| General information | |
|---|---|
| Brand | Hyundai |
| Model | Santa Fe |
| Generation | Santa Fe II (CM) |
| Type (Engine) | 2.2 CRDi (155 Hp) 4WD Automatic |
| Start of production | 2006 year |
| End of production | 2009 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 10.4 l/100 km 22.6 US mpg 27.2 UK mpg 9.6 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 6.7 l/100 km 35.1 US mpg 42.2 UK mpg 14.9 km/l |
| Fuel consumption (economy) – combined (NEDC) | 8.1 l/100 km 29 US mpg 34.9 UK mpg 12.3 km/l |
| CO2 emissions (NEDC) | 212 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 12.9 sec |
| Acceleration 0 – 62 mph | 12.9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 12.3 sec |
| Maximum speed | 178 km/h 110.6 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 12 kg/Hp, 83.6 Hp/tonne |
| Weight-to-torque ratio | 5.4 kg/Nm, 185.1 Nm/tonne |
| Engine specs | |
| Power | 155 Hp @ 4000 rpm. |
| Power per litre | 70.8 Hp/l |
| Torque | 343 Nm @ 1800-2500 rpm. 252.98 lb.-ft. @ 1800-2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | D4EB |
| Engine displacement | 2188 cm3 133.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 87 mm 3.43 in. |
| Piston Stroke | 92 mm 3.62 in. |
| Compression ratio | 17.3:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | SOHC |
| Engine oil capacity | 5.9 l 6.23 US qt | 5.19 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8.4 l 8.88 US qt | 7.39 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1853-1946 kg 4085.17 – 4290.2 lbs. |
| Max. weight | 2570 kg 5665.88 lbs. |
| Max load | 624-717 kg 1375.68 – 1580.71 lbs. |
| Trunk (boot) space – minimum | 528 l 18.65 cu. ft. |
| Fuel tank capacity | 75 l 19.81 US gal | 16.5 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (8%) | 3000 kg 6613.87 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 80 kg 176.37 lbs. |
| Dimensions | |
| Length | 4675 mm 184.06 in. |
| Width | 1890 mm 74.41 in. |
| Height | 1795 mm 70.67 in. |
| Wheelbase | 2700 mm 106.3 in. |
| Front track | 1615 mm 63.58 in. |
| Rear (Back) track | 1620 mm 63.78 in. |
| Front overhang | 940 mm 37.01 in. |
| Rear overhang | 1035 mm 40.75 in. |
| Ride height (ground clearance) | 203 mm 7.99 in. |
| Drag coefficient (Cd) | 0.38 |
| Minimum turning circle (turning diameter) | 10.9 m 35.76 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 235/65 R17; 235/60 R18 |
| Wheel rims size | 7J x 17; 8J x 18 |
| What is the body type, Hyundai Santa Fe II (CM)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Hyundai Santa Fe II (CM) 2.2 CRDi (155 Hp) 4WD Automatic? | 8.1 l/100 km 29 US mpg 34.9 UK mpg 12.3 km/l |
| How ECO is the car, Hyundai Santa Fe 2.2 CRDi (155 Hp) 4WD Automatic? | 212 g/km CO2 Euro 4 |
| How fast is the car, 2006 Santa Fe II (CM) 2.2 CRDi (155 Hp) 4WD Automatic? | 178 km/h | 110.6 mph 0-100 km/h: 12.9 sec 0-60 mph: 12.3 sec |
| How much power, Hyundai Santa Fe SUV 2006 2.2 CRDi (155 Hp) 4WD Automatic? | 155 Hp, 343 Nm 252.98 lb.-ft. |
| What is the engine size, Hyundai Santa Fe SUV 2006 2.2 CRDi (155 Hp) 4WD Automatic? | 2.2 l 2188 cm3 133.52 cu. in. |
| How many cylinders, 2006 Hyundai 2.2 CRDi (155 Hp) 4WD Automatic? | 4, Inline |
| What is the drivetrain, Hyundai Santa Fe II (CM) SUV 2006 2.2 CRDi (155 Hp) 4WD Automatic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2006 Hyundai Santa Fe SUV? | 4675 mm 184.06 in. |
| How wide is the vehicle, 2006 Hyundai Santa Fe SUV? | 1890 mm 74.41 in. |
| What is the curb weight, 2006 Hyundai Santa Fe II (CM) 2.2 CRDi (155 Hp) 4WD Automatic? | 1853-1946 kg 4085.17 – 4290.2 lbs. |
| What is the gross weight, 2006 Hyundai Santa Fe II (CM) 2.2 CRDi (155 Hp) 4WD Automatic? | 2570 kg 5665.88 lbs. |
| How much trunk (boot) space, 2006 Hyundai Santa Fe SUV? | 528 l 18.65 cu. ft. |
| How many gears, What type is the gearbox, 2006 Hyundai Santa Fe II (CM) 2.2 CRDi (155 Hp) 4WD Automatic? | 5, automatic transmission |
