| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | E-class |
| Generation | E-class All-Terrain (S214) |
| Type (Engine) | E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC |
| Start of production | September, 2023 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Station wagon (estate), Crossover |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 0.6-6.3 l/100 km 392 – 37.3 US mpg 470.8 – 44.8 UK mpg 166.7 – 15.9 km/l |
| CO2 emissions (WLTP) | 14-22 g/km |
| Fuel Type | Diesel / electricity |
| Acceleration 0 – 100 km/h | 6.9 sec |
| Acceleration 0 – 62 mph | 6.9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 6.6 sec |
| Maximum speed | 213 km/h 132.35 mph |
| Emission standard | Euro 6d-ISC-FCM |
| Weight-to-power ratio | 7.4 kg/Hp, 135.2 Hp/tonne |
| Weight-to-torque ratio | 3.3 kg/Nm, 302.4 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 25.4 kWh |
| Net (usable) battery capacity | 19.53 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Under the trunk |
| All-electric range (WLTP) | 81-101 km 50.33 – 62.76 mi |
| Average Energy consumption (WLTP) | 21.6-25.1 kWh/100 km
34.76 – 40.39 kWh/100 mi |
| Max speed (electric) | 140 km/h
86.99 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 129 Hp |
| Electric motor Torque | 440 Nm
324.53 lb.-ft. |
| Electric motor location | Between the combustion engine and the transmission |
| Electric motor type | Synchronous |
| System power | 313 Hp |
| System torque | 700 Nm 516.29 lb.-ft. |
| Internal combustion engine specs | |
| Power | 197 Hp @ 3600 rpm. |
| Power per litre | 98.8 Hp/l |
| Torque | 440 Nm @ 1800-2800 rpm. 324.53 lb.-ft. @ 1800-2800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | OM 654.820 |
| Engine displacement | 1993 cm3 121.62 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82 mm 3.23 in. |
| Piston Stroke | 94.3 mm 3.71 in. |
| Compression ratio | 15.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6 l 6.34 US qt | 5.28 UK qt |
| Engine oil specification | Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2315 kg 5103.7 lbs. |
| Max. weight | 2970 kg 6547.73 lbs. |
| Max load | 655 kg 1444.03 lbs. |
| Trunk (boot) space – minimum | 460 l 16.24 cu. ft. |
| Trunk (boot) space – maximum | 1675 l 59.15 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| AdBlue tank | 24 l 6.34 US gal | 5.28 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2100 kg 4629.71 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 84 kg 185.19 lbs. |
| Dimensions | |
| Length | 4950 mm 194.88 in. |
| Width | 1889 mm 74.37 in. |
| Width including mirrors | 2065 mm 81.3 in. |
| Height | 1489 mm 58.62 in. |
| Wheelbase | 2961 mm 116.57 in. |
| Front track | 1632 mm 64.25 in. |
| Rear (Back) track | 1648 mm 64.88 in. |
| Front overhang | 848 mm 33.39 in. |
| Rear overhang | 1141 mm 44.92 in. |
| Drag coefficient (Cd) | 0.28 |
| Minimum turning circle (turning diameter) | 12 m 39.37 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission G-TRONIC |
| Front suspension | Independent multi-link suspension, Transverse stabilizer, Air suspension |
| Rear suspension | Independent multi-link suspension, Air suspension, Transverse stabilizer |
| Front brakes | Ventilated discs, 370 mm |
| Rear brakes | Ventilated discs, 360 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | Front wheel tires: 255/40 R19 Rear wheel tires: 285/35 R19 |
| Wheel rims size | Front wheel rims: 8.5J x 19 Rear wheel rims: 10J x 19 |
| What is the body type, Mercedes-Benz E-class All-Terrain (S214)? | Station wagon (estate), Crossover, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz E-class All-Terrain (S214) E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 0.6-6.3 l/100 km 392 – 37.3 US mpg 470.8 – 44.8 UK mpg 166.7 – 15.9 km/l |
| How ECO is the car, Mercedes-Benz E-class E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 14-22 g/km CO2 Euro 6d-ISC-FCM |
| What is the range of pure electric driving, E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 81-101 km 50.33 – 62.76 mi |
| What is electricity consumption, Mercedes-Benz E-class All-Terrain (S214) E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 21.6-25.1 kWh/100 km 34.76 – 40.39 kWh/100 mi 97 – 83 MPGe 4.6 – 4 km/kWh 2.9 – 2.5 mi/kWh |
| How fast is the car, 2023 E-class All-Terrain (S214) E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 213 km/h | 132.35 mph 0-100 km/h: 6.9 sec 0-60 mph: 6.6 sec |
| How much power, Mercedes-Benz E-class Station wagon (estate), Crossover 2023 E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 313 Hp, 700 Nm 516.29 lb.-ft. |
| What is the engine size, Mercedes-Benz E-class Station wagon (estate), Crossover 2023 E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 2.0 l 1993 cm3 121.62 cu. in. |
| How many cylinders, 2023 Mercedes-Benz E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 4, Inline |
| What is the drivetrain, Mercedes-Benz E-class All-Terrain (S214) Station wagon (estate), Crossover 2023 E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | All wheel drive (4×4). PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2023 Mercedes-Benz E-class Station wagon (estate), Crossover? | 4950 mm 194.88 in. |
| How wide is the vehicle, 2023 Mercedes-Benz E-class Station wagon (estate), Crossover? | 1889 mm 74.37 in. |
| What is the curb weight, 2023 Mercedes-Benz E-class All-Terrain (S214) E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 2315 kg 5103.7 lbs. |
| What is the gross weight, 2023 Mercedes-Benz E-class All-Terrain (S214) E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 2970 kg 6547.73 lbs. |
| How much trunk (boot) space, 2023 Mercedes-Benz E-class Station wagon (estate), Crossover? | 460 – 1675 l 16.24 – 59.15 cu. ft. |
| How many gears, What type is the gearbox, 2023 Mercedes-Benz E-class All-Terrain (S214) E 300de (313 Hp) Plug-in Hybrid 4MATIC 9G-TRONIC? | 9, automatic transmission G-TRONIC |
