2018-2021 Kia Cerato IV Sedan 2.0 MPI (152 Hp) Automatic

Technical Specifications

Brand Kia
Model Cerato
Generation Cerato IV Sedan
Type (Engine) 2.0 MPI (152 Hp) Automatic
Start of production January, 2018
End of production May, 2021
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Fuel consumption (urban) 10.2 l/100 km (23.1 US mpg)
Fuel consumption (extra urban) 5.7 l/100 km (41.3 US mpg)
Fuel consumption (combined) 7.4 l/100 km (31.8 US mpg)
CO2 emissions 167 g/km
Fuel Type Petrol (Gasoline)
Emission standard Euro 5
Weight-to-power ratio 8.7 kg/Hp
Weight-to-torque ratio 6.9 kg/Nm
Power 152 Hp @ 6200 rpm
Torque 192 Nm @ 4000 rpm (141.61 lb.-ft. @ 4000 rpm)
Engine layout Front, Transverse
Engine Model/Code Nu / G4NH
Engine displacement 1999 cm3 (121.99 cu. in.)
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm (3.19 in.)
Piston Stroke 97 mm (3.82 in.)
Compression ratio 10.3:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, D-CVVT
Engine oil capacity 4 l (4.23 US qt | 3.52 UK qt)
Coolant 5.4 l (5.71 US qt | 4.75 UK qt)
Kerb Weight 1320 kg (2910.1 lbs.)
Trunk (boot) space (minimum) 502 l (17.73 cu. ft.)
Fuel tank capacity 50 l (13.21 US gal | 11 UK gal)
Permitted trailer load with brakes (12%) 1100 kg (2425.08 lbs.)
Permitted trailer load without brakes 610 kg (1344.82 lbs.)
Permitted towbar download 75 kg (165.35 lbs.)
Length 4640 mm (182.68 in.)
Width 1800 mm (70.87 in.)
Height 1440 mm (56.69 in.)
Wheelbase 2700 mm (106.3 in.)
Ride height (ground clearance) 150 mm (5.91 in.)
Minimum turning circle 10.6 m (34.78 ft.)
Drivetrain Architecture Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Independent type McPherson
Rear suspension Torsion
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/45 R17
Wheel rims size 17

The Kia Cerato IV Sedan 2.0 MPI (152 Hp) Automatic, produced from January 2018 to May 2021, represents a key variant within the fourth generation (BD) of the Cerato, also known as the K3 in select international markets. This model was specifically tailored for the North American market, aiming to deliver a blend of fuel efficiency, comfortable driving characteristics, and contemporary features. Positioned as a mid-range offering in the Cerato IV lineup, it bridged the gap between the more economical base engine and potentially more performance-focused trims. The Cerato IV was designed to attract a wide range of buyers seeking a dependable and well-equipped family sedan.

Powertrain & Engine Architecture

The core of the Cerato IV 2.0 MPI Automatic is the Kia Nu engine, designated as the G4NH code. This 2.0-liter inline-four cylinder engine is a naturally aspirated design employing multi-point fuel injection. The Nu engine family is recognized for its relatively uncomplicated construction, which contributes to its overall reliability. The engine incorporates a double overhead camshaft (DOHC) valvetrain coupled with Kia’s Dual Continuously Variable Valve Timing (D-CVVT) system. D-CVVT dynamically adjusts valve timing based on engine load and speed, enhancing both fuel economy and power output. Working in conjunction with this engine is a conventional six-speed automatic transmission. While not offering the rapid shifts of dual-clutch transmissions, this transmission provides smooth and predictable gear changes ideal for everyday driving. The transmission’s tuning prioritizes comfort and fuel efficiency over aggressive performance.

Driving Characteristics

The 152 horsepower and 192 Nm (141.61 lb-ft) of torque generated by the 2.0L engine and six-speed automatic pairing results in adequate, though not particularly sporty, performance. Acceleration from 0 to 60 mph is estimated to be in the 9-10 second range. The automatic transmission’s gear ratios are geared towards fuel efficiency, meaning that while it provides sufficient power for highway merging and passing maneuvers, it lacks the aggressive downshifts and quick acceleration found in higher-performance trims. Compared to a Cerato IV equipped with a manual transmission, the automatic version feels somewhat less responsive. However, the automatic transmission offers a more relaxed driving experience, especially in congested city traffic. The suspension is tuned for comfort, effectively absorbing bumps and providing a stable ride, but it doesn’t deliver the sharp handling characteristics of more performance-oriented vehicles.

Equipment & Trim Levels

The 2.0 MPI Automatic trim generally included a comprehensive set of standard features. These typically encompassed air conditioning, power windows and door locks, a touchscreen infotainment system with Apple CarPlay and Android Auto integration, a rearview camera, and a suite of safety technologies such as ABS, electronic stability control, and multiple airbags. Higher sub-trims within the 2.0 MPI range frequently added features like heated front seats, a sunroof, upgraded audio systems, and advanced driver-assistance systems (ADAS) such as lane departure warning and automatic emergency braking. Interior upholstery was commonly cloth, with options for leatherette or full leather available on higher trim levels. Dashboard layouts were generally straightforward and user-friendly, emphasizing ease of operation over elaborate styling.

Chassis & Braking

The Cerato IV Sedan employs a front-wheel-drive layout with an independent McPherson strut suspension in the front and a torsion beam suspension in the rear. This suspension configuration strikes a balance between ride comfort and handling. Braking is provided by ventilated discs at the front and solid discs at the rear. ABS (Anti-lock Braking System) is standard, enhancing braking performance and stability, particularly during emergency stops. The steering system is a rack-and-pinion setup with electric power steering, offering light and responsive steering feel.

Market Reception & Comparison

The Kia Cerato IV Sedan 2.0 MPI Automatic was generally well-received by automotive reviewers as a practical and value-driven compact sedan. Critics lauded its comfortable ride quality, spacious interior, and extensive feature set for its price point. However, some noted its somewhat uninspired driving dynamics and the engine’s modest power output compared to certain competitors. In terms of fuel economy, the 2.0 MPI Automatic achieved around 31.8 US mpg combined, which was competitive within its segment. Reliability ratings were generally favorable, with the Nu engine proving to be a durable and dependable powerplant. Compared to the base 1.6L engine, the 2.0 MPI offered a noticeable improvement in performance, making it a more attractive option for drivers who regularly transport passengers or drive on highways.

Legacy

The Kia Cerato IV Sedan 2.0 MPI Automatic has earned a reputation as a reliable and affordable used car. The Nu engine, while not renowned for its excitement, has demonstrated durability and relatively low maintenance costs. Typical maintenance requirements include routine oil changes, spark plug replacements, and occasional sensor replacements. The six-speed automatic transmission is also generally reliable, provided that proper fluid changes are performed. Today, these Ceratos represent a compelling value for buyers seeking a practical and well-equipped compact sedan at a reasonable price. This model played a significant role in solidifying Kia’s position as a mainstream automotive brand offering competitive alternatives to established Japanese and American manufacturers.
