| General information | |
|---|---|
| Brand | INEOS |
| Model | Grenadier |
| Generation | Grenadier Quartermaster |
| Type (Engine) | 3.0d Twin-Turbo (249 Hp) 4WD Automatic |
| Start of production | July, 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 10.9-12.1 l/100 km 21.6 – 19.4 US mpg 25.9 – 23.3 UK mpg 9.2 – 8.3 km/l |
| CO2 emissions (WLTP) | 286-317 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 9.9 sec |
| Acceleration 0 – 62 mph | 9.9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 9.4 sec |
| Maximum speed | 160 km/h 99.42 mph |
| Emission standard | Euro 6d |
| Weight-to-power ratio | 11 kg/Hp, 90.9 Hp/tonne |
| Weight-to-torque ratio | 5 kg/Nm, 200.7 Nm/tonne |
| Engine specs | |
| Power | 249 Hp @ 3250-4200 rpm. |
| Power per litre | 83.2 Hp/l |
| Torque | 550 Nm @ 1250-3000 rpm. 405.66 lb.-ft. @ 1250-3000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | BMW B57 |
| Engine displacement | 2993 cm3 182.64 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | Inline |
| Cylinder Bore | 84 mm 3.31 in. |
| Piston Stroke | 90 mm 3.54 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Twin-Turbo, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 7.5 l 7.93 US qt | 6.6 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2740 kg 6040.67 lbs. |
| Max. weight | 3500 kg 7716.18 lbs. |
| Max load | 760 kg 1675.51 lbs. |
| Fuel tank capacity | 90 l 23.78 US gal | 19.8 UK gal |
| AdBlue tank | 17 l 4.49 US gal | 3.74 UK gal |
| Max. roof load | 120 kg 264.55 lbs. |
| Permitted trailer load with brakes (12%) | 3500 kg 7716.18 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 350 kg 771.62 lbs. |
| Dimensions | |
| Length | 5440 mm 214.17 in. |
| Width | 1943 mm 76.5 in. |
| Width including mirrors | 2146 mm 84.49 in. |
| Height | 2019 mm 79.49 in. |
| Wheelbase | 3227 mm 127.05 in. |
| Front track | 1645 mm 64.76 in. |
| Rear (Back) track | 1645 mm 64.76 in. |
| Front overhang | 885 mm 34.84 in. |
| Rear overhang | 1328 mm 52.28 in. |
| Ride height (ground clearance) | 264 mm 10.39 in. |
| Minimum turning circle (turning diameter) | 14.5 m 47.57 ft. |
| Approach angle | 35.5° |
| Departure angle | 22.6° |
| Ramp-over (brakeover) angle | 26.2° |
| Climb angle | 45° |
| Wading depth | 800 mm 31.5 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission ZF |
| Front suspension | Coil spring, Rigid axle suspension, Transverse stabilizer |
| Rear suspension | Rigid axle suspension, Transverse stabilizer, Coil spring |
| Front brakes | Ventilated discs, 316 mm |
| Rear brakes | Disc, 305 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | 265/70 R17; 255/70 R18 |
| Wheel rims size | 17; 18 |
| What is the body type, INEOS Grenadier Quartermaster? | Pick-up, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, INEOS Grenadier Quartermaster 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 10.9-12.1 l/100 km 21.6 – 19.4 US mpg 25.9 – 23.3 UK mpg 9.2 – 8.3 km/l |
| How ECO is the car, INEOS Grenadier 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 286-317 g/km CO2 Euro 6d |
| How fast is the car, 2023 Grenadier Quartermaster 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 160 km/h | 99.42 mph 0-100 km/h: 9.9 sec 0-60 mph: 9.4 sec |
| How much power, INEOS Grenadier Pick-up 2023 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 249 Hp, 550 Nm 405.66 lb.-ft. |
| What is the engine size, INEOS Grenadier Pick-up 2023 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 3.0 l 2993 cm3 182.64 cu. in. |
| How many cylinders, 2023 INEOS 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 6, Inline |
| What is the drivetrain, INEOS Grenadier Quartermaster Pick-up 2023 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| How long is this vehicle, 2023 INEOS Grenadier Pick-up? | 5440 mm 214.17 in. |
| How wide is the vehicle, 2023 INEOS Grenadier Pick-up? | 1943 mm 76.5 in. |
| What is the curb weight, 2023 INEOS Grenadier Quartermaster 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 2740 kg 6040.67 lbs. |
| What is the gross weight, 2023 INEOS Grenadier Quartermaster 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 3500 kg 7716.18 lbs. |
| How many gears, What type is the gearbox, 2023 INEOS Grenadier Quartermaster 3.0d Twin-Turbo (249 Hp) 4WD Automatic? | 8, automatic transmission ZF |
