| General information | |
|---|---|
| Brand | Isuzu |
| Model | MU-X |
| Generation | MU-X (RF10) |
| Type (Engine) | 3.0d (177 Hp) 4×4 Automatic |
| Start of production | 2013 year |
| End of production | 2017 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 10.7-10.8 l/100 km 22 – 21.8 US mpg 26.4 – 26.2 UK mpg 9.3 – 9.3 km/l |
| Fuel consumption (economy) – extra urban | 7.0-7.1 l/100 km 33.6 – 33.1 US mpg 40.4 – 39.8 UK mpg 14.3 – 14.1 km/l |
| Fuel consumption (economy) – combined | 8.4 l/100 km 28 US mpg 33.6 UK mpg 11.9 km/l |
| CO2 emissions | 221-223 g/km |
| Fuel Type | Diesel |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 11.2 kg/Hp, 89.2 Hp/tonne |
| Weight-to-torque ratio | 5.2 kg/Nm, 191.4 Nm/tonne |
| Engine specs | |
| Power | 177 Hp @ 3600 rpm. |
| Power per litre | 59 Hp/l |
| Torque | 380 Nm @ 1800-2800 rpm. 280.27 lb.-ft. @ 1800-2800 rpm. |
| Engine Model/Code | 4JJ1-TC |
| Engine displacement | 2999 cm3 183.01 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 95.4 mm 3.76 in. |
| Piston Stroke | 104.9 mm 4.13 in. |
| Compression ratio | 17.3:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6.9 l 7.29 US qt | 6.07 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 11.1 l 11.73 US qt | 9.77 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1985-2060 kg 4376.18 – 4541.52 lbs. |
| Max. weight | 2750 kg 6062.71 lbs. |
| Max load | 690-765 kg 1521.19 – 1686.54 lbs. |
| Trunk (boot) space – minimum | 235 l 8.3 cu. ft. |
| Trunk (boot) space – maximum | 1830 l 64.63 cu. ft. |
| Fuel tank capacity | 65 l 17.17 US gal | 14.3 UK gal |
| Permitted trailer load with brakes (12%) | 3000 kg 6613.87 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4825 mm 189.96 in. |
| Width | 1860 mm 73.23 in. |
| Height | 1825-1860 mm 71.85 – 73.23 in. |
| Wheelbase | 2845 mm 112.01 in. |
| Front track | 1570 mm 61.81 in. |
| Rear (Back) track | 1570 mm 61.81 in. |
| Front overhang | 905 mm 35.63 in. |
| Rear overhang | 1075 mm 42.32 in. |
| Ride height (ground clearance) | 220-230 mm 8.66 – 9.06 in. |
| Minimum turning circle (turning diameter) | 11.6 m 38.06 ft. |
| Approach angle | 29.5-30.1° |
| Departure angle | 24.6-25.1° |
| Ramp-over (brakeover) angle | 21.9-22.6° |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, automatic transmission Rev-Tronic |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 245/70 R16; 255/65 R17 |
| Wheel rims size | 7J x 16; 7J x 17 |
| What is the body type, Isuzu MU-X (RF10)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Isuzu MU-X (RF10) 3.0d (177 Hp) 4×4 Automatic? | 8.4 l/100 km 28 US mpg 33.6 UK mpg 11.9 km/l |
| How ECO is the car, Isuzu MU-X 3.0d (177 Hp) 4×4 Automatic? | 221-223 g/km CO2 Euro 4 |
| How much power, Isuzu MU-X SUV 2013 3.0d (177 Hp) 4×4 Automatic? | 177 Hp, 380 Nm 280.27 lb.-ft. |
| What is the engine size, Isuzu MU-X SUV 2013 3.0d (177 Hp) 4×4 Automatic? | 3.0 l 2999 cm3 183.01 cu. in. |
| How many cylinders, 2013 Isuzu 3.0d (177 Hp) 4×4 Automatic? | 4, Inline |
| What is the drivetrain, Isuzu MU-X (RF10) SUV 2013 3.0d (177 Hp) 4×4 Automatic? | All wheel drive (4×4). Internal Combustion engine. |
| How long is this vehicle, 2013 Isuzu MU-X SUV? | 4825 mm 189.96 in. |
| How wide is the vehicle, 2013 Isuzu MU-X SUV? | 1860 mm 73.23 in. |
| What is the curb weight, 2013 Isuzu MU-X (RF10) 3.0d (177 Hp) 4×4 Automatic? | 1985-2060 kg 4376.18 – 4541.52 lbs. |
| What is the gross weight, 2013 Isuzu MU-X (RF10) 3.0d (177 Hp) 4×4 Automatic? | 2750 kg 6062.71 lbs. |
| How much trunk (boot) space, 2013 Isuzu MU-X SUV? | 235 – 1830 l 8.3 – 64.63 cu. ft. |
| How many gears, What type is the gearbox, 2013 Isuzu MU-X (RF10) 3.0d (177 Hp) 4×4 Automatic? | 5, automatic transmission Rev-Tronic |
