| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | CLK |
| Generation | CLK (A209, facelift 2005) |
| Type (Engine) | CLK 280 V6 (231 Hp) 7G-TRONIC |
| Start of production | July, 2005 year |
| End of production | August, 2009 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Cabriolet |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 13.3-13.6 l/100 km 17.7 – 17.3 US mpg 21.2 – 20.8 UK mpg 7.5 – 7.4 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 7-7.3 l/100 km 33.6 – 32.2 US mpg 40.4 – 38.7 UK mpg 14.3 – 13.7 km/l |
| Fuel consumption (economy) – combined (NEDC) | 9.3-9.6 l/100 km 25.3 – 24.5 US mpg 30.4 – 29.4 UK mpg 10.8 – 10.4 km/l |
| CO2 emissions (NEDC) | 222-229 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 7.8 sec |
| Acceleration 0 – 62 mph | 7.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.4 sec |
| Maximum speed | 245 km/h 152.24 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 7.1 kg/Hp, 141.7 Hp/tonne |
| Weight-to-torque ratio | 5.4 kg/Nm, 184 Nm/tonne |
| Engine specs | |
| Power | 231 Hp @ 6000 rpm. |
| Power per litre | 77.1 Hp/l |
| Torque | 300 Nm @ 2500-5000 rpm. 221.27 lb.-ft. @ 2500-5000 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 272.940 |
| Engine displacement | 2996 cm3 182.83 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 88 mm 3.46 in. |
| Piston Stroke | 82.1 mm 3.23 in. |
| Compression ratio | 11.3:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 8 l 8.45 US qt | 7.04 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 10 l 10.57 US qt | 8.8 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1630 kg 3593.53 lbs. |
| Max. weight | 2170 kg 4784.03 lbs. |
| Max load | 540 kg 1190.5 lbs. |
| Trunk (boot) space – minimum | 276 l 9.75 cu. ft. |
| Trunk (boot) space – maximum | 390 l 13.77 cu. ft. |
| Fuel tank capacity | 62 l 16.38 US gal | 13.64 UK gal |
| Dimensions | |
| Length | 4652 mm 183.15 in. |
| Width | 1740 mm 68.5 in. |
| Width including mirrors | 1991 mm 78.39 in. |
| Height | 1413 mm 55.63 in. |
| Wheelbase | 2715 mm 106.89 in. |
| Front track | 1493-1497 mm 58.78 – 58.94 in. |
| Rear (Back) track | 1474-1478 mm 58.03 – 58.19 in. |
| Front overhang | 854 mm 33.62 in. |
| Rear overhang | 1083 mm 42.64 in. |
| Minimum turning circle (turning diameter) | 10.76 m 35.3 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission G-TRONIC |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | Front wheel tires: 205/55 R16; 225/45 R17 Rear wheel tires: 225/50 R16; 245/40 R17 |
| Wheel rims size | Front wheel rims: 7J x 16; 7.5J x 17 Rear wheel rims: 8J x 16; 8.5J x 17 |
| What is the body type, Mercedes-Benz CLK (A209, facelift 2005)? | Cabriolet, 2 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz CLK (A209, facelift 2005) CLK 280 V6 (231 Hp) 7G-TRONIC? | 9.3-9.6 l/100 km 25.3 – 24.5 US mpg 30.4 – 29.4 UK mpg 10.8 – 10.4 km/l |
| How ECO is the car, Mercedes-Benz CLK CLK 280 V6 (231 Hp) 7G-TRONIC? | 222-229 g/km CO2 Euro 4 |
| How fast is the car, 2005 CLK (A209, facelift 2005) CLK 280 V6 (231 Hp) 7G-TRONIC? | 245 km/h | 152.24 mph 0-100 km/h: 7.8 sec 0-60 mph: 7.4 sec |
| How much power, Mercedes-Benz CLK Cabriolet 2005 CLK 280 V6 (231 Hp) 7G-TRONIC? | 231 Hp, 300 Nm 221.27 lb.-ft. |
| What is the engine size, Mercedes-Benz CLK Cabriolet 2005 CLK 280 V6 (231 Hp) 7G-TRONIC? | 3.0 l 2996 cm3 182.83 cu. in. |
| How many cylinders, 2005 Mercedes-Benz CLK 280 V6 (231 Hp) 7G-TRONIC? | 6, V-engine |
| What is the drivetrain, Mercedes-Benz CLK (A209, facelift 2005) Cabriolet 2005 CLK 280 V6 (231 Hp) 7G-TRONIC? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 2005 Mercedes-Benz CLK Cabriolet? | 4652 mm 183.15 in. |
| How wide is the vehicle, 2005 Mercedes-Benz CLK Cabriolet? | 1740 mm 68.5 in. |
| What is the curb weight, 2005 Mercedes-Benz CLK (A209, facelift 2005) CLK 280 V6 (231 Hp) 7G-TRONIC? | 1630 kg 3593.53 lbs. |
| What is the gross weight, 2005 Mercedes-Benz CLK (A209, facelift 2005) CLK 280 V6 (231 Hp) 7G-TRONIC? | 2170 kg 4784.03 lbs. |
| How much trunk (boot) space, 2005 Mercedes-Benz CLK Cabriolet? | 276 – 390 l 9.75 – 13.77 cu. ft. |
| How many gears, What type is the gearbox, 2005 Mercedes-Benz CLK (A209, facelift 2005) CLK 280 V6 (231 Hp) 7G-TRONIC? | 7, automatic transmission G-TRONIC |
