| General information | |
|---|---|
| Brand | Hyundai |
| Model | Santa Fe |
| Generation | Santa Fe V (MX5) |
| Type (Engine) | 2.5 Smartstream (281 Hp) AWD DCT |
| Start of production | August, 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5-7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 11.4-12.2 l/100 km 20.6 – 19.3 US mpg 24.8 – 23.2 UK mpg 8.8 – 8.2 km/l |
| Fuel consumption (economy) – extra urban | 8.2-8.8 l/100 km 28.7 – 26.7 US mpg 34.4 – 32.1 UK mpg 12.2 – 11.4 km/l |
| Fuel consumption (economy) – combined | 9.9-10.6 l/100 km 23.8 – 22.2 US mpg 28.5 – 26.6 UK mpg 10.1 – 9.4 km/l |
| CO2 emissions | 168-181 g/km |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 6.6 kg/Hp, 151.1 Hp/tonne |
| Weight-to-torque ratio | 4.4 kg/Nm, 226.3 Nm/tonne |
| Engine specs | |
| Power | 281 Hp @ 5800 rpm. |
| Power per litre | 112.5 Hp/l |
| Torque | 421 Nm @ 1700-4000 rpm. 310.51 lb.-ft. @ 1700-4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Smartstream |
| Engine displacement | 2497 cm3 152.38 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1860-1985 kg 4100.6 – 4376.18 lbs. |
| Fuel tank capacity | 67 l 17.7 US gal | 14.74 UK gal |
| Dimensions | |
| Length | 4830 mm 190.16 in. |
| Width | 1900 mm 74.8 in. |
| Height | 1720-1780 mm 67.72 – 70.08 in. |
| Wheelbase | 2815 mm 110.83 in. |
| Front track | 1637-1646 mm 64.45 – 64.8 in. |
| Rear (Back) track | 1647-1656 mm 64.84 – 65.2 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission DCT |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/60 R18; 255/45 R20; 245/45 R21 |
| Wheel rims size | 18; 20; 21 |
| What is the body type, Hyundai Santa Fe V (MX5)? | SUV, 5 Doors, 5-7 Seats |
|---|---|
| What is the fuel economy, Hyundai Santa Fe V (MX5) 2.5 Smartstream (281 Hp) AWD DCT? | 9.9-10.6 l/100 km 23.8 – 22.2 US mpg 28.5 – 26.6 UK mpg 10.1 – 9.4 km/l |
| How ECO is the car, Hyundai Santa Fe 2.5 Smartstream (281 Hp) AWD DCT? | 168-181 g/km CO2 |
| How much power, Hyundai Santa Fe SUV 2023 2.5 Smartstream (281 Hp) AWD DCT? | 281 Hp, 421 Nm 310.51 lb.-ft. |
| What is the engine size, Hyundai Santa Fe SUV 2023 2.5 Smartstream (281 Hp) AWD DCT? | 2.5 l 2497 cm3 152.38 cu. in. |
| How many cylinders, 2023 Hyundai 2.5 Smartstream (281 Hp) AWD DCT? | 4, Inline |
| What is the drivetrain, Hyundai Santa Fe V (MX5) SUV 2023 2.5 Smartstream (281 Hp) AWD DCT? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2023 Hyundai Santa Fe SUV? | 4830 mm 190.16 in. |
| How wide is the vehicle, 2023 Hyundai Santa Fe SUV? | 1900 mm 74.8 in. |
| What is the curb weight, 2023 Hyundai Santa Fe V (MX5) 2.5 Smartstream (281 Hp) AWD DCT? | 1860-1985 kg 4100.6 – 4376.18 lbs. |
| How many gears, What type is the gearbox, 2023 Hyundai Santa Fe V (MX5) 2.5 Smartstream (281 Hp) AWD DCT? | 8, automatic transmission DCT |
