| General information | |
|---|---|
| Brand | iCAR |
| Model | 03 |
| Generation | 03T |
| Type (Engine) | 69.77 kWh (184 Hp) |
| Start of production | August, 2024 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Maximum speed | 150 km/h 93.21 mph |
| Weight-to-power ratio | 9.9 kg/Hp, 101.3 Hp/tonne |
| Weight-to-torque ratio | 8.3 kg/Nm, 121.1 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 69.77 kWh |
| Battery technology | Lithium iron phosphate (LiFePO4) |
| Battery location | Below the floor |
| All-electric range (CLTC) | 520 km 323.11 mi |
| Average Energy consumption (CLTC) | 15.5 kWh/100 km
24.94 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 184 Hp |
| Electric motor Torque | 220 Nm
162.26 lb.-ft. |
| Electric motor model/code | 112AA5 |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 184 Hp |
| System torque | 220 Nm 162.26 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1817 kg 4005.8 lbs. |
| Max. weight | 2212 kg 4876.63 lbs. |
| Max load | 395 kg 870.83 lbs. |
| Dimensions | |
| Length | 4380 mm 172.44 in. |
| Width | 1916 mm 75.43 in. |
| Height | 1741 mm 68.54 in. |
| Wheelbase | 2715 mm 106.89 in. |
| Front track | 1626 mm 64.02 in. |
| Rear (Back) track | 1645 mm 64.76 in. |
| Ride height (ground clearance) | 225 mm 8.86 in. |
| Minimum turning circle (turning diameter) | 11.4 m 37.4 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the rear wheels. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/55 R19 |
| Wheel rims size | 19 |
| What is the body type, iCAR 03T? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 69.77 kWh (184 Hp)? | 520 km 323.11 mi |
| What is electricity consumption, iCAR 03T 69.77 kWh (184 Hp)? | 15.5 kWh/100 km 24.94 kWh/100 mi 135 MPGe 6.5 km/kWh 4 mi/kWh |
| How fast is the car, 2024 03T 69.77 kWh (184 Hp)? | 150 km/h | 93.21 mph |
| How much power, iCAR 03 SUV 2024 69.77 kWh (184 Hp)? | 184 Hp, 220 Nm 162.26 lb.-ft. |
| What is the drivetrain, iCAR 03T SUV 2024 69.77 kWh (184 Hp)? | Rear wheel drive. BEV (Electric Vehicle). One electric motor drives the rear wheels. |
| How long is this vehicle, 2024 iCAR 03 SUV? | 4380 mm 172.44 in. |
| How wide is the vehicle, 2024 iCAR 03 SUV? | 1916 mm 75.43 in. |
| What is the curb weight, 2024 iCAR 03T 69.77 kWh (184 Hp)? | 1817 kg 4005.8 lbs. |
| What is the gross weight, 2024 iCAR 03T 69.77 kWh (184 Hp)? | 2212 kg 4876.63 lbs. |
| How many gears, What type is the gearbox, 2024 iCAR 03T 69.77 kWh (184 Hp)? | 1, automatic transmission |
