| General information | |
|---|---|
| Brand | KGM |
| Model | Musso |
| Generation | Musso |
| Type (Engine) | 2.2 e-XDi 220 (202 Hp) 4WD |
| Start of production | 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Pick-up |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption at Low speed (WLTP) | 9.2-9.9 l/100 km 25.6 – 23.8 US mpg 30.7 – 28.5 UK mpg 10.9 – 10.1 km/l |
| Fuel consumption at Medium speed (WLTP) | 7.5-8 l/100 km 31.4 – 29.4 US mpg 37.7 – 35.3 UK mpg 13.3 – 12.5 km/l |
| Fuel consumption at high speed (WLTP) | 7-7.3 l/100 km 33.6 – 32.2 US mpg 40.4 – 38.7 UK mpg 14.3 – 13.7 km/l |
| Fuel consumption at very high speed (WLTP) | 8.8-9.1 l/100 km 26.7 – 25.8 US mpg 32.1 – 31 UK mpg 11.4 – 11 km/l |
| Combined fuel consumption (WLTP) | 8-8.5 l/100 km 29.4 – 27.7 US mpg 35.3 – 33.2 UK mpg 12.5 – 11.8 km/l |
| CO2 emissions (WLTP) | 211-223 g/km |
| Fuel Type | Diesel |
| Maximum speed | 177 km/h 109.98 mph |
| Emission standard | Euro 6d |
| Weight-to-power ratio | 10.2 kg/Hp, 97.6 Hp/tonne |
| Weight-to-torque ratio | 5.2 kg/Nm, 193.2 Nm/tonne |
| Engine specs | |
| Power | 202 Hp @ 3800 rpm. |
| Power per litre | 93.6 Hp/l |
| Torque | 400 Nm @ 1400-2800 rpm. 295.02 lb.-ft. @ 1400-2800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | D22DTR |
| Engine displacement | 2157 cm3 131.63 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 86.2 mm 3.39 in. |
| Piston Stroke | 92.4 mm 3.64 in. |
| Compression ratio | 15.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6 l 6.34 US qt | 5.28 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 10.2 l 10.78 US qt | 8.97 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2070-2155 kg 4563.57 – 4750.96 lbs. |
| Max. weight | 2940-3250 kg 6481.59 – 7165.02 lbs. |
| Max load | 870-1095 kg 1918.02 – 2414.06 lbs. |
| Fuel tank capacity | 75 l 19.81 US gal | 16.5 UK gal |
| AdBlue tank | 25 l 6.6 US gal | 5.5 UK gal |
| Permitted trailer load with brakes (12%) | 3200 kg 7054.79 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 120 kg 264.55 lbs. |
| Dimensions | |
| Length | 5095 mm 200.59 in. |
| Width | 1950 mm 76.77 in. |
| Height | 1870 mm 73.62 in. |
| Wheelbase | 3100 mm 122.05 in. |
| Front track | 1620-1640 mm 63.78 – 64.57 in. |
| Rear (Back) track | 1620-1640 mm 63.78 – 64.57 in. |
| Front overhang | 890 mm 35.04 in. |
| Rear overhang | 1105 mm 43.5 in. |
| Ride height (ground clearance) | 215 mm 8.46 in. |
| Minimum turning circle (turning diameter) | 11.82 m 38.78 ft. |
| Approach angle | 20° |
| Departure angle | 20.3° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Coil spring, Double wishbone |
| Rear suspension | Rigid axle suspension, Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 235/70 R17; 255/60 R18; 255/50 R20 |
| Wheel rims size | 7J x 17; 7.5J x 18; 8J x 20 |
| What is the body type, KGM Musso? | Pick-up, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, KGM Musso 2.2 e-XDi 220 (202 Hp) 4WD? | 8-8.5 l/100 km 29.4 – 27.7 US mpg 35.3 – 33.2 UK mpg 12.5 – 11.8 km/l |
| How ECO is the car, KGM Musso 2.2 e-XDi 220 (202 Hp) 4WD? | 211-223 g/km CO2 Euro 6d |
| How fast is the car, 2023 Musso 2.2 e-XDi 220 (202 Hp) 4WD? | 177 km/h | 109.98 mph |
| How much power, KGM Musso Pick-up 2023 2.2 e-XDi 220 (202 Hp) 4WD? | 202 Hp, 400 Nm 295.02 lb.-ft. |
| What is the engine size, KGM Musso Pick-up 2023 2.2 e-XDi 220 (202 Hp) 4WD? | 2.2 l 2157 cm3 131.63 cu. in. |
| How many cylinders, 2023 KGM 2.2 e-XDi 220 (202 Hp) 4WD? | 4, Inline |
| What is the drivetrain, KGM Musso Pick-up 2023 2.2 e-XDi 220 (202 Hp) 4WD? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2023 KGM Musso Pick-up? | 5095 mm 200.59 in. |
| How wide is the vehicle, 2023 KGM Musso Pick-up? | 1950 mm 76.77 in. |
| What is the curb weight, 2023 KGM Musso 2.2 e-XDi 220 (202 Hp) 4WD? | 2070-2155 kg 4563.57 – 4750.96 lbs. |
| What is the gross weight, 2023 KGM Musso 2.2 e-XDi 220 (202 Hp) 4WD? | 2940-3250 kg 6481.59 – 7165.02 lbs. |
| How many gears, What type is the gearbox, 2023 KGM Musso 2.2 e-XDi 220 (202 Hp) 4WD? | 6, manual transmission |
