| General information | |
|---|---|
| Brand | Jaguar |
| Model | XF |
| Generation | XF (X250) |
| Type (Engine) | R 5.0 V8 (510 Hp) Automatic |
| Start of production | 2009 year |
| End of production | 2011 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 18.7 l/100 km 12.6 US mpg 15.1 UK mpg 5.3 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 8.7 l/100 km 27 US mpg 32.5 UK mpg 11.5 km/l |
| Fuel consumption (economy) – combined (NEDC) | 12.5 l/100 km 18.8 US mpg 22.6 UK mpg 8 km/l |
| CO2 emissions (NEDC) | 292 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 4.9 sec |
| Acceleration 0 – 62 mph | 4.9 sec |
| Acceleration 0 – 60 mph | 4.7 sec |
| Maximum speed | 250 km/h, Electronically limited 155.34 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 3.7 kg/Hp, 269.7 Hp/tonne |
| Weight-to-torque ratio | 3 kg/Nm, 330.5 Nm/tonne |
| Engine specs | |
| Power | 510 Hp @ 6000-6500 rpm. |
| Power per litre | 102 Hp/l |
| Torque | 625 Nm @ 2500-5000 rpm. 460.98 lb.-ft. @ 2500-5000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | AJ133S, 508PS |
| Engine displacement | 5000 cm3 305.12 cu. in. |
| Number of cylinders | 8 |
| Engine configuration | V-engine |
| Cylinder Bore | 92.5 mm 3.64 in. |
| Piston Stroke | 93 mm 3.66 in. |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Supercharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 7.25 l 7.66 US qt | 6.38 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 12.3 l 13 US qt | 10.82 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1891 kg 4168.94 lbs. |
| Max. weight | 2330 kg 5136.77 lbs. |
| Max load | 439 kg 967.83 lbs. |
| Trunk (boot) space – minimum | 500 l 17.66 cu. ft. |
| Trunk (boot) space – maximum | 923 l 32.6 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| Permitted trailer load with brakes (12%) | 1850 kg 4078.55 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4961 mm 195.31 in. |
| Width | 1877 mm 73.9 in. |
| Width including mirrors | 2053 mm 80.83 in. |
| Height | 1460 mm 57.48 in. |
| Wheelbase | 2909 mm 114.53 in. |
| Front track | 1559 mm 61.38 in. |
| Rear (Back) track | 1571 mm 61.85 in. |
| Drag coefficient (Cd) | 0.29 |
| Minimum turning circle (turning diameter) | 11.48 m 37.66 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission |
| Front suspension | Coil spring, Double wishbone, Transverse stabilizer |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | Front wheel tires: 255/35 R20 Rear wheel tires: 285/30 R20 |
| Wheel rims size | Front wheel rims: 8.5J x 20 Rear wheel rims: 9.5J x 20 |
| What is the body type, Jaguar XF (X250)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Jaguar XF (X250) R 5.0 V8 (510 Hp) Automatic? | 12.5 l/100 km 18.8 US mpg 22.6 UK mpg 8 km/l |
| How ECO is the car, Jaguar XF R 5.0 V8 (510 Hp) Automatic? | 292 g/km CO2 Euro 5 |
| How fast is the car, 2009 XF (X250) R 5.0 V8 (510 Hp) Automatic? | 250 km/h | 155.34 mph 0-100 km/h: 4.9 sec 0-60 mph: 4.7 sec |
| How much power, Jaguar XF Sedan 2009 R 5.0 V8 (510 Hp) Automatic? | 510 Hp, 625 Nm 460.98 lb.-ft. |
| What is the engine size, Jaguar XF Sedan 2009 R 5.0 V8 (510 Hp) Automatic? | 5.0 l 5000 cm3 305.12 cu. in. |
| How many cylinders, 2009 Jaguar R 5.0 V8 (510 Hp) Automatic? | 8, V-engine |
| What is the drivetrain, Jaguar XF (X250) Sedan 2009 R 5.0 V8 (510 Hp) Automatic? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2009 Jaguar XF Sedan? | 4961 mm 195.31 in. |
| How wide is the vehicle, 2009 Jaguar XF Sedan? | 1877 mm 73.9 in. |
| What is the curb weight, 2009 Jaguar XF (X250) R 5.0 V8 (510 Hp) Automatic? | 1891 kg 4168.94 lbs. |
| What is the gross weight, 2009 Jaguar XF (X250) R 5.0 V8 (510 Hp) Automatic? | 2330 kg 5136.77 lbs. |
| How much trunk (boot) space, 2009 Jaguar XF Sedan? | 500 – 923 l 17.66 – 32.6 cu. ft. |
| How many gears, What type is the gearbox, 2009 Jaguar XF (X250) R 5.0 V8 (510 Hp) Automatic? | 6, automatic transmission |
