstream / G4KN |
| Engine displacement | 2497 cm3 152.38 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 88.5 mm 3.48 in. |
| Piston Stroke | 101.5 mm 4 in. |
| Compression ratio | 13:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection and Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC, CVVT |
| Engine oil capacity | 5.8 l 6.13 US qt | 5.1 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9.46 l 10 US qt | 8.32 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1703-1711 kg 3754.47 – 3772.11 lbs. |
| Max. weight | 2475 kg 5456.44 lbs. |
| Max load | 764-772 kg 1684.33 – 1701.97 lbs. |
| Trunk (boot) space – maximum | 765 l 27.02 cu. ft. |
| Fuel tank capacity | 67 l 17.7 US gal | 14.74 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 1588 kg 3500.94 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4971 mm 195.71 in. |
| Width | 1905 mm 75 in. |
| Height | 1694 mm 66.69 in. |
| Wheelbase | 3005 mm 118.31 in. |
| Front track | 1643 mm 64.69 in. |
| Rear (Back) track | 1648 mm 64.88 in. |
| Ride height (ground clearance) | 218 mm 8.58 in. |
| Drag coefficient (Cd) | 0.37 |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Approach angle | 17.5° |
| Departure angle | 23.2° |
| Ramp-over (brakeover) angle | 18.6° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs, 325×30 mm |
| Rear brakes | Disc, 325×12 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/60 R18; 245/50 R20 |
| Wheel rims size | 7.5J x 18; 7.5J x 20 |
| What is the body type, Hyundai Santa Cruz? | Pick-up, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Hyundai Santa Cruz 2.5 GDI MPI (191 Hp) Automatic? | 10.2 l/100 km 23.1 US mpg 27.7 UK mpg 9.8 km/l |
| How ECO is the car, Hyundai Santa Cruz 2.5 GDI MPI (191 Hp) Automatic? | ULEV |
| How much power, Hyundai Santa Cruz Pick-up 2021 2.5 GDI MPI (191 Hp) Automatic? | 191 Hp, 245 Nm 180.7 lb.-ft. |
| What is the engine size, Hyundai Santa Cruz Pick-up 2021 2.5 GDI MPI (191 Hp) Automatic? | 2.5 l 2497 cm3 152.38 cu. in. |
| How many cylinders, 2021 Hyundai 2.5 GDI MPI (191 Hp) Automatic? | 4, Inline |
| What is the drivetrain, Hyundai Santa Cruz Pick-up 2021 2.5 GDI MPI (191 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2021 Hyundai Santa Cruz Pick-up? | 4971 mm 195.71 in. |
| How wide is the vehicle, 2021 Hyundai Santa Cruz Pick-up? | 1905 mm 75 in. |
| What is the curb weight, 2021 Hyundai Santa Cruz 2.5 GDI MPI (191 Hp) Automatic? | 1703-1711 kg 3754.47 – 3772.11 lbs. |
| What is the gross weight, 2021 Hyundai Santa Cruz 2.5 GDI MPI (191 Hp) Automatic? | 2475 kg 5456.44 lbs. |
| How much trunk (boot) space, 2021 Hyundai Santa Cruz Pick-up? | 765 l 27.02 cu. ft. |
| How many gears, What type is the gearbox, 2021 Hyundai Santa Cruz 2.5 GDI MPI (191 Hp) Automatic? | 8, automatic transmission |
