| General information | |
|---|---|
| Brand | Maxus |
| Model | Deliver 5 |
| Generation | eDeliver 5 L1 |
| Type (Engine) | 64 kWh (163 Hp) Electric |
| Start of production | September, 2024 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Van |
| Seats | 3 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 10.7 sec |
| Acceleration 0 – 62 mph | 10.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 10.2 sec |
| Maximum speed | 120 km/h 74.56 mph |
| Weight-to-power ratio | 11.3 kg/Hp, 88.1 Hp/tonne |
| Weight-to-torque ratio | 7.7 kg/Nm, 129.7 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 64 kWh |
| Battery technology | Lithium iron phosphate (LiFePO4) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 335 km 208.16 mi |
| Average Energy consumption (WLTP) | 21 kWh/100 km
33.8 kWh/100 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 163 Hp |
| Electric motor Torque | 240 Nm
177.01 lb.-ft. |
| Electric motor model/code | TZ180XSSQC |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| System power | 163 Hp |
| System torque | 240 Nm 177.01 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1850 kg 4078.55 lbs. |
| Max. weight | 3050 kg 6724.1 lbs. |
| Max load | 1200 kg 2645.55 lbs. |
| Trunk (boot) space – maximum | 6600 l 233.08 cu. ft. |
| Permitted trailer load with brakes (12%) | 1500 kg 3306.93 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4800 mm 188.98 in. |
| Width | 1874 mm 73.78 in. |
| Height | 1960 mm 77.17 in. |
| Wheelbase | 3100 mm 122.05 in. |
| Front track | 1650 mm 64.96 in. |
| Rear (Back) track | 1650 mm 64.96 in. |
| Front overhang | 650 mm 25.59 in. |
| Rear overhang | 1050 mm 41.34 in. |
| Minimum turning circle (turning diameter) | 11.5 m 37.73 ft. |
| Approach angle | 25.5° |
| Departure angle | 21° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Leaf spring |
| Front brakes | Disc |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 195/65 R16C |
| Wheel rims size | 16 |
| What is the body type, Maxus eDeliver 5 L1? | Van, 5 Doors, 3 Seats |
|---|---|
| What is the range of pure electric driving, 64 kWh (163 Hp) Electric? | 335 km 208.16 mi |
| What is electricity consumption, Maxus eDeliver 5 L1 64 kWh (163 Hp) Electric? | 21 kWh/100 km 33.8 kWh/100 mi 100 MPGe 4.8 km/kWh 3 mi/kWh |
| How fast is the car, 2024 eDeliver 5 L1 64 kWh (163 Hp) Electric? | 120 km/h | 74.56 mph 0-100 km/h: 10.7 sec 0-60 mph: 10.2 sec |
| How much power, Maxus Deliver 5 Van 2024 64 kWh (163 Hp) Electric? | 163 Hp, 240 Nm 177.01 lb.-ft. |
| What is the drivetrain, Maxus eDeliver 5 L1 Van 2024 64 kWh (163 Hp) Electric? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2024 Maxus Deliver 5 Van? | 4800 mm 188.98 in. |
| How wide is the vehicle, 2024 Maxus Deliver 5 Van? | 1874 mm 73.78 in. |
| What is the curb weight, 2024 Maxus eDeliver 5 L1 64 kWh (163 Hp) Electric? | 1850 kg 4078.55 lbs. |
| What is the gross weight, 2024 Maxus eDeliver 5 L1 64 kWh (163 Hp) Electric? | 3050 kg 6724.1 lbs. |
| How much trunk (boot) space, 2024 Maxus Deliver 5 Van? | 6600 l 233.08 cu. ft. |
| How many gears, What type is the gearbox, 2024 Maxus eDeliver 5 L1 64 kWh (163 Hp) Electric? | 1, automatic transmission |
