| General information | |
|---|---|
| Brand | Kia |
| Model | EV9 |
| Generation | EV9 |
| Type (Engine) | GT 99.8 kWh (508 Hp) AWD Electric 6 Seat |
| Start of production | May, 2025 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV |
| Seats | 6 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 4.6 sec |
| Acceleration 0 – 62 mph | 4.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 4.4 sec |
| Maximum speed | 220 km/h 136.7 mph |
| Weight-to-power ratio | 5.1 kg/Hp, 197.4 Hp/tonne |
| Weight-to-torque ratio | 3.5 kg/Nm, 287.6 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 99.8 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery weight | 566 kg 1247.82 lbs. |
| Battery location | Below the floor |
| All-electric range (WLTP) | 505 km 313.79 mi |
| Average Energy consumption (WLTP) | 22.8 kWh/100 km
36.69 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| Electric motor 2 | |
| Electric motor location | Rear axle, Transverse |
| Electric motor type | Synchronous |
| System power | 508 Hp |
| System torque | 740 Nm 545.8 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2573-2674 kg 5672.49 – 5895.16 lbs. |
| Max. weight | 3190 kg 7032.75 lbs. |
| Max load | 516-617 kg 1137.59 – 1360.25 lbs. |
| Trunk (boot) space – minimum | 333-828 l 11.76 – 29.24 cu. ft. |
| Trunk (boot) space – maximum | 2393 l 84.51 cu. ft. |
| Max. roof load | 70 kg 154.32 lbs. |
| Permitted trailer load with brakes (12%) | 2500 kg 5511.56 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 125 kg 275.58 lbs. |
| Dimensions | |
| Length | 5015 mm 197.44 in. |
| Width | 1980 mm 77.95 in. |
| Width with mirrors folded | 2047 mm 80.59 in. |
| Width including mirrors | 2263 mm 89.09 in. |
| Height | 1755 mm 69.09 in. |
| Wheelbase | 3100 mm 122.05 in. |
| Front track | 1692 mm 66.61 in. |
| Rear (Back) track | 1703 mm 67.05 in. |
| Front overhang | 875 mm 34.45 in. |
| Rear overhang | 1040 mm 40.94 in. |
| Ride height (ground clearance) | 177 mm 6.97 in. |
| Minimum turning circle (turning diameter) | 12.4 m 40.68 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs, 380 mm |
| Rear brakes | Ventilated discs, 380 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 285/45 R21 113V |
| Wheel rims size | 9J x 21 ET58.5 |
| What is the body type, Kia EV9? | SUV, 5 Doors, 6 Seats |
|---|---|
| What is the range of pure electric driving, GT 99.8 kWh (508 Hp) AWD Electric 6 Seat? | 505 km 313.79 mi |
| What is electricity consumption, Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat? | 22.8 kWh/100 km 36.69 kWh/100 mi 92 MPGe 4.4 km/kWh 2.7 mi/kWh |
| How fast is the car, 2025 EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat? | 220 km/h | 136.7 mph 0-100 km/h: 4.6 sec 0-60 mph: 4.4 sec |
| How much power, Kia EV9 SUV 2025 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat? | 508 Hp, 740 Nm 545.8 lb.-ft. |
| What is the drivetrain, Kia EV9 SUV 2025 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat? | All wheel drive (4×4). BEV (Electric Vehicle). One electric motor drives the front wheels, one electric motor drives the rear wheels. |
| How long is this vehicle, 2025 Kia EV9 SUV? | 5015 mm 197.44 in. |
| How wide is the vehicle, 2025 Kia EV9 SUV? | 1980 mm 77.95 in. |
| What is the curb weight, 2025 Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat? | 2573-2674 kg 5672.49 – 5895.16 lbs. |
| What is the gross weight, 2025 Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat? | 3190 kg 7032.75 lbs. |
| How much trunk (boot) space, 2025 Kia EV9 SUV? | 333 – 2393 l 11.76 – 84.51 cu. ft. |
| How many gears, What type is the gearbox, 2025 Kia EV9 GT 99.8 kWh (508 Hp) AWD Electric 6 Seat? | 1, automatic transmission |
