| General information | |
|---|---|
| Brand | Mahindra |
| Model | MM 540/550 |
| Generation | MM 540/550 |
| Type (Engine) | 540 XDB (72 Hp) |
| Start of production | 1990 year |
| End of production | 2004 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Off-road vehicle |
| Seats | 8 |
| Doors | 3 |
| Performance specs | |
| Fuel Type | Diesel |
| Maximum speed | 110 km/h 68.35 mph |
| Weight-to-power ratio | 19 kg/Hp, 52.6 Hp/tonne |
| Weight-to-torque ratio | 9 kg/Nm, 110.9 Nm/tonne |
| Engine specs | |
| Power | 72 Hp @ 4000 rpm. |
| Power per litre | 28.8 Hp/l |
| Torque | 152 Nm @ 2000 rpm. 112.11 lb.-ft. @ 2000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine displacement | 2498 cm3 152.44 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 94 mm 3.7 in. |
| Piston Stroke | 90 mm 3.54 in. |
| Compression ratio | 23:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Precombustion chamber injection |
| Engine aspiration | Naturally aspirated engine |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1370 kg 3020.33 lbs. |
| Max. weight | 2030 kg 4475.38 lbs. |
| Max load | 660 kg 1455.05 lbs. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Dimensions | |
| Length | 3810 mm 150 in. |
| Width | 1650 mm 64.96 in. |
| Height | 1930 mm 75.98 in. |
| Wheelbase | 2430 mm 95.67 in. |
| Front track | 1290 mm 50.79 in. |
| Rear (Back) track | 1290 mm 50.79 in. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Leaf spring |
| Rear suspension | Leaf spring |
| Front brakes | Drum |
| Rear brakes | Drum |
| Assisting systems | ABS (Anti-lock braking system) |
| What is the body type, Mahindra MM 540/550? | Off-road vehicle, 3 Doors, 8 Seats |
|---|---|
| How fast is the car, 1990 MM 540/550 540 XDB (72 Hp)? | 110 km/h | 68.35 mph |
| How much power, Mahindra MM 540/550 Off-road vehicle 1990 540 XDB (72 Hp)? | 72 Hp, 152 Nm 112.11 lb.-ft. |
| What is the engine size, Mahindra MM 540/550 Off-road vehicle 1990 540 XDB (72 Hp)? | 2.5 l 2498 cm3 152.44 cu. in. |
| How many cylinders, 1990 Mahindra 540 XDB (72 Hp)? | 4, Inline |
| What is the drivetrain, Mahindra MM 540/550 Off-road vehicle 1990 540 XDB (72 Hp)? | All wheel drive (4×4). Internal Combustion engine. |
| How long is this vehicle, 1990 Mahindra MM 540/550 Off-road vehicle? | 3810 mm 150 in. |
| How wide is the vehicle, 1990 Mahindra MM 540/550 Off-road vehicle? | 1650 mm 64.96 in. |
| What is the curb weight, 1990 Mahindra MM 540/550 540 XDB (72 Hp)? | 1370 kg 3020.33 lbs. |
| What is the gross weight, 1990 Mahindra MM 540/550 540 XDB (72 Hp)? | 2030 kg 4475.38 lbs. |
| How many gears, What type is the gearbox, 1990 Mahindra MM 540/550 540 XDB (72 Hp)? | 5, manual transmission |
