The Kia Shuma II 1.8i 16V Automatic, produced between 2001 and 2004, represented a significant step forward for Kia in the compact hatchback segment. Positioned as a mid-range offering within the Shuma II lineup – which also included 1.5 and 1.6 liter engine options – the 1.8i Automatic aimed to provide a balance of performance and convenience for buyers seeking a more refined driving experience. Built on the Kia 1HX0 platform (shared with the Hyundai Elantra XD/A3), the Shuma II was primarily marketed in Europe, and to a lesser extent in other global markets, as a practical and affordable family vehicle. This variant combined a 1.8-liter, 16-valve gasoline engine with a four-speed automatic transmission, offering a comfortable and accessible entry point into the compact car class.
Technical Specifications
| Brand | Kia |
| Model | Shuma |
| Generation | Shuma II |
| Type (Engine) | 1.8i 16V (114 Hp) Automatic |
| Start of production | 2001 |
| End of production | 2004 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Fuel consumption (urban) | 13.7 l/100 km (17.2 US mpg, 20.6 UK mpg, 7.3 km/l) |
| Fuel consumption (extra urban) | 7.5 l/100 km (31.4 US mpg, 37.7 UK mpg, 13.3 km/l) |
| Fuel consumption (combined) | 9.8 l/100 km (24 US mpg, 28.8 UK mpg, 10.2 km/l) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 13.5 sec |
| Acceleration 0 – 62 mph | 13.5 sec |
| Acceleration 0 – 60 mph | 12.8 sec |
| Maximum speed | 188 km/h (116.82 mph) |
| Weight-to-power ratio | 10 kg/Hp, 100.4 Hp/tonne |
| Weight-to-torque ratio | 7.5 kg/Nm, 133.9 Nm/tonne |
| Power | 114 Hp @ 5600 rpm |
| Power per litre | 63.6 Hp/l |
| Torque | 152 Nm @ 4500 rpm (112.11 lb.-ft. @ 4500 rpm) |
| Engine layout | Front, Transverse |
| Engine Model/Code | T8D |
| Engine displacement | 1793 cm3 (109.42 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm (3.19 in.) |
| Piston Stroke | 87 mm (3.43 in.) |
| Compression ratio | 9.4:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 4 l (4.23 US qt | 3.52 UK qt) |
| Kerb Weight | 1135 kg (2502.25 lbs.) |
| Max. weight | 1645 kg (3626.6 lbs.) |
| Max load | 510 kg (1124.36 lbs.) |
| Trunk (boot) space – minimum | 440 l (15.54 cu. ft.) |
| Trunk (boot) space – maximum | 1207 l (42.62 cu. ft.) |
| Fuel tank capacity | 50 l (13.21 US gal | 11 UK gal) |
| Length | 4525 mm (178.15 in.) |
| Width | 1720 mm (67.72 in.) |
| Height | 1415 mm (55.71 in.) |
| Wheelbase | 2560 mm (100.79 in.) |
| Front track | 1465 mm (57.68 in.) |
| Rear (Back) track | 1455 mm (57.28 in.) |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Coil spring |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/60 R14 |
| Wheel rims size | 14 |
Powertrain & Engine Architecture
The heart of the Shuma II 1.8i Automatic is the Kia T8D engine, a 1.8-liter inline-four cylinder gasoline engine. This engine utilizes a multi-port fuel injection (MPI) system, delivering fuel directly into the intake ports just before the intake valves. The engine features a dual overhead camshaft (DOHC) design with four valves per cylinder (16V), contributing to improved breathing and overall efficiency. The T8D engine produced 114 horsepower at 5600 rpm and 152 Nm (112 lb-ft) of torque at 4500 rpm. Paired with this engine is a four-speed automatic transmission, providing smooth and convenient gear changes. While not a particularly advanced transmission by modern standards, it was well-suited to the engine’s power characteristics and the intended market positioning of the vehicle. The transmission was designed for reliability and ease of maintenance, rather than outright performance.
Driving Characteristics
The Shuma II 1.8i Automatic offered a comfortable, if not particularly sporty, driving experience. Acceleration from 0 to 60 mph took approximately 12.8 seconds, and top speed was around 116.82 mph. Compared to the manual transmission version of the same engine, the automatic resulted in a slight performance decrease due to the inherent losses in the torque converter. However, the automatic transmission provided a smoother and more relaxed driving experience, particularly in urban traffic. The four-speed automatic’s gear ratios were optimized for fuel efficiency and everyday drivability, rather than aggressive acceleration. The steering was light and easy, making the Shuma II a simple car to maneuver. The suspension, while comfortable, wasn’t particularly sophisticated, resulting in some body roll during cornering.
Equipment & Trim Levels
The 1.8i Automatic trim typically included features such as power windows, central locking, power steering, and an AM/FM radio. Air conditioning was often standard, or available as an option. Interior upholstery was typically cloth, with a relatively simple dashboard layout. Optional extras could include alloy wheels, a sunroof, and upgraded audio systems. The Shuma II aimed for a balance of affordability and features, offering a reasonable level of equipment for its price point. Safety features were relatively basic for the time, typically including ABS brakes and driver/passenger airbags.
Chassis & Braking
The Shuma II utilized a front-wheel-drive layout with a MacPherson strut front suspension and a coil spring rear suspension. The front brakes were ventilated discs, providing adequate stopping power, while the rear brakes were solid discs. The suspension was tuned for comfort, prioritizing ride quality over handling precision. The steering system employed a rack-and-pinion setup with hydraulic power assistance. Tire size was typically 195/60 R14, mounted on 14-inch steel or alloy wheels.
Market Reception & Comparison
The Kia Shuma II 1.8i Automatic was generally well-received as a practical and affordable family car. Critics praised its spacious interior, comfortable ride, and reasonable fuel economy. However, it was often criticized for its somewhat bland styling and lack of driving excitement. Compared to other trims in the Shuma II lineup, the 1.8i Automatic offered a noticeable performance upgrade over the 1.5 and 1.6 liter models, but at the expense of slightly higher fuel consumption. It competed with other compact hatchbacks such as the Ford Focus, Opel/Vauxhall Astra, and Renault Megane.
Legacy
The Kia Shuma II, and specifically the 1.8i Automatic variant, has proven to be a relatively reliable vehicle in the used car market. The T8D engine is known for its durability, and the four-speed automatic transmission is generally robust. However, as with any older vehicle, regular maintenance is crucial to ensure long-term reliability. Common issues can include wear and tear on suspension components, corrosion, and occasional problems with the fuel injection system. Today, the Shuma II is often seen as a budget-friendly option for those seeking a practical and dependable compact hatchback. While not a collector’s item, it represents an important step in Kia’s evolution as a global automotive manufacturer.
