| General information | |
|---|---|
| Brand | iCAR |
| Model | V23 |
| Generation | V23 |
| Type (Engine) | 59.93 kWh (136 Hp) |
| Start of production | December, 2024 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Maximum speed | 140 km/h 86.99 mph |
| Weight-to-power ratio | 12.6 kg/Hp, 79.5 Hp/tonne |
| Weight-to-torque ratio | 9.5 kg/Nm, 105.3 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 59.93 kWh |
| Battery technology | Lithium iron phosphate (LiFePO4) |
| Battery location | Below the floor |
| All-electric range (CLTC) | 401 km 249.17 mi |
| Average Energy consumption (CLTC) | 16.8 kWh/100 km
27.04 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 136 Hp |
| Electric motor Torque | 180 Nm
132.76 lb.-ft. |
| Electric motor model/code | 112AB9 |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 136 Hp |
| System torque | 180 Nm 132.76 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1710 kg 3769.9 lbs. |
| Max. weight | 2085 kg 4596.64 lbs. |
| Max load | 375 kg 826.73 lbs. |
| Trunk (boot) space – minimum | 234 l 8.26 cu. ft. |
| Trunk (boot) space – maximum | 744 l 26.27 cu. ft. |
| Dimensions | |
| Length | 4220 mm 166.14 in. |
| Width | 1915 mm 75.39 in. |
| Height | 1845 mm 72.64 in. |
| Wheelbase | 2735 mm 107.68 in. |
| Front track | 1613 mm 63.5 in. |
| Rear (Back) track | 1641 mm 64.61 in. |
| Ride height (ground clearance) | 200 mm 7.87 in. |
| Approach angle | 42° |
| Departure angle | 40° |
| Wading depth | 600 mm 23.62 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the rear wheels. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 255/55 R19 |
| Wheel rims size | 19 |
| What is the body type, iCAR V23? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 59.93 kWh (136 Hp)? | 401 km 249.17 mi |
| What is electricity consumption, iCAR V23 59.93 kWh (136 Hp)? | 16.8 kWh/100 km 27.04 kWh/100 mi 125 MPGe 6 km/kWh 3.7 mi/kWh |
| How fast is the car, 2024 V23 59.93 kWh (136 Hp)? | 140 km/h | 86.99 mph |
| How much power, iCAR V23 SUV 2024 59.93 kWh (136 Hp)? | 136 Hp, 180 Nm 132.76 lb.-ft. |
| What is the drivetrain, iCAR V23 SUV 2024 59.93 kWh (136 Hp)? | Rear wheel drive. BEV (Electric Vehicle). One electric motor drives the rear wheels. |
| How long is this vehicle, 2024 iCAR V23 SUV? | 4220 mm 166.14 in. |
| How wide is the vehicle, 2024 iCAR V23 SUV? | 1915 mm 75.39 in. |
| What is the curb weight, 2024 iCAR V23 59.93 kWh (136 Hp)? | 1710 kg 3769.9 lbs. |
| What is the gross weight, 2024 iCAR V23 59.93 kWh (136 Hp)? | 2085 kg 4596.64 lbs. |
| How much trunk (boot) space, 2024 iCAR V23 SUV? | 234 – 744 l 8.26 – 26.27 cu. ft. |
| How many gears, What type is the gearbox, 2024 iCAR V23 59.93 kWh (136 Hp)? | 1, automatic transmission |
