| General information | |
|---|---|
| Brand | Jaguar |
| Model | I-Pace |
| Generation | I-Pace (facelift 2023) |
| Type (Engine) | EV400 90 kWh (400 Hp) AWD |
| Start of production | January, 2023 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV, Crossover |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 4.8 sec |
| Acceleration 0 – 62 mph | 4.8 sec |
| Acceleration 0 – 60 mph | 4.5 sec |
| Maximum speed | 200 km/h 124.27 mph |
| Weight-to-power ratio | 5.3 kg/Hp, 187.5 Hp/tonne |
| Weight-to-torque ratio | 3.1 kg/Nm, 326.3 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 90 kWh |
| Net (usable) battery capacity | 84.7 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 408-470 km 253.52 – 292.04 mi |
| Average Energy consumption (WLTP) | 22-25.2 kWh/100 km
35.41 – 40.56 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 200 Hp |
| Electric motor Torque | 348 Nm
256.67 lb.-ft. |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor power | 200 Hp |
| Electric motor Torque | 348 Nm
256.67 lb.-ft. |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 400 Hp |
| System torque | 696 Nm 513.34 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2133 kg 4702.46 lbs. |
| Max. weight | 2670 kg 5886.34 lbs. |
| Max load | 537 kg 1183.88 lbs. |
| Trunk (boot) space – minimum | 656 l 23.17 cu. ft. |
| Trunk (boot) space – maximum | 1453 l 51.31 cu. ft. |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 750 kg 1653.47 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 45 kg 99.21 lbs. |
| Dimensions | |
| Length | 4682 mm 184.33 in. |
| Width with mirrors folded | 2011 mm 79.17 in. |
| Width including mirrors | 2139 mm 84.21 in. |
| Height | 1566 mm 61.65 in. |
| Wheelbase | 2990 mm 117.72 in. |
| Front track | 1641-1643 mm 64.61 – 64.69 in. |
| Rear (Back) track | 1660-1662 mm 65.35 – 65.43 in. |
| Ride height (ground clearance) | 174 mm 6.85 in. |
| Drag coefficient (Cd) | 0.29 |
| Minimum turning circle (turning diameter) | 12.75 m 41.83 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Double wishbone, Air Suspension – Optional |
| Rear suspension | Independent multi-link suspension, Air Suspension – Optional |
| Front brakes | Ventilated discs, 350 mm |
| Rear brakes | Ventilated discs, 325 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Wheel rims size | 18; 19; 20; 22 |
| What is the body type, Jaguar I-Pace (facelift 2023)? | SUV, Crossover, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, EV400 90 kWh (400 Hp) AWD? | 408-470 km 253.52 – 292.04 mi |
| What is electricity consumption, Jaguar I-Pace (facelift 2023) EV400 90 kWh (400 Hp) AWD? | 22-25.2 kWh/100 km 35.41 – 40.56 kWh/100 mi 95 – 83 MPGe 4.5 – 4 km/kWh 2.8 – 2.5 mi/kWh |
| How fast is the car, 2023 I-Pace (facelift 2023) EV400 90 kWh (400 Hp) AWD? | 200 km/h | 124.27 mph 0-100 km/h: 4.8 sec 0-60 mph: 4.5 sec |
| How much power, Jaguar I-Pace SUV, Crossover 2023 EV400 90 kWh (400 Hp) AWD? | 400 Hp, 696 Nm 513.34 lb.-ft. |
| What is the drivetrain, Jaguar I-Pace (facelift 2023) SUV, Crossover 2023 EV400 90 kWh (400 Hp) AWD? | All wheel drive (4×4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| How long is this vehicle, 2023 Jaguar I-Pace SUV, Crossover? | 4682 mm 184.33 in. |
| How wide is the vehicle, 2023 Jaguar I-Pace SUV, Crossover? | 2011 mm 79.17 in. |
| What is the curb weight, 2023 Jaguar I-Pace (facelift 2023) EV400 90 kWh (400 Hp) AWD? | 2133 kg 4702.46 lbs. |
| What is the gross weight, 2023 Jaguar I-Pace (facelift 2023) EV400 90 kWh (400 Hp) AWD? | 2670 kg 5886.34 lbs. |
| How much trunk (boot) space, 2023 Jaguar I-Pace SUV, Crossover? | 656 – 1453 l 23.17 – 51.31 cu. ft. |
| How many gears, What type is the gearbox, 2023 Jaguar I-Pace (facelift 2023) EV400 90 kWh (400 Hp) AWD? | 1, automatic transmission |
