| General information | |
|---|---|
| Brand | Hyundai |
| Model | Santa Fe |
| Generation | Santa Fe II (CM, facelift 2009) |
| Type (Engine) | 2.2 CRDi (197 Hp) |
| Start of production | 2009 year |
| End of production | 2012 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 8.2 l/100 km 28.7 US mpg 34.4 UK mpg 12.2 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 5.2 l/100 km 45.2 US mpg 54.3 UK mpg 19.2 km/l |
| Fuel consumption (economy) – combined (NEDC) | 6.3 l/100 km 37.3 US mpg 44.8 UK mpg 15.9 km/l |
| CO2 emissions (NEDC) | 171 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 9.5 sec |
| Acceleration 0 – 62 mph | 9.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9 sec |
| Maximum speed | 190 km/h 118.06 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 8.9 kg/Hp, 112.3 Hp/tonne |
| Weight-to-torque ratio | 4.2 kg/Nm, 239.9 Nm/tonne |
| Engine specs | |
| Power | 197 Hp @ 3800 rpm. |
| Power per litre | 89.6 Hp/l |
| Torque | 421 Nm @ 1800-2500 rpm. 310.51 lb.-ft. @ 1800-2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | D4HB |
| Engine displacement | 2199 cm3 134.19 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 85.4 mm 3.36 in. |
| Piston Stroke | 96 mm 3.78 in. |
| Compression ratio | 16:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6.7 l 7.08 US qt | 5.9 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8.6 l 9.09 US qt | 7.57 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1755-1835 kg 3869.11 – 4045.48 lbs. |
| Max. weight | 2520 kg 5555.65 lbs. |
| Max load | 685-765 kg 1510.17 – 1686.54 lbs. |
| Trunk (boot) space – minimum | 528 l 18.65 cu. ft. |
| Fuel tank capacity | 75 l 19.81 US gal | 16.5 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2500 kg 5511.56 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4660 mm 183.46 in. |
| Width | 1890 mm 74.41 in. |
| Height | 1760 mm 69.29 in. |
| Wheelbase | 2700 mm 106.3 in. |
| Front track | 1615 mm 63.58 in. |
| Rear (Back) track | 1620 mm 63.78 in. |
| Front overhang | 930 mm 36.61 in. |
| Rear overhang | 1030 mm 40.55 in. |
| Ride height (ground clearance) | 200 mm 7.87 in. |
| Drag coefficient (Cd) | 0.38 |
| Minimum turning circle (turning diameter) | 10.9 m 35.76 ft. |
| Approach angle | 24.6° |
| Departure angle | 21.6° |
| Ramp-over (brakeover) angle | 17.9° |
| Wading depth | 500 mm 19.69 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 235/65 R17 |
| Wheel rims size | 7J x 17 |
| What is the body type, Hyundai Santa Fe II (CM, facelift 2009)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Hyundai Santa Fe II (CM, facelift 2009) 2.2 CRDi (197 Hp)? | 6.3 l/100 km 37.3 US mpg 44.8 UK mpg 15.9 km/l |
| How ECO is the car, Hyundai Santa Fe 2.2 CRDi (197 Hp)? | 171 g/km CO2 Euro 5 |
| How fast is the car, 2009 Santa Fe II (CM, facelift 2009) 2.2 CRDi (197 Hp)? | 190 km/h | 118.06 mph 0-100 km/h: 9.5 sec 0-60 mph: 9 sec |
| How much power, Hyundai Santa Fe SUV 2009 2.2 CRDi (197 Hp)? | 197 Hp, 421 Nm 310.51 lb.-ft. |
| What is the engine size, Hyundai Santa Fe SUV 2009 2.2 CRDi (197 Hp)? | 2.2 l 2199 cm3 134.19 cu. in. |
| How many cylinders, 2009 Hyundai 2.2 CRDi (197 Hp)? | 4, Inline |
| What is the drivetrain, Hyundai Santa Fe II (CM, facelift 2009) SUV 2009 2.2 CRDi (197 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2009 Hyundai Santa Fe SUV? | 4660 mm 183.46 in. |
| How wide is the vehicle, 2009 Hyundai Santa Fe SUV? | 1890 mm 74.41 in. |
| What is the curb weight, 2009 Hyundai Santa Fe II (CM, facelift 2009) 2.2 CRDi (197 Hp)? | 1755-1835 kg 3869.11 – 4045.48 lbs. |
| What is the gross weight, 2009 Hyundai Santa Fe II (CM, facelift 2009) 2.2 CRDi (197 Hp)? | 2520 kg 5555.65 lbs. |
| How much trunk (boot) space, 2009 Hyundai Santa Fe SUV? | 528 l 18.65 cu. ft. |
| How many gears, What type is the gearbox, 2009 Hyundai Santa Fe II (CM, facelift 2009) 2.2 CRDi (197 Hp)? | 6, manual transmission |
