| General information | |
|---|---|
| Brand | Mazda |
| Model | CX-7 |
| Generation | CX-7 |
| Type (Engine) | 2.3 DISI Turbo (244 Hp) AWD Automatic |
| Start of production | 2006 year |
| End of production | 2009 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV, Crossover |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (EPA) | 13.1-14.7 l/100 km 18 – 16 US mpg 21.6 – 19.2 UK mpg 7.6 – 6.8 km/l |
| Fuel consumption (economy) – extra urban (EPA) | 9.8-10.7 l/100 km 24 – 22 US mpg 28.8 – 26.4 UK mpg 10.2 – 9.3 km/l |
| Fuel Type | Petrol (Gasoline) |
| Emission standard | LEV II |
| Weight-to-power ratio | 7.3 kg/Hp, 136.9 Hp/tonne |
| Weight-to-torque ratio | 5.1 kg/Nm, 196.4 Nm/tonne |
| Engine specs | |
| Power | 244 Hp @ 5000 rpm. |
| Power per litre | 107.9 Hp/l |
| Torque | 350 Nm @ 2500 rpm. 258.15 lb.-ft. @ 2500 rpm. |
| Maximum engine speed | 6700 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | L3-VDT |
| Engine displacement | 2261 cm3 137.97 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 87.5 mm 3.44 in. |
| Piston Stroke | 94 mm 3.7 in. |
| Compression ratio | 9.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.7 l 6.02 US qt | 5.02 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9 l 9.51 US qt | 7.92 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1782 kg 3928.64 lbs. |
| Max. weight | 2267 kg 4997.88 lbs. |
| Max load | 485 kg 1069.24 lbs. |
| Trunk (boot) space – minimum | 847 l 29.91 cu. ft. |
| Trunk (boot) space – maximum | 1659 l 58.59 cu. ft. |
| Fuel tank capacity | 69 l 18.23 US gal | 15.18 UK gal |
| Permitted trailer load with brakes (12%) | 907 kg 1999.59 lbs. |
| Dimensions | |
| Length | 4675 mm 184.06 in. |
| Width | 1872 mm 73.7 in. |
| Height | 1645 mm 64.76 in. |
| Wheelbase | 2750 mm 108.27 in. |
| Front track | 1617 mm 63.66 in. |
| Rear (Back) track | 1612 mm 63.46 in. |
| Ride height (ground clearance) | 206 mm 8.11 in. |
| Minimum turning circle (turning diameter) | 11.4 m 37.4 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 6 gears, automatic transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/60 R18 |
| Wheel rims size | 7.5J x 18 |
| What is the body type, Mazda CX-7? | SUV, Crossover, 5 Doors, 5 Seats |
|---|---|
| How ECO is the car, Mazda CX-7 2.3 DISI Turbo (244 Hp) AWD Automatic? | LEV II |
| How much power, Mazda CX-7 SUV, Crossover 2006 2.3 DISI Turbo (244 Hp) AWD Automatic? | 244 Hp, 350 Nm 258.15 lb.-ft. |
| What is the engine size, Mazda CX-7 SUV, Crossover 2006 2.3 DISI Turbo (244 Hp) AWD Automatic? | 2.3 l 2261 cm3 137.97 cu. in. |
| How many cylinders, 2006 Mazda 2.3 DISI Turbo (244 Hp) AWD Automatic? | 4, Inline |
| What is the drivetrain, Mazda CX-7 SUV, Crossover 2006 2.3 DISI Turbo (244 Hp) AWD Automatic? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary. |
| How long is this vehicle, 2006 Mazda CX-7 SUV, Crossover? | 4675 mm 184.06 in. |
| How wide is the vehicle, 2006 Mazda CX-7 SUV, Crossover? | 1872 mm 73.7 in. |
| What is the curb weight, 2006 Mazda CX-7 2.3 DISI Turbo (244 Hp) AWD Automatic? | 1782 kg 3928.64 lbs. |
| What is the gross weight, 2006 Mazda CX-7 2.3 DISI Turbo (244 Hp) AWD Automatic? | 2267 kg 4997.88 lbs. |
| How much trunk (boot) space, 2006 Mazda CX-7 SUV, Crossover? | 847 – 1659 l 29.91 – 58.59 cu. ft. |
| How many gears, What type is the gearbox, 2006 Mazda CX-7 2.3 DISI Turbo (244 Hp) AWD Automatic? | 6, automatic transmission |
