The Jaguar XF (X260) 2.0 (300 Hp) AWD Automatic represents a significant step in the evolution of Jaguar’s mid-size luxury sedan. Produced for a relatively short period, from 2017 to 2018, this variant occupied a key position within the X260 generation, offering a blend of performance, technology, and all-weather capability. It was positioned as a premium offering, bridging the gap between the base 2.0-liter models and the higher-performance supercharged variants. The X260 generation itself marked a departure from the previous XF, utilizing an aluminum-intensive construction to reduce weight and improve efficiency, while maintaining Jaguar’s reputation for dynamic handling and luxurious interiors.
Technical Specifications
| Brand | Jaguar |
| Model | XF |
| Generation | XF (X260) |
| Type (Engine) | 2.0 (300 Hp) AWD Automatic |
| Start of production | 2017 |
| End of production | 2018 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Fuel consumption (combined) | 7.2 l/100 km |
| Fuel consumption (US mpg) | 32.7 US mpg |
| Fuel consumption (UK mpg) | 39.2 UK mpg |
| Fuel consumption (km/l) | 13.9 km/l |
| CO2 emissions | 163 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 5.8 sec |
| Acceleration 0 – 62 mph | 5.8 sec |
| Acceleration 0 – 60 mph | 5.5 sec |
| Maximum speed | 250 km/h (155.34 mph) |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 5.7 kg/Hp |
| Weight-to-torque ratio | 4.3 kg/Nm |
| Power | 300 Hp @ 5500 rpm |
| Power per litre | 150.2 Hp/l |
| Torque | 400 Nm @ 1500-4500 rpm (295.02 lb.-ft. @ 1500-4500 rpm) |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | Ingenium / PT204 |
| Engine displacement | 1997 cm3 (121.86 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 83 mm (3.27 in.) |
| Piston Stroke | 92.4 mm (3.64 in.) |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Twin-Turbo, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 7 l (7.4 US qt | 6.16 UK qt) |
| Kerb Weight | 1715 kg (3780.93 lbs.) |
| Trunk (boot) space – minimum | 540 l (19.07 cu. ft.) |
| Fuel tank capacity | 74 l (19.55 US gal | 16.28 UK gal) |
| Length | 4954 mm (195.04 in.) |
| Width | 1987 mm (78.23 in.) |
| Width including mirrors | 2091 mm (82.32 in.) |
| Height | 1457 mm (57.36 in.) |
| Wheelbase | 2960 mm (116.54 in.) |
| Front track | 1605 mm (63.19 in.) |
| Rear (Back) track | 1594 mm (62.76 in.) |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Independent coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
Powertrain & Engine Architecture
At the heart of the XF 2.0 AWD Automatic lies Jaguar Land Rover’s Ingenium engine family, specifically the PT204 2.0-liter turbocharged inline-four. This engine is a modern design, featuring direct injection, a twin-scroll turbocharger, and variable valve timing. The twin-turbo setup provides a broad torque curve, delivering 400 Nm (295 lb-ft) of torque from as low as 1500 rpm and sustaining it through 4500 rpm. This characteristic makes the engine responsive in everyday driving situations. The engine’s aluminum block and head contribute to its relatively lightweight construction. The engine is paired with a ZF-sourced eight-speed automatic transmission, known for its smooth shifts and efficiency. The all-wheel-drive system utilizes a multi-plate clutch to distribute torque between the front and rear axles, enhancing traction and stability, particularly in adverse weather conditions.
Driving Characteristics
The 300 horsepower and all-wheel-drive configuration of this XF variant deliver a compelling driving experience. Acceleration from 0 to 60 mph is achieved in approximately 5.5 seconds, making it a genuinely quick sedan. The eight-speed automatic transmission is well-tuned, providing seamless gear changes and contributing to the car’s overall refinement. While not as overtly sporty as the supercharged XF models, the 2.0-liter AWD offers a good balance between performance and comfort. The gear ratios are optimized for both acceleration and fuel efficiency. Compared to the rear-wheel-drive versions of the XF 2.0, the AWD model offers enhanced grip and stability, particularly on slippery surfaces. However, the added weight of the AWD system does slightly impact fuel economy and agility.
Equipment & Trim Levels
The XF 2.0 AWD Automatic typically came well-equipped, reflecting its position as a premium trim level. Standard features included leather upholstery, a touchscreen infotainment system with navigation, automatic climate control, and a suite of safety technologies such as lane departure warning and automatic emergency braking. Optional extras included a panoramic sunroof, upgraded sound system, adaptive cruise control, and various interior trim options. The interior design emphasized luxury and sophistication, with high-quality materials and a driver-focused layout. The dashboard featured a combination of analog gauges and digital displays, providing the driver with essential information.
Chassis & Braking
The XF X260 utilizes a double wishbone front suspension and an independent coil spring rear suspension, providing a comfortable yet controlled ride. The suspension is tuned to balance handling and ride quality, offering a good compromise between sportiness and comfort. The car is equipped with ventilated disc brakes on all four wheels, providing ample stopping power. The electronic stability control system and anti-lock braking system (ABS) work together to enhance safety and stability. The steering is electrically assisted, providing a precise and responsive feel.
Market Reception & Comparison
The Jaguar XF 2.0 AWD Automatic was generally well-received by automotive critics. It was praised for its refined interior, comfortable ride, and strong performance. The all-wheel-drive system was seen as a valuable addition, particularly in regions with inclement weather. Compared to the higher-output supercharged XF models, the 2.0-liter AWD offered a more affordable entry point into the XF range, while still providing a luxurious and enjoyable driving experience. Fuel economy was considered competitive for its class, although not class-leading. Reliability reports have been generally positive, with the Ingenium engine proving to be a robust and dependable unit.
Legacy
The Jaguar XF 2.0 AWD Automatic represents a significant step forward in Jaguar’s engineering and design. The Ingenium engine family has become a cornerstone of Jaguar Land Rover’s powertrain strategy, and the X260 generation helped to establish the XF as a credible competitor in the mid-size luxury sedan segment. On the used car market, these models continue to be sought after for their blend of performance, luxury, and reliability. The relatively short production run of this specific variant may contribute to its collectibility in the future. Regular maintenance, including oil changes and adherence to Jaguar’s recommended service intervals, is crucial for ensuring the long-term reliability of this powertrain.
