| General information | |
|---|---|
| Brand | Mercedes-Benz |
| Model | E-class |
| Generation | E-class Coupe (C238, facelift 2020) |
| Type (Engine) | E 220d (194 Hp) 4MATIC 9G-TRONIC |
| Start of production | 2020 year |
| End of production | 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Coupe |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 5.6-6.3 l/100 km 42 – 37.3 US mpg 50.4 – 44.8 UK mpg 17.9 – 15.9 km/l |
| CO2 emissions (WLTP) | 147-165 g/km |
| Fuel consumption (economy) – urban | 6.3-6.6 l/100 km 37.3 – 35.6 US mpg 44.8 – 42.8 UK mpg 15.9 – 15.2 km/l |
| Fuel consumption (economy) – extra urban | 4.6-4.8 l/100 km 51.1 – 49 US mpg 61.4 – 58.9 UK mpg 21.7 – 20.8 km/l |
| Fuel consumption (economy) – combined | 5.2-5.5 l/100 km 45.2 – 42.8 US mpg 54.3 – 51.4 UK mpg 19.2 – 18.2 km/l |
| CO2 emissions | 137-144 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 7.7 sec |
| Acceleration 0 – 62 mph | 7.7 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.3 sec |
| Maximum speed | 229 km/h, Electronically limited 142.29 mph |
| Emission standard | EURO 6d-ISC-FCM |
| Weight-to-power ratio | 9.2 kg/Hp, 109 Hp/tonne |
| Weight-to-torque ratio | 4.5 kg/Nm, 224.7 Nm/tonne |
| Engine specs | |
| Power | 194 Hp |
| Power per litre | 99.5 Hp/l |
| Torque | 400 Nm @ 1600-2800 rpm. 295.02 lb.-ft. @ 1600-2800 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | OM 654 DE 20 LA |
| Engine displacement | 1950 cm3 119 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82 mm 3.23 in. |
| Piston Stroke | 92.3 mm 3.63 in. |
| Compression ratio | 15.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6.3 l 6.66 US qt | 5.54 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1780 kg 3924.23 lbs. |
| Max. weight | 2395 kg 5280.07 lbs. |
| Max load | 615 kg 1355.84 lbs. |
| Trunk (boot) space – minimum | 425 l 15.01 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 1800 kg 3968.32 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4835 mm 190.35 in. |
| Width | 1860 mm 73.23 in. |
| Width including mirrors | 2055 mm 80.91 in. |
| Height | 1428 mm 56.22 in. |
| Wheelbase | 2873 mm 113.11 in. |
| Front track | 1604 mm 63.15 in. |
| Rear (Back) track | 1610 mm 63.39 in. |
| Front overhang | 850 mm 33.46 in. |
| Rear overhang | 1112 mm 43.78 in. |
| Drag coefficient (Cd) | 0.272 |
| Minimum turning circle (turning diameter) | 11.61 m 38.09 ft. |
| Approach angle | 12.8° |
| Departure angle | 14.4° |
| Ramp-over (brakeover) angle | 9.5° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission G-TRONIC |
| Front suspension | Independent multi-link suspension, Transverse stabilizer |
| Rear suspension | Independent multi-link suspension, Transverse stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/55 R17 |
| Wheel rims size | 7.5J x 17 |
| What is the body type, Mercedes-Benz E-class Coupe (C238, facelift 2020)? | Coupe, 2 Doors, 4 Seats |
|---|---|
| What is the fuel economy, Mercedes-Benz E-class Coupe (C238, facelift 2020) E 220d (194 Hp) 4MATIC 9G-TRONIC? | 5.6-6.3 l/100 km 42 – 37.3 US mpg 50.4 – 44.8 UK mpg 17.9 – 15.9 km/l |
| How ECO is the car, Mercedes-Benz E-class E 220d (194 Hp) 4MATIC 9G-TRONIC? | 147-165 g/km CO2 EURO 6d-ISC-FCM |
| How fast is the car, 2020 E-class Coupe (C238, facelift 2020) E 220d (194 Hp) 4MATIC 9G-TRONIC? | 229 km/h | 142.29 mph 0-100 km/h: 7.7 sec 0-60 mph: 7.3 sec |
| How much power, Mercedes-Benz E-class Coupe 2020 E 220d (194 Hp) 4MATIC 9G-TRONIC? | 194 Hp, 400 Nm 295.02 lb.-ft. |
| What is the engine size, Mercedes-Benz E-class Coupe 2020 E 220d (194 Hp) 4MATIC 9G-TRONIC? | 2.0 l 1950 cm3 119 cu. in. |
| How many cylinders, 2020 Mercedes-Benz E 220d (194 Hp) 4MATIC 9G-TRONIC? | 4, Inline |
| What is the drivetrain, Mercedes-Benz E-class Coupe (C238, facelift 2020) Coupe 2020 E 220d (194 Hp) 4MATIC 9G-TRONIC? | All wheel drive (4×4). Internal Combustion engine. The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| How long is this vehicle, 2020 Mercedes-Benz E-class Coupe? | 4835 mm 190.35 in. |
| How wide is the vehicle, 2020 Mercedes-Benz E-class Coupe? | 1860 mm 73.23 in. |
| What is the curb weight, 2020 Mercedes-Benz E-class Coupe (C238, facelift 2020) E 220d (194 Hp) 4MATIC 9G-TRONIC? | 1780 kg 3924.23 lbs. |
| What is the gross weight, 2020 Mercedes-Benz E-class Coupe (C238, facelift 2020) E 220d (194 Hp) 4MATIC 9G-TRONIC? | 2395 kg 5280.07 lbs. |
| How much trunk (boot) space, 2020 Mercedes-Benz E-class Coupe? | 425 l 15.01 cu. ft. |
| How many gears, What type is the gearbox, 2020 Mercedes-Benz E-class Coupe (C238, facelift 2020) E 220d (194 Hp) 4MATIC 9G-TRONIC? | 9, automatic transmission G-TRONIC |
