| General information | |
|---|---|
| Brand | Kia |
| Model | EV9 |
| Generation | EV9 |
| Type (Engine) | 76.1 kWh (215 Hp) Electric |
| Start of production | March, 2023 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 60 mph | 7.7 sec |
| Maximum speed | 190 km/h 118.06 mph |
| 100 km/h – 0 | 39 m |
| Weight-to-power ratio | 10.7 kg/Hp, 93.1 Hp/tonne |
| Weight-to-torque ratio | 6.6 kg/Nm, 151.5 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 76.1 kWh |
| Battery voltage | 632 V |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery weight | 463 kg 1020.74 lbs. |
| Battery location | Below the floor |
| All-electric range (EPA) | 370.1 km 229.97 mi |
| Average Energy consumption (EPA) | 23.8 kWh/100 km
38.3 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 215 Hp @ 4400-9000 rpm. |
| Electric motor Torque | 350 Nm @ 0-4200 rpm.
258.15 lb.-ft. @ 0-4200 rpm. |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 215 Hp |
| System torque | 350 Nm 258.15 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2310 kg 5092.68 lbs. |
| Max. weight | 2910 kg 6415.45 lbs. |
| Max load | 600 kg 1322.77 lbs. |
| Trunk (boot) space – minimum | 572 l 20.2 cu. ft. |
| Trunk (boot) space – maximum | 2313 l 81.68 cu. ft. |
| Permitted trailer load with brakes (12%) | 907 kg 1999.59 lbs. |
| Permitted trailer load without brakes | 454 kg 1000.9 lbs. |
| Dimensions | |
| Length | 5009 mm 197.2 in. |
| Width | 1979 mm 77.91 in. |
| Height | 1750 mm 68.9 in. |
| Wheelbase | 3099 mm 122.01 in. |
| Front track | 1702 mm 67.01 in. |
| Rear (Back) track | 1715 mm 67.52 in. |
| Front overhang | 871 mm 34.29 in. |
| Rear overhang | 1039 mm 40.91 in. |
| Ride height (ground clearance) | 178 mm 7.01 in. |
| Minimum turning circle (turning diameter) | 12.4 m 40.68 ft. |
| Approach angle | 20° |
| Departure angle | 22.8° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the rear wheels. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Spring Strut, Independent type McPherson |
| Rear suspension | Spring Strut, Independent multi-link suspension |
| Front brakes | Ventilated discs, 360.68 mm |
| Rear brakes | Disc, 345.44 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Wheel rims size | 19 |
| What is the body type, Kia EV9? | SUV, 5 Doors, 7 Seats |
|---|---|
| What is the range of pure electric driving, 76.1 kWh (215 Hp) Electric? | 370.1 km 229.97 mi |
| What is electricity consumption, Kia EV9 76.1 kWh (215 Hp) Electric? | 23.8 kWh/100 km 38.3 kWh/100 mi 88 MPGe 4.2 km/kWh 2.6 mi/kWh |
| How fast is the car, 2023 EV9 76.1 kWh (215 Hp) Electric? | 190 km/h | 118.06 mph 0-60 mph: 7.7 sec |
| How much power, Kia EV9 SUV 2023 76.1 kWh (215 Hp) Electric? | 215 Hp, 350 Nm 258.15 lb.-ft. |
| What is the drivetrain, Kia EV9 SUV 2023 76.1 kWh (215 Hp) Electric? | Rear wheel drive. BEV (Electric Vehicle). One electric motor drives the rear wheels. |
| How long is this vehicle, 2023 Kia EV9 SUV? | 5009 mm 197.2 in. |
| How wide is the vehicle, 2023 Kia EV9 SUV? | 1979 mm 77.91 in. |
| What is the curb weight, 2023 Kia EV9 76.1 kWh (215 Hp) Electric? | 2310 kg 5092.68 lbs. |
| What is the gross weight, 2023 Kia EV9 76.1 kWh (215 Hp) Electric? | 2910 kg 6415.45 lbs. |
| How much trunk (boot) space, 2023 Kia EV9 SUV? | 572 – 2313 l 20.2 – 81.68 cu. ft. |
| How many gears, What type is the gearbox, 2023 Kia EV9 76.1 kWh (215 Hp) Electric? | 1, automatic transmission |
