The Mercedes-Benz E 230 T-modell (S210), produced from May 1995 to January 1998, represented a compelling blend of practicality and luxury within the W210 E-Class range. As the estate version of the E-Class, the T-modell offered increased cargo capacity without sacrificing the refined driving experience expected of a Mercedes-Benz. The E 230 variant, powered by a 2.3-liter inline-four engine producing 150 horsepower, occupied a middle ground in the lineup, positioned as a more accessible alternative to the higher-performance E 320 and E 420 models, as well as the diesel-powered E 300 Diesel. It catered to buyers seeking a comfortable, well-equipped wagon for family use and long-distance travel.
Technical Specifications
| Brand | Mercedes-Benz |
| Model | E-class |
| Generation | E-class T-modell (S210) |
| Type (Engine) | E 230 (150 Hp) |
| Start of production | May, 1995 |
| End of production | January, 1998 |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Fuel consumption (economy) – urban | 11.6 l/100 km (20.3 US mpg) |
| Fuel consumption (economy) – extra urban | 6.6 l/100 km (35.6 US mpg) |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 – 100 km/h | 11.2 sec |
| Acceleration 0 – 62 mph | 11.2 sec |
| Acceleration 0 – 60 mph | 10.6 sec |
| Maximum speed | 208 km/h (129.25 mph) |
| Weight-to-power ratio | 10.5 kg/Hp |
| Weight-to-torque ratio | 7.1 kg/Nm |
| Power | 150 Hp @ 5400 rpm |
| Torque | 220 Nm @ 3800 rpm (162.26 lb.-ft. @ 3800 rpm) |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | M 111 E 23 / 111.970 |
| Engine displacement | 2295 cm3 (140.05 cu. in.) |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 90.9 mm (3.58 in.) |
| Piston Stroke | 88.4 mm (3.48 in.) |
| Compression ratio | 10.4:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
| Engine oil capacity | 5.5 l (5.81 US qt | 4.84 UK qt) |
| Coolant | 8.5 l (8.98 US qt | 7.48 UK qt) |
| Kerb Weight | 1570 kg (3461.26 lbs.) |
| Max. weight | 2150 kg (4739.94 lbs.) |
| Max load | 580 kg (1278.68 lbs.) |
| Trunk (boot) space – minimum | 600 l (21.19 cu. ft.) |
| Trunk (boot) space – maximum | 1975 l (69.75 cu. ft.) |
| Fuel tank capacity | 70 l (18.49 US gal | 15.4 UK gal) |
| Length | 4816 mm (189.61 in.) |
| Width | 1799 mm (70.83 in.) |
| Height | 1505 mm (59.25 in.) |
| Wheelbase | 2833 mm (111.54 in.) |
| Front track | 1542 mm (60.71 in.) |
| Rear (Back) track | 1546 mm (60.87 in.) |
| Drivetrain Architecture | Rear wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Double wishbone |
| Rear suspension | Hydro-pneumatic element, Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/65 R15 |
| Wheel rims size | 7J x 15 |
Powertrain & Engine Architecture
The heart of the E 230 T-modell was the M111 E 23 engine, a 2.3-liter inline-four cylinder powerplant. This engine was a significant departure from the older CIS (Continuous Injection System) engines previously used by Mercedes-Benz, embracing multi-port fuel injection for improved efficiency and performance. The M111 featured a double overhead camshaft (DOHC) valvetrain with four valves per cylinder, contributing to its relatively high specific output. The engine code 111.970 identifies this specific iteration. The engine produced 150 horsepower at 5400 rpm and 220 Nm (162 lb-ft) of torque at 3800 rpm. The five-speed manual transmission was standard, providing a direct connection to the rear wheels. While an automatic transmission was available, it impacted acceleration and fuel economy.
Driving Characteristics
The E 230 T-modell, with its 150 hp and manual transmission, offered a balanced driving experience. Acceleration from 0 to 60 mph took approximately 10.6 seconds, and top speed was limited to 208 km/h (129 mph). While not a sports car, the E 230 provided sufficient power for comfortable highway cruising and overtaking. The manual transmission allowed for greater driver control, but the relatively long gearing emphasized fuel economy over outright performance. Compared to the E 320, which boasted a significantly more powerful six-cylinder engine, the E 230 felt less responsive. However, the E 230’s lighter weight and simpler engine design contributed to better fuel economy and potentially lower maintenance costs.
Equipment & Trim Levels
The E 230 T-modell came standard with a respectable array of features, including power windows, power locks, and air conditioning. Interior upholstery typically consisted of cloth, although leather was available as an option. The dashboard layout was typical of the W210 E-Class, featuring a straightforward design with clearly marked gauges. Optional extras included a sunroof, upgraded audio system, and automatic climate control. The T-modell also benefited from the estate-specific features such as a self-leveling rear suspension, designed to maintain ride height even when heavily loaded, and a retractable cargo cover for security and privacy.
Chassis & Braking
The E 230 T-modell utilized a double wishbone suspension at the front and an independent multi-link hydro-pneumatic suspension at the rear. This suspension setup provided a comfortable ride and good handling characteristics. Brakes consisted of ventilated discs at the front and solid discs at the rear, with ABS (Anti-lock Braking System) as standard equipment. The steering was rack and pinion with hydraulic power assistance, offering precise and responsive control. The standard tire size was 205/65 R15, mounted on 7J x 15 inch wheels.
Market Reception & Comparison
The E 230 T-modell was generally well-received by automotive critics. It was praised for its practicality, comfort, and build quality. However, some reviewers noted that the 2.3-liter engine felt somewhat underpowered, particularly when the vehicle was fully loaded. Compared to the E 320 T-modell, the E 230 offered a more affordable entry point into the E-Class estate range, but at the expense of performance. Fuel economy was a strong point for the E 230, making it an attractive option for drivers who prioritized efficiency. Reliability was generally good, although the complex rear suspension system could require occasional maintenance.
Legacy
The M111 engine, found in the E 230 T-modell, proved to be a durable and reliable powerplant. While not known for exceptional performance, it offered a good balance of efficiency and longevity. Today, the W210 E-Class T-modell, including the E 230 variant, has gained a following among enthusiasts who appreciate its classic Mercedes-Benz styling and practicality. Well-maintained examples are becoming increasingly sought after, particularly those with lower mileage and a complete service history. The E 230 T-modell represents a refined and versatile estate car from a golden era of Mercedes-Benz engineering.
