| General information | |
|---|---|
| Brand | Kia |
| Model | Carens |
| Generation | Carens III (facelift 2016) |
| Type (Engine) | 1.6 GDI (135 Hp) 7 Seat |
| Start of production | 2016 year |
| End of production | 2019 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | MPV |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 7.8-8.3 l/100 km 30.2 – 28.3 US mpg 36.2 – 34 UK mpg 12.8 – 12 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 5.2-5.4 l/100 km 45.2 – 43.6 US mpg 54.3 – 52.3 UK mpg 19.2 – 18.5 km/l |
| Fuel consumption (economy) – combined (NEDC) | 6.2-6.5 l/100 km 37.9 – 36.2 US mpg 45.6 – 43.5 UK mpg 16.1 – 15.4 km/l |
| CO2 emissions (NEDC) | 143-150 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 11.3 sec |
| Acceleration 0 – 62 mph | 11.3 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 10.7 sec |
| Maximum speed | 185 km/h 114.95 mph |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 10.4 kg/Hp, 95.9 Hp/tonne |
| Weight-to-torque ratio | 8.5 kg/Nm, 117.2 Nm/tonne |
| Engine specs | |
| Power | 135 Hp @ 6300 rpm. |
| Power per litre | 84.9 Hp/l |
| Torque | 165 Nm @ 4850 rpm. 121.7 lb.-ft. @ 4850 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | G4FD |
| Engine displacement | 1591 cm3 97.09 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 77 mm 3.03 in. |
| Piston Stroke | 85.4 mm 3.36 in. |
| Compression ratio | 11:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 3.6 l 3.8 US qt | 3.17 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6.2 l 6.55 US qt | 5.46 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1408-1531 kg 3104.11 – 3375.28 lbs. |
| Max. weight | 2140 kg 4717.89 lbs. |
| Max load | 609-732 kg 1342.62 – 1613.78 lbs. |
| Trunk (boot) space – minimum | 103 l 3.64 cu. ft. |
| Trunk (boot) space – maximum | 1650 l 58.27 cu. ft. |
| Fuel tank capacity | 58 l 15.32 US gal | 12.76 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 1300 kg 2866.01 lbs. |
| Permitted trailer load without brakes | 730 kg 1609.37 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4525 mm 178.15 in. |
| Width | 1805 mm 71.06 in. |
| Height | 1610 mm 63.39 in. |
| Wheelbase | 2750 mm 108.27 in. |
| Front track | 1569-1573 mm 61.77 – 61.93 in. |
| Rear (Back) track | 1582-1586 mm 62.28 – 62.44 in. |
| Front overhang | 940 mm 37.01 in. |
| Rear overhang | 835 mm 32.87 in. |
| Minimum turning circle (turning diameter) | 11 m 36.09 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs, 300 mm |
| Rear brakes | Disc, 284 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/55 R16 91V; 225/45 R17 91V |
| Wheel rims size | 6.5J x 16 ET48.5; 7.0J x 17 ET50.5 |
| What is the body type, Kia Carens III (facelift 2016)? | MPV, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Kia Carens III (facelift 2016) 1.6 GDI (135 Hp) 7 Seat? | 6.2-6.5 l/100 km 37.9 – 36.2 US mpg 45.6 – 43.5 UK mpg 16.1 – 15.4 km/l |
| How ECO is the car, Kia Carens 1.6 GDI (135 Hp) 7 Seat? | 143-150 g/km CO2 Euro 6 |
| How fast is the car, 2016 Carens III (facelift 2016) 1.6 GDI (135 Hp) 7 Seat? | 185 km/h | 114.95 mph 0-100 km/h: 11.3 sec 0-60 mph: 10.7 sec |
| How much power, Kia Carens MPV 2016 1.6 GDI (135 Hp) 7 Seat? | 135 Hp, 165 Nm 121.7 lb.-ft. |
| What is the engine size, Kia Carens MPV 2016 1.6 GDI (135 Hp) 7 Seat? | 1.6 l 1591 cm3 97.09 cu. in. |
| How many cylinders, 2016 Kia 1.6 GDI (135 Hp) 7 Seat? | 4, Inline |
| What is the drivetrain, Kia Carens III (facelift 2016) MPV 2016 1.6 GDI (135 Hp) 7 Seat? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2016 Kia Carens MPV? | 4525 mm 178.15 in. |
| How wide is the vehicle, 2016 Kia Carens MPV? | 1805 mm 71.06 in. |
| What is the curb weight, 2016 Kia Carens III (facelift 2016) 1.6 GDI (135 Hp) 7 Seat? | 1408-1531 kg 3104.11 – 3375.28 lbs. |
| What is the gross weight, 2016 Kia Carens III (facelift 2016) 1.6 GDI (135 Hp) 7 Seat? | 2140 kg 4717.89 lbs. |
| How much trunk (boot) space, 2016 Kia Carens MPV? | 103 – 1650 l 3.64 – 58.27 cu. ft. |
| How many gears, What type is the gearbox, 2016 Kia Carens III (facelift 2016) 1.6 GDI (135 Hp) 7 Seat? | 6, manual transmission |
