| General information | |
|---|---|
| Brand | Hyundai |
| Model | Santa Fe |
| Generation | Santa Fe IV (TM, facelift 2020) |
| Type (Engine) | 2.5 Smartstream (277 Hp) DCT |
| Start of production | October, 2020 year |
| End of production | August, 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – combined | 9.4 l/100 km 25 US mpg 30.1 UK mpg 10.6 km/l |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | ULEV70 |
| Engine specs | |
| Power | 277 Hp @ 6000 rpm. |
| Power per litre | 110.9 Hp/l |
| Torque | 422 Nm @ 3500 rpm. 311.25 lb.-ft. @ 3500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Smartstream / G4KP |
| Engine displacement | 2497 cm3 152.38 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection and Multi-port manifold injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.8 l 6.13 US qt | 5.1 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.73 l 8.17 US qt | 6.8 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Trunk (boot) space – minimum | 1031 l 36.41 cu. ft. |
| Trunk (boot) space – maximum | 2042 l 72.11 cu. ft. |
| Fuel tank capacity | 71 l 18.76 US gal | 15.62 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 1588 kg 3500.94 lbs. |
| Permitted trailer load without brakes | 748 kg 1649.06 lbs. |
| Dimensions | |
| Length | 4785 mm 188.39 in. |
| Width | 1900 mm 74.8 in. |
| Height | 1709 mm 67.28 in. |
| Wheelbase | 2766 mm 108.9 in. |
| Front track | 1638-1646 mm 64.49 – 64.8 in. |
| Rear (Back) track | 1646-1656 mm 64.8 – 65.2 in. |
| Front overhang | 945 mm 37.2 in. |
| Rear overhang | 1074 mm 42.28 in. |
| Ride height (ground clearance) | 208 mm 8.19 in. |
| Drag coefficient (Cd) | 0.34 |
| Minimum turning circle (turning diameter) | 11.4 m 37.4 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission DCT |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs, 345.44 mm |
| Rear brakes | Disc, 304.8 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/55 R19; 255/45 R20 |
| Wheel rims size | 7.5J x 19; 8J x 20 |
| What is the body type, Hyundai Santa Fe IV (TM, facelift 2020)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Hyundai Santa Fe IV (TM, facelift 2020) 2.5 Smartstream (277 Hp) DCT? | 9.4 l/100 km 25 US mpg 30.1 UK mpg 10.6 km/l |
| How ECO is the car, Hyundai Santa Fe 2.5 Smartstream (277 Hp) DCT? | ULEV70 |
| How much power, Hyundai Santa Fe SUV 2020 2.5 Smartstream (277 Hp) DCT? | 277 Hp, 422 Nm 311.25 lb.-ft. |
| What is the engine size, Hyundai Santa Fe SUV 2020 2.5 Smartstream (277 Hp) DCT? | 2.5 l 2497 cm3 152.38 cu. in. |
| How many cylinders, 2020 Hyundai 2.5 Smartstream (277 Hp) DCT? | 4, Inline |
| What is the drivetrain, Hyundai Santa Fe IV (TM, facelift 2020) SUV 2020 2.5 Smartstream (277 Hp) DCT? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2020 Hyundai Santa Fe SUV? | 4785 mm 188.39 in. |
| How wide is the vehicle, 2020 Hyundai Santa Fe SUV? | 1900 mm 74.8 in. |
| How much trunk (boot) space, 2020 Hyundai Santa Fe SUV? | 1031 – 2042 l 36.41 – 72.11 cu. ft. |
| How many gears, What type is the gearbox, 2020 Hyundai Santa Fe IV (TM, facelift 2020) 2.5 Smartstream (277 Hp) DCT? | 8, automatic transmission DCT |
